TDengine 时序函数 DIFF 用户手册
DIFF 函数用户手册
函数概述
DIFF 函数用于计算数据列中相邻两行数据的差值，通常用于分析数据的变化趋势和增量。该函数特别适用于监控智能电表数据的变化模式。
语法
SELECT DIFF(column_name [, ignore_negative]) FROM table_name;
参数说明
column_name: 数值型列名，支持整数和浮点数类型ignore_negative: 可选参数，整数类型- 0 或省略：保留负数结果
- 1：忽略负数结果，负数结果显示为 NULL
返回值类型
- 输入为整数类型：返回 BIGINT
- 输入为浮点数类型：返回 DOUBLE
智能电表场景应用示例
基于智能电表数据库结构：
-- 数据库和表结构
USE test;
-- meters 超级表包含 ts, current, voltage, phase 字段和 location, groupid 标签
基础用法示例
电流变化监控
-- 计算电流的变化量
SELECT ts, current, DIFF(current) as current_diff
FROM meters
WHERE tbname = 'd1001'
ORDER BY ts;-- 计算电压的变化量
SELECT ts, voltage, DIFF(voltage) as voltage_diff
FROM meters
WHERE tbname = 'd1001'
ORDER BY ts;-- 计算相位的变化量
SELECT ts, phase, DIFF(phase) as phase_diff
FROM meters
WHERE tbname = 'd1001'
ORDER BY ts;
忽略负数差值
-- 只关注电流增长的情况
SELECT ts, current, DIFF(current, 1) as current_growth
FROM meters
WHERE tbname = 'd1001'
ORDER BY ts;-- 只关注电压上升的情况
SELECT ts, voltage, DIFF(voltage, 1) as voltage_rise
FROM meters
WHERE tbname = 'd1001'
ORDER BY ts;
用电量增量分析
累计用电量变化
-- 分析累计电流的变化（模拟累计用电量）
SELECT ts, current, DIFF(current) as power_increment
FROM meters
WHERE location = 'California.LosAngles' AND tbname = 'd1001'
ORDER BY ts;
按时间段分析用电增量
-- 分析最近一小时的用电增量
SELECT ts, current, DIFF(current) as hourly_increment
FROM meters
WHERE tbname = 'd1001' AND ts >= NOW() - 1h
ORDER BY ts;-- 分析今日的用电增量
SELECT ts, current, DIFF(current) as daily_increment
FROM meters
WHERE tbname = 'd1001' AND ts >= TODAY()
ORDER BY ts;
电网负载变化监控
实时负载变化
-- 监控实时负载变化
SELECT ts, current, DIFF(current) as load_change
FROM meters
WHERE location = 'California.SanFrancisco'AND tbname = 'd1002'
ORDER BY ts DESC
LIMIT 100;
异常负载检测
-- 检测电流突变（变化超过5A）
SELECT ts, current, DIFF(current) as current_change
FROM meters
WHERE tbname = 'd1001'AND ABS(DIFF(current)) > 5
ORDER BY ts;
电压质量监控
电压波动分析
-- 分析电压波动情况
SELECT ts, voltage, DIFF(voltage) as voltage_fluctuation
FROM meters
WHERE location = 'California.Cupertino'AND tbname = 'd1003'
ORDER BY ts;
相位角变化监控
相位漂移检测
-- 监控相位漂移
SELECT ts, phase, DIFF(phase) as phase_drift
FROM meters
WHERE location = 'California.MountainView'AND tbname = 'd1004'
ORDER BY ts;
相位稳定性分析
-- 分析相位稳定性（忽略负变化）
SELECT ts, phase, DIFF(phase, 1) as phase_improvement
FROM meters
WHERE tbname = 'd1004'
ORDER BY ts;
多设备对比分析
按设备分组计算差值
-- 按设备分组计算各自的电流变化
SELECT tbname, ts, current, DIFF(current) as current_change
FROM meters
WHERE location = 'California.SanJose'
PARTITION BY tbname
ORDER BY tbname, ts;
设备性能对比
-- 对比不同设备的电压变化模式
SELECT tbname, ts, voltage, DIFF(voltage) as voltage_change
FROM meters
WHERE location = 'California.Sunnyvale'
PARTITION BY tbname
ORDER BY tbname, ts;
能效分析应用
设备效率变化
-- 分析设备效率变化（电流与电压的关系变化）
SELECT ts, current, voltage, DIFF(current) as current_change,DIFF(voltage) as voltage_change
FROM meters
WHERE tbname = 'd1001'
ORDER BY ts;
重要限制和注意事项
-
函数限制：
- TDengine 不支持函数嵌套：
DIFF(ABS(current))❌ - 不支持在 WHERE 中直接使用：
WHERE DIFF(current) > 10❌
- TDengine 不支持函数嵌套：
-
数据要求：
- 第一行数据的 DIFF 值为 NULL（没有前一行数据）
- 输入列必须是数值型
- 按时间戳顺序计算差值
-
结果特点：
- 返回行数 = 输入行数（第一行为 NULL）
- NULL 值参与计算时结果为 NULL
- 支持分区计算，各分区独立计算差值
