快学快用系列：一文学会java后端WebApi开发
文章目录
- 第一部分：Web API开发基础概念
- 1.1 什么是Web API
- 1.2 RESTful API设计原则
- 第二部分：开发环境搭建
- 2.1 环境要求
- 2.2 创建Spring Boot项目
- 2.3 配置文件
- 第三部分：项目架构设计
- 3.1 分层架构
- 3.2 包结构设计
- 第四部分：数据模型设计
- 4.1 实体类设计
- 4.2 DTO设计
- 第五部分：数据访问层实现
- 5.1 Repository接口
- 5.2 自定义Repository实现
- 第六部分：业务逻辑层实现
- 6.1 Service接口设计
- 6.2 Service实现类
- 第七部分：控制器层实现
- 7.1 基础控制器
- 7.2 全局异常处理
- 第八部分：安全配置
- 8.1 Spring Security配置
- 8.2 JWT认证配置
- 第九部分：高级特性实现
- 9.1 缓存配置
- 9.2 异步处理
- 第十部分：测试
- 10.1 单元测试
- 10.2 集成测试
- 第十一部分：部署与监控
- 11.1 Docker配置
- 11.2 健康检查与监控
- 第十二部分：最佳实践与总结
- 12.1 API设计最佳实践
- 12.2 性能优化建议
- 12.3 安全考虑
- 12.4 总结
第一部分：Web API开发基础概念
1.1 什么是Web API
Web API（Application Programming Interface）是一种允许不同软件系统之间进行通信的接口。在Web开发中，API通常基于HTTP协议，使用RESTful架构风格，通过URL端点提供数据和服务。
Web API的核心特点：
- 基于HTTP/HTTPS协议
- 返回结构化数据（JSON/XML）
- 无状态通信
- 跨平台兼容
1.2 RESTful API设计原则
REST（Representational State Transfer）是一种软件架构风格，包含以下核心原则：
- 统一接口：使用标准的HTTP方法和状态码
- 无状态：每个请求包含所有必要信息
- 可缓存：响应应标记为可缓存或不可缓存
- 分层系统：客户端不需要知道是否连接到最终服务器
- 按需代码：服务器可以临时扩展功能
第二部分：开发环境搭建
2.1 环境要求
必需工具：
- JDK 8或以上版本
- IDE（IntelliJ IDEA/Eclipse）
- Maven 3.6+ 或 Gradle
- MySQL/PostgreSQL数据库
2.2 创建Spring Boot项目
使用Spring Initializr创建项目：
<!-- pom.xml -->
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"><modelVersion>4.0.0</modelVersion><parent><groupId>org.springframework.boot</groupId><artifactId>spring-boot-starter-parent</artifactId><version>2.7.0</version><relativePath/></parent><groupId>com.example</groupId><artifactId>webapi-demo</artifactId><version>1.0.0</version><properties><java.version>11</java.version></properties><dependencies><dependency><groupId>org.springframework.boot</groupId><artifactId>spring-boot-starter-web</artifactId></dependency><dependency><groupId>org.springframework.boot</groupId><artifactId>spring-boot-starter-data-jpa</artifactId></dependency><dependency><groupId>org.springframework.boot</groupId><artifactId>spring-boot-starter-validation</artifactId></dependency><dependency><groupId>mysql</groupId><artifactId>mysql-connector-java</artifactId></dependency><dependency><groupId>org.springframework.boot</groupId><artifactId>spring-boot-starter-test</artifactId><scope>test</scope></dependency></dependencies>
</project>
2.3 配置文件
# application.yml
server:port: 8080servlet:context-path: /apispring:datasource:url: jdbc:mysql://localhost:3306/webapi_dbusername: rootpassword: passworddriver-class-name: com.mysql.cj.jdbc.Driverjpa:hibernate:ddl-auto: updateshow-sql: trueproperties:hibernate:dialect: org.hibernate.dialect.MySQL8Dialectformat_sql: truelogging:level:com.example: DEBUGorg.hibernate.SQL: DEBUG
第三部分：项目架构设计
3.1 分层架构
典型的Java Web API采用分层架构：
Controller层 (API接口)↓
Service层 (业务逻辑)↓
Repository层 (数据访问)↓
Model层 (数据模型)
3.2 包结构设计
src/main/java/com/example/webapi/
├── config/ # 配置类
├── controller/ # 控制器
├── service/ # 业务逻辑
├── repository/ # 数据访问
├── model/ # 数据模型
│ ├── entity/ # 实体类
│ ├── dto/ # 数据传输对象
│ └── vo/ # 视图对象
├── exception/ # 异常处理
└── util/ # 工具类
第四部分：数据模型设计
4.1 实体类设计
// User.java
package com.example.webapi.model.entity;import javax.persistence.*;
import javax.validation.constraints.*;
import java.time.LocalDateTime;
import java.util.List;@Entity
@Table(name = "users")
public class User {@Id@GeneratedValue(strategy = GenerationType.IDENTITY)private Long id;@NotBlank(message = "用户名不能为空")@Size(min = 3, max = 50, message = "用户名长度必须在3-50字符之间")@Column(unique = true, nullable = false)private String username;@Email(message = "邮箱格式不正确")@Column(unique = true, nullable = false)private String email;@NotBlank(message = "密码不能为空")@Size(min = 6, message = "密码长度至少6位")private String password;private String phone;@Enumerated(EnumType.STRING)private UserStatus status = UserStatus.ACTIVE;@Column(name = "created_at")private LocalDateTime createdAt;@Column(name = "updated_at")private LocalDateTime updatedAt;// 构造方法public User() {this.createdAt = LocalDateTime.now();this.updatedAt = LocalDateTime.now();}// Getter和Setter方法// ... 省略具体实现
