概述

增强现实（AR）技术将虚拟内容叠加到真实世界中，创造沉浸式体验。本节重点介绍基于标记（Marker）的AR技术，涵盖标记识别、姿态估计、虚拟物体跟踪等核心概念。

AR系统架构：

核心原理

标记识别流程

步骤	技术方法	输出结果
图像预处理	灰度化、高斯模糊、二值化	优化后的二值图像
轮廓检测	Canny边缘检测、轮廓查找	潜在标记轮廓
形状分析	多边形近似、矩形验证	候选标记区域
编码解码	透视校正、比特矩阵读取	标记ID和姿态

姿态估计算法

// 相机姿态估计
class PoseEstimator {// 解决PnP问题：从2D-3D点对应关系估计相机姿态solvePnP(imagePoints, objectPoints, cameraMatrix) {// imagePoints: 图像中的2D点// objectPoints: 对应的3D物体点// cameraMatrix: 相机内参矩阵// 使用EPnP或迭代法求解return {rotation: this.estimateRotation(imagePoints, objectPoints),translation: this.estimateTranslation(imagePoints, objectPoints),reprojectionError: this.calculateError(imagePoints, objectPoints)};}// 计算重投影误差calculateError(imagePoints, objectPoints, rotation, translation) {let totalError = 0;for (let i = 0; i < imagePoints.length; i++) {const projected = this.projectPoint(objectPoints[i], rotation, translation);const error = Math.sqrt(Math.pow(projected.x - imagePoints[i].x, 2) +Math.pow(projected.y - imagePoints[i].y, 2));totalError += error;}return totalError / imagePoints.length;}
}

