TCP netstat TIME_WAIT CLOSE_WAIT

TIME_WAIT is different from CLOSE_WAIT, and it’s not necessarily a client-side fault. It happens due to how TCP handles connection termination.

Key Differences

TCP State	Cause	Who is responsible?	Fix/Optimization
CLOSE_WAIT	Server didn’t close() the socket after client closed it.	Server-side issue (socket left open).	Ensure close(client_fd); is always called.
TIME_WAIT	Server closed the socket first, waiting to ensure the client received the FIN.	Normal behavior (not necessarily a problem).	Use SO_LINGER or SO_REUSEADDR to mitigate excessive TIME_WAIT.

---

Why Does TIME_WAIT Happen?

• When your server calls close(client_fd);, it sends a FIN to the client.
• If the client follows the normal TCP closure process, it replies with ACK and sends its own FIN, which your server then ACKs.
• Your server enters TIME_WAIT for 2×MSL (Maximum Segment Lifetime, usually 60s total) to ensure any delayed packets are handled before fully releasing the connection.

---

Is TIME_WAIT the Client’s Fault?

• If the client closes the connection first, the server goes to CLOSE_WAIT (which we fixed).
• If the server closes first, TIME_WAIT is expected.
• Too many TIME_WAIT sockets? It usually means many short-lived connections are being closed quickly.

---

How to Reduce TIME_WAIT Issues?

1. Enable SO_REUSEADDR

   • Allows immediate reuse of the same port, even in TIME_WAIT state.

   int opt = 1;
   setsockopt(server_fd, SOL_SOCKET, SO_REUSEADDR, &opt, sizeof(opt));


2. Use SO_LINGER to Force Immediate Closure

   • Not recommended unless necessary, as it can cause packet loss.

   struct linger sl;
   sl.l_onoff = 1;  // Enable linger
   sl.l_linger = 2; // Close socket after 2 seconds
   setsockopt(client_fd, SOL_SOCKET, SO_LINGER, &sl, sizeof(sl));


3. Keep Connections Open Longer

   • If possible, reuse connections instead of opening/closing frequently.

4. Tune TCP Stack (sysctl)

   • Reduce TIME_WAIT timeout if necessary:

   sudo sysctl -p | grep net.ipv4.tcp_fin_timeout  # net.ipv4.tcp_fin_timeout = 2
   sysctl -w net.ipv4.tcp_fin_timeout=30


---

Conclusion

• CLOSE_WAIT is a server-side issue (fixed by properly closing sockets).
• TIME_WAIT is expected behavior when the server closes first.
• Too many TIME_WAIT sockets? Use SO_REUSEADDR, linger options, or connection pooling if appropriate.