}enum UserStatus {ACTIVE, INACTIVE, DELETED
}
4.2 DTO设计
// UserDTO.java
package com.example.webapi.model.dto;import javax.validation.constraints.*;
import java.time.LocalDateTime;public class UserDTO {private Long id;@NotBlank(message = "用户名不能为空")private String username;@Email(message = "邮箱格式不正确")private String email;private String phone;private LocalDateTime createdAt;// 构造方法public UserDTO() {}// Getter和Setter// ... 省略具体实现
}// CreateUserRequest.java
package com.example.webapi.model.dto;import javax.validation.constraints.*;public class CreateUserRequest {@NotBlank(message = "用户名不能为空")@Size(min = 3, max = 50)private String username;@Email@NotBlankprivate String email;@NotBlank@Size(min = 6)private String password;private String phone;// Getter和Setter// ... 省略具体实现
}
第五部分：数据访问层实现
5.1 Repository接口
// UserRepository.java
package com.example.webapi.repository;import com.example.webapi.model.entity.User;
import com.example.webapi.model.entity.UserStatus;
import org.springframework.data.jpa.repository.JpaRepository;
import org.springframework.data.jpa.repository.Query;
import org.springframework.data.repository.query.Param;
import org.springframework.stereotype.Repository;import java.util.List;
import java.util.Optional;@Repository
public interface UserRepository extends JpaRepository<User, Long> {Optional<User> findByUsername(String username);Optional<User> findByEmail(String email);List<User> findByStatus(UserStatus status);boolean existsByUsername(String username);boolean existsByEmail(String email);@Query("SELECT u FROM User u WHERE u.email LIKE %:email%")List<User> findByEmailContaining(@Param("email") String email);@Query("SELECT u FROM User u WHERE u.createdAt >= :startDate AND u.createdAt < :endDate")List<User> findUsersByCreateTimeRange(@Param("startDate") LocalDateTime startDate, @Param("endDate") LocalDateTime endDate);
}
5.2 自定义Repository实现
// UserRepositoryCustom.java
package com.example.webapi.repository;import com.example.webapi.model.entity.User;
import org.springframework.data.domain.Page;
import org.springframework.data.domain.Pageable;import java.util.List;public interface UserRepositoryCustom {Page<User> findUsersWithPagination(String keyword, Pageable pageable);List<User> findActiveUsersWithRecentActivity();
}// UserRepositoryCustomImpl.java
package com.example.webapi.repository;import com.example.webapi.model.entity.User;
import com.example.webapi.model.entity.UserStatus;
import org.springframework.data.domain.Page;
import org.springframework.data.domain.PageImpl;
import org.springframework.data.domain.Pageable;
import org.springframework.stereotype.Repository;import javax.persistence.EntityManager;
import javax.persistence.PersistenceContext;
import javax.persistence.TypedQuery;
import java.time.LocalDateTime;
import java.util.List;@Repository
public class UserRepositoryCustomImpl implements UserRepositoryCustom {@PersistenceContextprivate EntityManager entityManager;@Overridepublic Page<User> findUsersWithPagination(String keyword, Pageable pageable) {String countQueryStr = "SELECT COUNT(u) FROM User u WHERE " +"(u.username LIKE :keyword OR u.email LIKE :keyword) AND u.status = 'ACTIVE'";TypedQuery<Long> countQuery = entityManager.createQuery(countQueryStr, Long.class);countQuery.setParameter("keyword", "%" + keyword + "%");Long total = countQuery.getSingleResult();String queryStr = "SELECT u FROM