完整代码实现

AR标记跟踪系统

<template><div class="ar-marker-container"><!-- 视频流显示 --><div class="video-section"><video ref="videoElement" class="video-feed" autoplay playsinline></video><canvas ref="processingCanvas" class="processing-canvas"></canvas><!-- 状态指示器 --><div class="status-indicator" :class="trackingStatus">{{ statusMessage }}</div></div><!-- 控制面板 --><div class="control-panel"><div class="panel-section"><h3>🎯 标记设置</h3><div class="marker-controls"><div class="control-group"><label>标记类型</label><select v-model="markerType"><option value="aruco">ArUco标记</option><option value="qr">QR码</option><option value="custom">自定义</option></select></div><div class="control-group"><label>标记ID</label><input type="number" v-model="targetMarkerId" min="0" max="1023"></div><div class="control-group"><label>标记尺寸 (cm)</label><input type="number" v-model="markerSize" min="1" max="50"></div></div></div><div class="panel-section"><h3>📱 相机控制</h3><div class="camera-controls"><button @click="toggleCamera" class="control-button">{{ isCameraActive ? '🛑 停止相机' : '📷 启动相机' }}</button><div class="control-group"><label>相机分辨率</label><select v-model="cameraResolution"><option value="low">低 (640x480)</option><option value="medium">中 (1280x720)</option><option value="high">高 (1920x1080)</option></select></div></div></div><div class="panel-section"><h3>🎮 虚拟内容</h3><div class="content-controls"><div class="control-group"><label>显示模型</label><select v-model="selectedModel"><option value="cube">立方体</option><option value="sphere">球体</option><option value="teapot">茶壶</option><option value="custom">自定义模型</option></select></div><div class="control-group"><label>模型缩放</label><input type="range" v-model="modelScale" min="0.1" max="3" step="0.1"><span>{{ modelScale }}x</span></div><button @click="addVirtualObject" class="control-button">➕ 添加物体</button></div></div><div class="panel-section"><h3>📊 跟踪信息</h3><div class="tracking-info"><div class="info-item"><span>标记状态:</span><span :class="trackingStatus">{{ trackingStatusText }}</span></div><div class="info-item"><span>检测到的ID:</span><span>{{ detectedMarkerId !== null ? detectedMarkerId : '无' }}</span></div><div class="info-item"><span>置信度:</span><span>{{ detectionConfidence }}%</span></div><div class="info-item"><span>跟踪帧率:</span><span>{{ trackingFPS }} FPS</span></div><div class="info-item"><span>位置误差:</span><span>{{ positionError.toFixed(2) }} px</span></div></div></div></div><!-- 3D预览面板 --><div class="preview-panel" v-if="show3DPreview"><div class="preview-header"><h4>3D场景预览</h4><button @click="show3DPreview = false" class="close-button">×</button></div><canvas ref="previewCanvas" class="preview-canvas"></canvas></div><!-- 加载状态 --><div v-if="isLoading" class="loading-overlay"><div class="loading-spinner"></div><p>初始化AR系统...</p></div></div>
</template><script>
import { onMounted, onUnmounted, ref, reactive } from 'vue';
import * as THREE from 'three';// 简化版标记检测器
class SimpleMarkerDetector {constructor() {this.canvas = document.createElement('canvas');this.ctx = this.canvas.getContext('2d');this.detectionParams = {minContourArea: 1000,aspectRatioRange: { min: 0.8, max: 1.2 }};}// 检测图像中的标记async detectMarkers(videoElement) {const { width, height } = this.getOptimalCanvasSize(videoElement);this.canvas.width = width;this.canvas.height = height;// 绘制视频帧到画布this.ctx.drawImage(videoElement, 0, 0, width, height);// 获取图像数据const imageData = this.ctx.getImageData(0, 0, width, height);// 简化检测逻辑const markers = this.findCandidateMarkers(imageData);return this.validateMarkers(markers);}// 寻找候选标记findCandidateMarkers(imageData) {const candidates = [];const grayData = this.grayscale(imageData);const binaryData = this.adaptiveThreshold(grayData);const contours = this.findContours(binaryData);for (const contour of contours) {if (this.isPotentialMarker(contour)) {const corners = this.approxPolygon(contour);if (corners.length === 4) {candidates.push({corners,area: this.contourArea(contour)});}}}return candidates;}// 验证标记validateMarkers(candidates) {const validMarkers = [];for (const candidate of candidates) {// 透视校正const warped = this.perspectiveWarp(candidate.corners);// 解码标记IDconst markerInfo = this.decodeMarker(warped);if (markerInfo) {validMarkers.push({id: markerInfo.id,corners: candidate.corners,confidence: markerInfo.confidence});}}return validMarkers;}// 图像处理辅助方法grayscale(imageData) {const data = new Uint8ClampedArray(imageData.data.length / 4);for (let i = 0, j = 0; i < imageData.data.length; i += 4, j++) {data[j] = Math.round(0.299 * imageData.data[i] +0.587 * imageData.data[i + 1] +0.114 * imageData.data[i + 2]);}return data;}adaptiveThreshold(data) {const binary = new Uint8ClampedArray(data.length);const blockSize = 15;const c = 5;// 简化实现 - 实际应使用积分图像for (let i = 0; i < data.length; i++) {binary[i] = data[i] > 128 ? 255 : 0;}return binary;}// 其他图像处理方法的简化实现...findContours() { return []; }isPotentialMarker() { return true; }approxPolygon() { return []; }contourArea() { return 0; }perspectiveWarp() { return null; }decodeMarker() { return { id: 1, confidence: 0.9 }; }getOptimalCanvasSize() { return { width: 640, height: 480 }; }
}// 姿态估计器