User u WHERE " +"(u.username LIKE :keyword OR u.email LIKE :keyword) AND u.status = 'ACTIVE' " +"ORDER BY u.createdAt DESC";TypedQuery<User> query = entityManager.createQuery(queryStr, User.class);query.setParameter("keyword", "%" + keyword + "%");query.setFirstResult((int) pageable.getOffset());query.setMaxResults(pageable.getPageSize());List<User> users = query.getResultList();return new PageImpl<>(users, pageable, total);}@Overridepublic List<User> findActiveUsersWithRecentActivity() {String queryStr = "SELECT u FROM User u WHERE u.status = 'ACTIVE' " +"AND u.updatedAt >= :recentTime";return entityManager.createQuery(queryStr, User.class).setParameter("recentTime", LocalDateTime.now().minusDays(7)).getResultList();}
}
第六部分：业务逻辑层实现
6.1 Service接口设计
// UserService.java
package com.example.webapi.service;import com.example.webapi.model.dto.CreateUserRequest;
import com.example.webapi.model.dto.UpdateUserRequest;
import com.example.webapi.model.dto.UserDTO;
import org.springframework.data.domain.Page;
import org.springframework.data.domain.Pageable;import java.util.List;public interface UserService {UserDTO createUser(CreateUserRequest request);UserDTO getUserById(Long id);UserDTO getUserByUsername(String username);Page<UserDTO> getAllUsers(Pageable pageable);List<UserDTO> searchUsers(String keyword);UserDTO updateUser(Long id, UpdateUserRequest request);void deleteUser(Long id);boolean existsByUsername(String username);boolean existsByEmail(String email);
}
6.2 Service实现类
// UserServiceImpl.java
package com.example.webapi.service.impl;import com.example.webapi.model.dto.CreateUserRequest;
import com.example.webapi.model.dto.UpdateUserRequest;
import com.example.webapi.model.dto.UserDTO;
import com.example.webapi.model.entity.User;
import com.example.webapi.model.entity.UserStatus;
import com.example.webapi.repository.UserRepository;
import com.example.webapi.service.UserService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.data.domain.Page;
import org.springframework.data.domain.Pageable;
import org.springframework.security.crypto.password.PasswordEncoder;
import org.springframework.stereotype.Service;
import org.springframework.transaction.annotation.Transactional;import java.util.List;
import java.util.stream.Collectors;@Service
@Transactional
public class UserServiceImpl implements UserService {@Autowiredprivate UserRepository userRepository;@Autowiredprivate PasswordEncoder passwordEncoder;@Overridepublic UserDTO createUser(CreateUserRequest request) {// 检查用户名和邮箱是否已存在if (userRepository.existsByUsername(request.getUsername())) {throw new RuntimeException("用户名已存在");}if (userRepository.existsByEmail(request.getEmail())) {throw new RuntimeException("邮箱已存在");}// 创建用户实体User user = new User();user.setUsername(request.getUsername());user.setEmail(request.getEmail());user.setPassword(passwordEncoder.encode(request.getPassword()));user.setPhone(request.getPhone());user.setStatus(UserStatus.ACTIVE);User savedUser = userRepository.save(user);return convertToDTO(savedUser);}@Override@Transactional(readOnly = true)public UserDTO getUserById(Long id) {User user = userRepository.findById(id).orElseThrow(() -> new RuntimeException("用户不存在"));return convertToDTO(user);}@Override@Transactional(readOnly = true)public UserDTO getUserByUsername(String username) {User user = userRepository.findByUsername(username).orElseThrow(() -> new RuntimeException("用户不存在"));return convertToDTO(user);}@Override@Transactional(readOnly = true)public Page<UserDTO> getAllUsers(Pageable pageable) {return userRepository.findAll(pageable).map(this::convertToDTO);}@Override@Transactional(readOnly = true)public List<UserDTO> searchUsers(String keyword) {return userRepository.findByEmailContaining(keyword).stream().map(this::convertToDTO).collect(Collectors.toList());}@Overridepublic UserDTO updateUser(Long id, UpdateUserRequest request) {User user = userRepository.findById(id).orElseThrow(() -> new RuntimeException("用户不存在"));// 更新用户信息if (request.getEmail() != null && !request.getEmail().equals(user.getEmail())) {if (userRepository.existsByEmail(request.getEmail())) {throw new RuntimeException("邮箱已存在");}user.setEmail(request.getEmail());}if (request.getPhone() != null) {user.setPhone(request.getPhone());}User updatedUser = userRepository.save(user);return convertToDTO(updatedUser);}@Overridepublic void deleteUser(Long id) {User user = userRepository.findById(id).orElseThrow(() -> new RuntimeException("用户不存在"));user.setStatus(UserStatus.DELETED);userRepository.save(user);}@Override@Transactional(readOnly = true)public boolean existsByUsername(String username) {return userRepository.existsByUsername(username);}@Override@Transactional(readOnly = true)public boolean existsByEmail(String email) {return userRepository.existsByEmail(email);}// 转换实体为DTOprivate UserDTO convertToDTO(User user) {UserDTO dto = new UserDTO();dto.setId(user.getId());dto.setUsername(user.getUsername());dto.setEmail(user.getEmail());dto.setPhone(user.getPhone());dto.setCreatedAt(user.getCreatedAt());return dto;}
}
第七部分：控制器层实现
7.1 基础控制器
// UserController.java
package com.example.webapi.controller;import com.example.webapi.model.dto.CreateUserRequest;
import com.example.webapi.model.dto.UpdateUserRequest;
import com.example.webapi.model.dto.UserDTO;
import com.example.webapi.service.UserService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.data.domain.Page;
import org.springframework.data.domain.PageRequest;
import org.springframework.data.domain.Pageable;
import org.springframework.data.domain.Sort;
import org.springframework.http.HttpStatus;
import org.springframework.http.ResponseEntity;
import org.springframework.validation.annotation.Validated;
import org.springframework.web.bind.annotation.*;import javax.validation.Valid;
import java.util.HashMap;
import java.util.List;
import java.util.Map;@RestController
@RequestMapping("/users")
@Validated
public class UserController {@Autowiredprivate UserService userService;@PostMappingpublic ResponseEntity<?> createUser(@Valid @RequestBody CreateUserRequest request) {try {UserDTO user = userService.createUser(request);return ResponseEntity.status(HttpStatus.CREATED).body(createSuccessResponse("用户创建成功", user));} catch (RuntimeException e) {return ResponseEntity.badRequest().body(createErrorResponse(e.getMessage()));}}@GetMapping("/{id}")public ResponseEntity<?> getUserById(@PathVariable Long id) {try {UserDTO user = userService.getUserById(id);return ResponseEntity.ok(createSuccessResponse("获取用户成功", user));} catch (RuntimeException e) {return ResponseEntity.status(HttpStatus.NOT_FOUND).body(createErrorResponse(e.getMessage()));}}@GetMappingpublic ResponseEntity<?> getAllUsers(@RequestParam(defaultValue = "0") int page,@RequestParam(defaultValue = "10") int size,@RequestParam(defaultValue = "createdAt") String sort) {Pageable pageable = PageRequest.of(page, size, Sort.by(sort).descending());Page<UserDTO> users = userService.getAllUsers(pageable);Map<String, Object> response = new HashMap<>();response.put("success", true);response.put("message", "获取用户列表成功");response.put("data", users.getContent());response.put("currentPage", users.getNumber());response.put("totalItems", users.getTotalElements());response.put("totalPages", users.getTotalPages());return ResponseEntity.ok(response);}@GetMapping("/search")public ResponseEntity<?