class PoseEstimator {estimatePose(markerCorners, markerSize, cameraMatrix) {// 3D物体点（假设标记在XY平面上，Z=0）const objectPoints = [[-markerSize/2, -markerSize/2, 0],[markerSize/2, -markerSize/2, 0],[markerSize/2, markerSize/2, 0],[-markerSize/2, markerSize/2, 0]];// 使用EPnP算法求解姿态return this.solveEPnP(markerCorners, objectPoints, cameraMatrix);}solveEPnP(imagePoints, objectPoints, cameraMatrix) {// 简化实现 - 实际应使用数值优化const rotation = new THREE.Matrix3();const translation = new THREE.Vector3(0, 0, 50); // 默认距离return {rotation: new THREE.Matrix4().setFromMatrix3(rotation),translation,reprojectionError: 2.5};}
}// AR场景管理器
class ARSceneManager {constructor(renderer, camera) {this.renderer = renderer;this.camera = camera;this.scene = new THREE.Scene();this.virtualObjects = new Map();this.setupScene();}setupScene() {// 添加环境光const ambientLight = new THREE.AmbientLight(0x404040, 0.6);this.scene.add(ambientLight);// 添加方向光const directionalLight = new THREE.DirectionalLight(0xffffff, 0.8);directionalLight.position.set(1, 1, 1);this.scene.add(directionalLight);}// 添加虚拟物体到标记addVirtualObject(markerId, objectType = 'cube', scale = 1) {let geometry, material;switch (objectType) {case 'cube':geometry = new THREE.BoxGeometry(1, 1, 1);material = new THREE.MeshStandardMaterial({ color: 0x00ff88,transparent: true,opacity: 0.8});break;case 'sphere':geometry = new THREE.SphereGeometry(0.5, 32, 32);material = new THREE.MeshStandardMaterial({ color: 0xff4444,transparent: true,opacity: 0.8});break;case 'teapot':// 简化茶壶几何体geometry = new THREE.CylinderGeometry(0.5, 0.3, 1, 8);material = new THREE.MeshStandardMaterial({ color: 0x8844ff,transparent: true,opacity: 0.8});break;}const mesh = new THREE.Mesh(geometry, material);mesh.scale.setScalar(scale);mesh.visible = false; // 初始隐藏this.scene.add(mesh);this.virtualObjects.set(markerId, mesh);return mesh;}// 更新虚拟物体位置updateObjectPose(markerId, pose) {const object = this.virtualObjects.get(markerId);if (!object) return;object.visible = true;object.position.copy(pose.translation);object.rotation.setFromRotationMatrix(pose.rotation);}// 隐藏物体hideObject(markerId) {const object = this.virtualObjects.get(markerId);if (object) {object.visible = false;}}// 渲染场景render() {this.renderer.render(this.scene, this.camera);}
}export default {name: 'ARMarkerTracking',setup() {// 响应式数据const videoElement = ref(null);const processingCanvas = ref(null);const previewCanvas = ref(null);const isCameraActive = ref(false);const isLoading = ref(false);const trackingStatus = ref('searching');const statusMessage = ref('寻找标记中...');const markerType = ref('aruco');const targetMarkerId = ref(1);const markerSize = ref(10);const cameraResolution = ref('medium');const selectedModel = ref('cube');const modelScale = ref(1);const show3DPreview = ref(false);const detectedMarkerId = ref(null);const detectionConfidence = ref(0);const trackingFPS = ref(0);const positionError = ref(0);// 计算属性const trackingStatusText = {searching: '寻找标记',tracking: '跟踪中',lost: '跟踪丢失'}[trackingStatus.value];// AR系统组件let markerDetector, poseEstimator, sceneManager;let camera, renderer, arRenderer;let animationFrameId;let frameCount = 0;let lastFpsUpdate = 0;// 初始化AR系统const initARSystem = async () => {isLoading.value = true;// 初始化组件markerDetector = new SimpleMarkerDetector();poseEstimator = new PoseEstimator();// 初始化3D渲染await init3DRenderer();isLoading.value = false;};// 初始化3D渲染器const init3DRenderer = async () => {if (!previewCanvas.value) return;// 创建Three.js场景renderer = new THREE.WebGLRenderer({ canvas: previewCanvas.value,antialias: true,alpha: true});camera = new THREE.PerspectiveCamera(60, 1, 0.1, 1000);sceneManager = new ARSceneManager(renderer, camera);// 添加示例物体sceneManager.addVirtualObject(1, 'cube', 1);// 启动渲染循环animate3DScene();};// 3D场景动画const animate3DScene = () => {animationFrameId = requestAnimationFrame(animate3DScene);sceneManager.render();};// 相机控制const toggleCamera = async () => {if (isCameraActive.value) {stopCamera();} else {await startCamera();}};// 启动相机const startCamera = async () => {try {const stream = await navigator.mediaDevices.getUserMedia({video: {width: { ideal: 1280 },height: { ideal: 720 },facingMode: 'environment'}});videoElement.value.srcObject = stream;isCameraActive.value = true;// 开始AR跟踪循环startARTracking();} catch (error) {console.error('无法访问相机:', error);statusMessage.value = '相机访问失败';}};// 停止相机const stopCamera = () => {if (videoElement.value.srcObject) {videoElement.value.srcObject.getTracks().forEach(track => track.stop());videoElement.value.srcObject = null;}isCameraActive.value = false;trackingStatus.value = 'searching';if (animationFrameId) {cancelAnimationFrame(animationFrameId);}};// AR跟踪循环const startARTracking = () => {const processFrame = async () => {if (!isCameraActive.value) return;// 检测标记const markers = await markerDetector.detectMarkers(videoElement.value);// 处理检测结果await processDetectionResults(markers);// 更新性能统计updatePerformanceStats();// 继续下一帧animationFrameId = requestAnimationFrame(processFrame);};processFrame();};// 处理检测结果const processDetectionResults = async (markers) => {const targetMarker = markers.find(m => m.id === targetMarkerId.value);if (targetMarker) {// 找到目标标记trackingStatus.value = 'tracking';statusMessage.value = `跟踪标记 #${targetMarker.id}`;detectedMarkerId.value = targetMarker.id;detectionConfidence.value = Math.round(targetMarker.confidence * 100);// 估计姿态const cameraMatrix = this.getCameraMatrix(); // 需要实现const pose = poseEstimator.estimatePose(targetMarker.corners,markerSize.value,cameraMatrix);positionError.value = pose.reprojectionError;// 更新虚拟物体sceneManager.updateObjectPose(targetMarker.id, pose);} else {// 未找到标记trackingStatus.value = 'searching';statusMessage.value = '寻找标记中...';detectedMarkerId.value = null;detectionConfidence.value = 0;if (detectedMarkerId.value !== null) {sceneManager.hideObject(detectedMarkerId.value);}}};// 更新性能统计const updatePerformanceStats = () => {frameCount++;const now = performance.now();if (now - lastFpsUpdate >= 1000) {trackingFPS.value = Math.round((frameCount * 1000) / (now - lastFpsUpdate));frameCount = 0;lastFpsUpdate = now;}};// 添加虚拟物体const addVirtualObject = () => {sceneManager.addVirtualObject(targetMarkerId.value, selectedModel.value, modelScale.value);};// 获取相机矩阵（简化实现）const getCameraMatrix = () => {return new THREE.Matrix4().makePerspective(60 * Math.PI / 180,videoElement.value.videoWidth / videoElement.value.videoHeight,0.1,1000);};onMounted(() => {initARSystem();});onUnmounted(() => {stopCamera();if (animationFrameId) {cancelAnimationFrame(animationFrameId);}});return {// 模板引用videoElement,processingCanvas,previewCanvas,// 状态数据isCameraActive,isLoading,trackingStatus,statusMessage,markerType,targetMarkerId,markerSize,cameraResolution,selectedModel,modelScale,show3DPreview,detectedMarkerId,detectionConfidence,trackingFPS,positionError,trackingStatusText,// 方法toggleCamera,addVirtualObject};}
};
</script><style scoped>
.ar-marker-container {width: 100%;height: 100vh;display: flex;background: #000;overflow: hidden;
}.video-section {flex: 1;position: relative;background: #000;
}.video-feed {width: 100%;height: 100%;object-fit: cover;
}.processing-canvas {position: absolute;top: 0;left: 0;width: 100%;height: 100%;pointer-events: none;
}.status-indicator {position: absolute;top: 20px;left: 20px;padding: 10px 20px;background: rgba(0, 0, 0, 0.7);color: white;border-radius: 20px;font-size: 14px;backdrop-filter: blur(10px);border: 1px solid rgba(255, 255, 255, 0.2);
}.status-indicator.searching {background: rgba(255, 165, 0, 0.7);
}.status-indicator.tracking {background: rgba(0, 255, 0, 0.7);
}.status-indicator.lost {background: rgba(255, 0, 0, 0.7);
}.control-panel {width: 350px;background: #2d2d2d;padding: 20px;overflow-y: auto;border-left: 1px solid #444;
}.panel-section {margin-bottom: 25px;padding-bottom: 20px;border-bottom: 1px solid #444;
}.panel-section:last-child {margin-bottom: 0;border-bottom: none;
}.panel-section h3 {color: #00ffff;margin-bottom: 15px;font-size: 16px;
}.control-group {margin-bottom: 15px;
}.control-group label {display: block;margin-bottom: 8px;color: #ccc;font-size: 14px;
}.control-group select,
.control-group input[type="number"] {width: 100%;padding: 8px 12px;background: #444;border: 1px solid #666;border-radius: 4px;color: white;font-size: 14px;
}.control-group input[type="range"] {width: 100%;margin: 8px 0;
}.control-button {width: 100%;padding: 12px;background: linear-gradient(45deg, #667eea, #764ba2);color: white;border: none;border-radius: 6px;cursor: pointer;font-size: 14px;transition: all 0.3s ease;
}.control-button:hover {transform: translateY(-2px);box-shadow: 0 5px 15px rgba(0, 0, 0, 0.3);
}.tracking-info {display: flex;flex-direction: column;gap: 10px;
}.info-item {display: flex;justify-content: space-between;align-items: center;padding: 8px 0;border-bottom: 1px solid #444;
}.info-item:last-child {border-bottom: none;
}.info-item span:first-child {color: #ccc;
}.info-item span:last-child {color: #00ff88;font-weight: bold;
}.preview-panel {position: absolute;bottom: 20px;right: 370px;width: 300px;height: 200px;background: #2d2d2d;border-radius: 8px;border: 1px solid #444;overflow: hidden;
}.preview-header {padding: 10px 15px;background: #1a1a1a;display: flex;justify-content: space-between;align-items: center;border-bottom: 1px solid #444;
}.preview-header h4 {margin: 0;color: #00ffff;font-size: 14px;
}.close-button {background: none;border: none;color: #ccc;font-size: 20px;cursor: pointer;padding: 0;width: 24px;height: 24px;display: flex;align-items: center;justify-content: center;
}.preview-canvas {width: 100%;height: calc(100% - 45px);display: block;
}.loading-overlay {position: absolute;top: 0;left: 0;width: 100%;height: 100%;background: rgba(0, 0, 0, 0.8);display: flex;flex-direction: column;justify-content: center;align-items: center;z-index: 1000;
}.loading-spinner {width: 40px;height: 40px;border: 4px solid #333;border-top: 4px solid #00ffff;border-radius: 50%;animation: spin 1s linear infinite;margin-bottom: 15px;
}.loading-overlay p {color: white;margin: 0;
}@keyframes spin {0% { transform: rotate(0deg); }100% { transform: rotate(360deg); }
}/* 响应式设计 */
@media (max-width: 1024px) {.ar-marker-container {flex-direction: column;}.control-panel {width: 100%;height: 300px;}.preview-panel {right: 20px;bottom: 320px;}
}@media (max-width: 768px) {.preview-panel {display: none;}.control-panel {height: 400px;}
}
</style>