> searchUsers(@RequestParam String keyword) {List<UserDTO> users = userService.searchUsers(keyword);return ResponseEntity.ok(createSuccessResponse("搜索用户成功", users));}@PutMapping("/{id}")public ResponseEntity<?> updateUser(@PathVariable Long id, @Valid @RequestBody UpdateUserRequest request) {try {UserDTO user = userService.updateUser(id, request);return ResponseEntity.ok(createSuccessResponse("用户更新成功", user));} catch (RuntimeException e) {return ResponseEntity.badRequest().body(createErrorResponse(e.getMessage()));}}@DeleteMapping("/{id}")public ResponseEntity<?> deleteUser(@PathVariable Long id) {try {userService.deleteUser(id);return ResponseEntity.ok(createSuccessResponse("用户删除成功", null));} catch (RuntimeException e) {return ResponseEntity.badRequest().body(createErrorResponse(e.getMessage()));}}// 工具方法：创建成功响应private Map<String, Object> createSuccessResponse(String message, Object data) {Map<String, Object> response = new HashMap<>();response.put("success", true);response.put("message", message);response.put("data", data);response.put("timestamp", System.currentTimeMillis());return response;}// 工具方法：创建错误响应private Map<String, Object> createErrorResponse(String message) {Map<String, Object> response = new HashMap<>();response.put("success", false);response.put("message", message);response.put("timestamp", System.currentTimeMillis());return response;}
}
7.2 全局异常处理
// GlobalExceptionHandler.java
package com.example.webapi.exception;import org.springframework.http.HttpStatus;
import org.springframework.http.ResponseEntity;
import org.springframework.validation.FieldError;
import org.springframework.web.bind.MethodArgumentNotValidException;
import org.springframework.web.bind.annotation.ExceptionHandler;
import org.springframework.web.bind.annotation.RestControllerAdvice;import javax.servlet.http.HttpServletRequest;
import java.util.HashMap;
import java.util.Map;@RestControllerAdvice
public class GlobalExceptionHandler {@ExceptionHandler(MethodArgumentNotValidException.class)public ResponseEntity<?> handleValidationExceptions(MethodArgumentNotValidException ex, HttpServletRequest request) {Map<String, String> errors = new HashMap<>();ex.getBindingResult().getAllErrors().forEach((error) -> {String fieldName = ((FieldError) error).getField();String errorMessage = error.getDefaultMessage();errors.put(fieldName, errorMessage);});Map<String, Object> response = new HashMap<>();response.put("success", false);response.put("message", "参数验证失败");response.put("errors", errors);response.put("path", request.getRequestURI());response.put("timestamp", System.currentTimeMillis());return ResponseEntity.status(HttpStatus.BAD_REQUEST).body(response);}@ExceptionHandler(RuntimeException.class)public ResponseEntity<?> handleRuntimeException(RuntimeException ex, HttpServletRequest request) {Map<String, Object> response = new HashMap<>();response.put("success", false);response.put("message", ex.getMessage());response.put("path", request.getRequestURI());response.put("timestamp", System.currentTimeMillis());return ResponseEntity.status(HttpStatus.BAD_REQUEST).body(response);}@ExceptionHandler(Exception.class)public ResponseEntity<?> handleGlobalException(Exception ex, HttpServletRequest request) {Map<String, Object> response = new HashMap<>();response.put("success", false);response.put("message", "服务器内部错误");response.put("path", request.getRequestURI());response.put("timestamp", System.currentTimeMillis());return ResponseEntity.status(HttpStatus.INTERNAL_SERVER_ERROR).body(response);}
}
第八部分：安全配置
8.1 Spring Security配置
// SecurityConfig.java