高级特性实现

多标记跟踪系统

// 多标记跟踪管理器
class MultiMarkerTracker {constructor() {this.activeMarkers = new Map();this.trackingHistory = new Map();this.maxHistorySize = 60; // 保留60帧历史}// 更新标记状态updateMarkers(detectedMarkers) {const currentTime = performance.now();// 更新现有标记for (const [markerId, marker] of this.activeMarkers) {const detected = detectedMarkers.find(m => m.id === markerId);if (detected) {// 更新位置和置信度marker.lastSeen = currentTime;marker.corners = detected.corners;marker.confidence = detected.confidence;marker.isVisible = true;this.addToHistory(markerId, detected);} else {// 标记暂时丢失marker.isVisible = false;marker.confidence *= 0.9; // 置信度衰减}}// 添加新检测到的标记for (const detected of detectedMarkers) {if (!this.activeMarkers.has(detected.id)) {this.activeMarkers.set(detected.id, {id: detected.id,corners: detected.corners,confidence: detected.confidence,firstSeen: currentTime,lastSeen: currentTime,isVisible: true});}}// 清理长时间未见的标记this.cleanupOldMarkers(currentTime);}// 添加位置历史addToHistory(markerId, markerData) {if (!this.trackingHistory.has(markerId)) {this.trackingHistory.set(markerId, []);}const history = this.trackingHistory.get(markerId);history.push({timestamp: performance.now(),corners: markerData.corners,confidence: markerData.confidence});// 限制历史记录大小if (history.length > this.maxHistorySize) {history.shift();}}// 清理旧标记cleanupOldMarkers(currentTime) {const timeout = 5000; // 5秒超时for (const [markerId, marker] of this.activeMarkers) {if (currentTime - marker.lastSeen > timeout) {this.activeMarkers.delete(markerId);this.trackingHistory.delete(markerId);}}}// 获取稳定位置（使用历史数据平滑）getStablePosition(markerId, smoothingFactor = 0.3) {const history = this.trackingHistory.get(markerId);if (!history || history.length < 2) {return this.activeMarkers.get(markerId)?.corners;}// 使用加权平均平滑位置const recentFrames = history.slice(-5); // 最近5帧let weightedCorners = null;for (const frame of recentFrames) {if (!weightedCorners) {weightedCorners = frame.corners.map(corner => ({x: corner.x * frame.confidence,y: corner.y * frame.confidence}));} else {frame.corners.forEach((corner, index) => {weightedCorners[index].x += corner.x * frame.confidence;weightedCorners[index].y += corner.y * frame.confidence;});}}// 归一化const totalConfidence = recentFrames.reduce((sum, frame) => sum + frame.confidence, 0);return weightedCorners.map(corner => ({x: corner.x / totalConfidence,y: corner.y / totalConfidence}));}
}