package com.example.webapi.config;import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.security.config.annotation.web.builders.HttpSecurity;
import org.springframework.security.config.annotation.web.configuration.EnableWebSecurity;
import org.springframework.security.config.http.SessionCreationPolicy;
import org.springframework.security.crypto.bcrypt.BCryptPasswordEncoder;
import org.springframework.security.crypto.password.PasswordEncoder;
import org.springframework.security.web.SecurityFilterChain;@Configuration
@EnableWebSecurity
public class SecurityConfig {@Beanpublic SecurityFilterChain filterChain(HttpSecurity http) throws Exception {http.cors().and().csrf().disable().sessionManagement().sessionCreationPolicy(SessionCreationPolicy.STATELESS).and().authorizeRequests().antMatchers("/api/auth/**").permitAll().antMatchers("/api/users/create").permitAll().antMatchers("/api/public/**").permitAll().anyRequest().authenticated();return http.build();}@Beanpublic PasswordEncoder passwordEncoder() {return new BCryptPasswordEncoder();}
}
8.2 JWT认证配置
// JwtUtils.java
package com.example.webapi.util;import io.jsonwebtoken.*;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.stereotype.Component;import java.util.Date;@Component
public class JwtUtils {@Value("${app.jwt.secret}")private String jwtSecret;@Value("${app.jwt.expiration}")private int jwtExpirationMs;public String generateJwtToken(String username) {return Jwts.builder().setSubject(username).setIssuedAt(new Date()).setExpiration(new Date((new Date()).getTime() + jwtExpirationMs)).signWith(SignatureAlgorithm.HS512, jwtSecret).compact();}public String getUserNameFromJwtToken(String token) {return Jwts.parser().setSigningKey(jwtSecret).parseClaimsJws(token).getBody().getSubject();}public boolean validateJwtToken(String authToken) {try {Jwts.parser().setSigningKey(jwtSecret).parseClaimsJws(authToken);return true;} catch (SignatureException e) {// 日志记录} catch (MalformedJwtException e) {// 日志记录} catch (ExpiredJwtException e) {// 日志记录} catch (UnsupportedJwtException e) {// 日志记录} catch (IllegalArgumentException e) {// 日志记录}return false;}
}
第九部分：高级特性实现
9.1 缓存配置
// CacheConfig.java
package com.example.webapi.config;import org.springframework.cache.CacheManager;
import org.springframework.cache.annotation.EnableCaching;
import org.springframework.cache.concurrent.ConcurrentMapCacheManager;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;import java.util.Arrays;@Configuration
@EnableCaching
public class CacheConfig {@Beanpublic CacheManager cacheManager() {ConcurrentMapCacheManager cacheManager = new ConcurrentMapCacheManager();cacheManager.setCacheNames(Arrays.asList("users", "products"));return cacheManager;}
}// 在Service中使用缓存
@Service
public class UserServiceImpl implements UserService {@Cacheable(value = "users", key = "#id")@Overridepublic UserDTO getUserById(Long id) {// 从数据库获取用户}@CacheEvict(value = "users", key = "#id")@Overridepublic UserDTO updateUser(Long id, UpdateUserRequest request) {// 更新用户}
}
9.2 异步处理
// AsyncConfig.java
package com.example.webapi.config;import org.springframework.context.annotation.Configuration;
import org.springframework.scheduling.annotation.EnableAsync;
import org.springframework.scheduling.concurrent.ThreadPoolTaskExecutor;import java.util.concurrent.Executor;@Configuration
@EnableAsync
public class AsyncConfig {@Bean(name = "taskExecutor")public Executor taskExecutor() {ThreadPoolTaskExecutor executor = new ThreadPoolTaskExecutor();executor.setCorePoolSize(5);executor.setMaxPoolSize(10);executor.setQueueCapacity(100);executor.setThreadNamePrefix("AsyncThread-");executor.initialize();return executor;}
}// 异步服务
@Service
public class EmailService {@Async("taskExecutor")public void sendWelcomeEmail(String email, String username) {// 发送邮件的逻辑try {Thread.sleep(5000); // 模拟耗时操作System.out.println("欢迎邮件已发送至: " + email);} catch (InterruptedException e) {Thread.currentThread().interrupt();}}
}
第十部分：测试
10.1 单元测试
// UserServiceTest.java
package com.example.webapi.service;import com.example.webapi.model.dto.CreateUserRequest;
import com.example.webapi.model.dto.UserDTO;
import com.example.webapi.model.entity.User;
import com.example.webapi.repository.UserRepository;
import org.junit.jupiter.api.BeforeEach;
import org.junit.jupiter.api.Test;
import org.junit.jupiter.api.extension.ExtendWith;
import org.mockito.InjectMocks;
import org.mockito.Mock;
import org.mockito.junit.jupiter.MockitoExtension;
import org.springframework.security.crypto.password.PasswordEncoder;import java.util.Optional;import static org.junit.jupiter.api.Assertions.*;
import static org.mockito.ArgumentMatchers.any;
import static org.mockito.Mockito.*;@ExtendWith(MockitoExtension.class)
class UserServiceTest {@Mockprivate UserRepository userRepository;@Mockprivate PasswordEncoder passwordEncoder;@InjectMocksprivate UserServiceImpl userService;private CreateUserRequest createUserRequest;@BeforeEachvoid setUp() {createUserRequest = new CreateUserRequest();createUserRequest.setUsername("testuser");createUserRequest.setEmail("test@example.com");createUserRequest.setPassword("password123");createUserRequest.setPhone("13800138000");}@Testvoid createUser_Success() {// 准备when(userRepository.existsByUsername("testuser")).thenReturn(false);when(userRepository.existsByEmail("test@example.com")).thenReturn(false);when(passwordEncoder.encode("password123")).thenReturn("encodedPassword");User savedUser = new User();savedUser.setId(1L);savedUser.setUsername("testuser");savedUser.setEmail("test@example.com");when(userRepository.save(any(User.class))).thenReturn(savedUser);// 执行UserDTO result = userService.createUser(createUserRequest);// 验证assertNotNull(result);assertEquals(1L, result.getId());assertEquals("testuser", result.getUsername());assertEquals("test@example.com", result.getEmail());verify(userRepository, times(1)).save(any(User.class));}@Testvoid getUserById_UserExists() {// 准备User user = new User();user.setId(1L);user.setUsername("testuser");user.setEmail("test@example.com");when(userRepository.findById(1L)).thenReturn(Optional.of(user));// 执行UserDTO result = userService.getUserById(1L);// 验证assertNotNull(result);assertEquals(1L, result.getId());assertEquals("testuser", result.getUsername());}
}
10.2 集成测试
// UserControllerIntegrationTest.java
package com.example.webapi.controller;import com.example.webapi.model.dto.CreateUserRequest;
import com.example.webapi.repository.UserRepository;
import com.fasterxml.jackson.databind.ObjectMapper;
import org.junit.jupiter.api.Test;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.boot.test.autoconfigure.web.servlet.AutoConfigureMockMvc;
import org.springframework.boot.test.context.SpringBootTest;
import org.springframework.http.MediaType;
import org.springframework.test.web.servlet.MockMvc;
import org.springframework.transaction.annotation.Transactional;import static org.springframework.test.web.servlet.request.MockMvcRequestBuilders.*;
import static org.springframework.test.web.servlet.result.MockMvcResultMatchers.*;@SpringBootTest
@AutoConfigureMockMvc
@Transactional