姿态平滑过滤器

// 卡尔曼滤波器用于姿态平滑
class PoseKalmanFilter {constructor() {this.state = {x: 0, y: 0, z: 0,vx: 0, vy: 0, vz: 0,qx: 0, qy: 0, qz: 0, qw: 1};this.covariance = this.initializeCovariance();this.processNoise = 0.1;this.measurementNoise = 1.0;}// 预测步骤predict(deltaTime) {// 状态转移：x = x + v * dtthis.state.x += this.state.vx * deltaTime;this.state.y += this.state.vy * deltaTime;this.state.z += this.state.vz * deltaTime;// 简化协方差更新this.covariance = this.covariance.map(row => row.map(value => value + this.processNoise));return this.state;}// 更新步骤update(measurement) {// 计算卡尔曼增益const K = this.calculateKalmanGain();// 状态更新this.state.x += K[0] * (measurement.x - this.state.x);this.state.y += K[1] * (measurement.y - this.state.y);this.state.z += K[2] * (measurement.z - this.state.z);// 四元数球面线性插值this.state = this.slerpQuaternion(this.state, measurement, K[3]);// 协方差更新this.updateCovariance(K);return this.state;}// 四元数球面线性插值slerpQuaternion(from, to, t) {const result = { ...from };// 简化SLERP实现const dot = from.qx * to.qx + from.qy * to.qy + from.qz * to.qz + from.qw * to.qw;if (dot > 0.9995) {// 线性插值result.qx = from.qx + t * (to.qx - from.qx);result.qy = from.qy + t * (to.qy - from.qy);result.qz = from.qz + t * (to.qz - from.qz);result.qw = from.qw + t * (to.qw - from.qw);} else {// 球面插值const theta = Math.acos(dot);const sinTheta = Math.sin(theta);const ratio1 = Math.sin((1 - t) * theta) / sinTheta;const ratio2 = Math.sin(t * theta) / sinTheta;result.qx = ratio1 * from.qx + ratio2 * to.qx;result.qy = ratio1 * from.qy + ratio2 * to.qy;result.qz = ratio1 * from.qz + ratio2 * to.qz;result.qw = ratio1 * from.qw + ratio2 * to.qw;}// 归一化const length = Math.sqrt(result.qx * result.qx + result.qy * result.qy +result.qz * result.qz + result.qw * result.qw);result.qx /= length;result.qy /= length;result.qz /= length;result.qw /= length;return result;}calculateKalmanGain() {// 简化卡尔曼增益计算return [0.8, 0.8, 0.8, 0.5];}initializeCovariance() {return [[1, 0, 0, 0],[0, 1, 0, 0],[0, 0, 1, 0],[0, 0, 0, 1]];}updateCovariance(K) {// 简化协方差更新for (let i = 0; i < this.covariance.length; i++) {for (let j = 0; j < this.covariance[i].length; j++) {this.covariance[i][j] *= (1 - K[i]);}}}
}

本节介绍了基于标记的AR系统核心实现，包括标记识别、姿态估计和虚拟内容跟踪。通过这套系统，开发者可以构建稳定的AR应用，将数字内容精准地锚定在现实世界中。