class UserControllerIntegrationTest {@Autowiredprivate MockMvc mockMvc;@Autowiredprivate ObjectMapper objectMapper;@Autowiredprivate UserRepository userRepository;@Testvoid createUser_ValidRequest_ReturnsCreated() throws Exception {CreateUserRequest request = new CreateUserRequest();request.setUsername("integrationtest");request.setEmail("integration@test.com");request.setPassword("password123");mockMvc.perform(post("/api/users").contentType(MediaType.APPLICATION_JSON).content(objectMapper.writeValueAsString(request))).andExpect(status().isCreated()).andExpect(jsonPath("$.success").value(true)).andExpect(jsonPath("$.data.username").value("integrationtest"));}@Testvoid getUserById_UserExists_ReturnsUser() throws Exception {// 先创建用户CreateUserRequest request = new CreateUserRequest();request.setUsername("testuser");request.setEmail("test@example.com");request.setPassword("password123");String response = mockMvc.perform(post("/api/users").contentType(MediaType.APPLICATION_JSON).content(objectMapper.writeValueAsString(request))).andReturn().getResponse().getContentAsString();// 提取用户ID并查询// 这里简化处理，实际应该解析响应获取IDmockMvc.perform(get("/api/users/1")).andExpect(status().isOk()).andExpect(jsonPath("$.success").value(true));}
}
第十一部分：部署与监控
11.1 Docker配置
# Dockerfile
FROM openjdk:11-jre-slimWORKDIR /appCOPY target/webapi-demo-1.0.0.jar app.jarRUN sh -c 'touch /app.jar'ENV JAVA_OPTS=""EXPOSE 8080ENTRYPOINT [ "sh", "-c", "java $JAVA_OPTS -Djava.security.egd=file:/dev/./urandom -jar /app.jar" ]
# docker-compose.yml
version: '3.8'services:webapi:build: .ports:- "8080:8080"environment:- SPRING_DATASOURCE_URL=jdbc:mysql://mysql:3306/webapi_db- SPRING_DATASOURCE_USERNAME=root- SPRING_DATASOURCE_PASSWORD=passworddepends_on:- mysqlmysql:image: mysql:8.0environment:- MYSQL_ROOT_PASSWORD=password- MYSQL_DATABASE=webapi_dbports:- "3306:3306"volumes:- mysql_data:/var/lib/mysqlvolumes:mysql_data:
11.2 健康检查与监控
// HealthCheckController.java
package com.example.webapi.controller;import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.boot.actuate.health.HealthComponent;
import org.springframework.boot.actuate.health.HealthEndpoint;
import org.springframework.jdbc.core.JdbcTemplate;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;import java.util.HashMap;
import java.util.Map;@RestController
@RequestMapping("/health")
public class HealthCheckController {@Autowiredprivate JdbcTemplate jdbcTemplate;@Autowiredprivate HealthEndpoint healthEndpoint;@GetMappingpublic Map<String, Object> healthCheck() {Map<String, Object> health = new HashMap<>();// 数据库健康检查try {jdbcTemplate.execute("SELECT 1");health.put("database", "UP");} catch (Exception e) {health.put("database", "DOWN");}// 系统健康检查HealthComponent systemHealth = healthEndpoint.health();health.put("status", systemHealth.getStatus().getCode());health.put("timestamp", System.currentTimeMillis());return health;}
}
第十二部分：最佳实践与总结
12.1 API设计最佳实践
-
使用合适的HTTP状态码
- 200: 成功
- 201: 创建成功
- 400: 客户端错误
- 401: 未授权
- 403: 禁止访问
- 404: 资源不存在
- 500: 服务器错误
-
统一的响应格式
{"success": true,"message": "操作成功","data": {},"timestamp": 1640995200000
}
-
版本控制
- URL路径版本:
/api/v1/users - 请求头版本:
Accept: application/vnd.example.v1+json
- URL路径版本:
-
分页和过滤
GET /api/users?page=0&size=10&sort=createdAt,descGET /api/users?name=john&email=example.com
12.2 性能优化建议
-
数据库优化
- 合理使用索引
- 避免N+1查询问题
- 使用连接查询替代多次查询
-
缓存策略
- 使用Redis进行会话存储
- 缓存热点数据
- 设置合理的缓存过期时间
-
异步处理
- 使用消息队列处理耗时操作
- 异步发送邮件和通知
- 后台任务处理
12.3 安全考虑
-
输入验证
- 使用Bean Validation注解
- 防范SQL注入
- XSS防护
-
认证授权
- 使用JWT进行无状态认证
- 基于角色的访问控制
- API密钥管理
-
其他安全措施
- HTTPS强制使用
- 定期更新依赖
- 安全头部配置
12.4 总结
通过本文的详细讲解，您应该已经掌握了Java后端Web API开发的全流程。从环境搭建、项目架构设计，到具体的编码实现和测试部署，我们覆盖了开发一个完整Web API项目所需的所有关键知识点。
核心要点回顾：
- 采用分层架构，保持代码清晰和可维护性
- 使用Spring Boot快速开发，减少配置工作
- 实现完整的CRUD操作和业务逻辑
- 添加适当的异常处理和日志记录
- 编写全面的测试用例
- 考虑安全性和性能优化
在实际项目开发中，还需要根据具体需求不断调整和优化架构设计，同时关注代码质量、团队协作和持续集成等工程实践。希望本文能为您的Java Web API开发之旅提供有力的帮助！
