📂 前言
AR 眼镜之-蓝牙电话-实现方案
AR 眼镜之-蓝牙电话-实现方案
AR 眼镜系统版本
FreeRTOS。
Android 手机系统版本
Android 15。
1. 🔱 技术方案
1.1 结构框图
1.2 方案介绍
-
主要通过 BLE 定义私有协议，实现手机来电状态监听并推送给 AR 眼镜显示、以及在眼镜上实现接听和挂断电话的功能；
-
与 BT 蓝牙电话不同的是，BLE 只能实现电话显示和控制功能，不能将通话音频传给 AR 眼镜，所以用户如果要接听电话，则需要通过手机扬声器或其他蓝牙耳机进行音频输出。
1.3 实现方案
步骤一：手机 App 申请权限
申请手机来电状态权限 READ_PHONE_STATE、获取手机来电号码权限 READ_CALL_LOG、查询联系人名字权限 READ_CONTACTS、以及接/挂电话权限 ANSWER_PHONE_CALLS；
步骤二：手机来电状态监听并推送给 AR 眼镜
-
手机 App 监听到来电后，查询来电信息，包括：来电的电话号码以及联系人名字；
-
通过 BLE 定义的私有协议，将来电的电话号码以及联系人名字，推送给 AR 眼镜。
步骤三：AR 眼镜显示来电信息并操作挂断/接听
-
RTOS AR 眼镜收到 BLE 私有协议命令后，调起来电 UI 界面，显示来电电话号码和名字；
-
AR 眼镜将用户挂断或接听电话的操作，通过 BLE 命令发给手机 App。
步骤四：手机 App 执行挂断/接听操作
手机 App 收到挂断/接听命令后，调用系统电话的挂断/接听接口。
2. ⚛️ 自定义电话实现
2.1 自定义电话时序图
2.2 实现细节
1、手机 App 申请权限
1）在 Manifest 中申明权限
申请手机来电状态权限 READ_PHONE_STATE、获取手机来电号码权限 READ_CALL_LOG、查询联系人名字权限 READ_CONTACTS、以及接/挂电话权限 ANSWER_PHONE_CALLS。
<!--Phone Call Start--><!--手机来电状态--><uses-permission android:name="android.permission.READ_PHONE_STATE" /><!--获取手机来电号码--><uses-permission android:name="android.permission.READ_CALL_LOG" /><!--查询联系人名字--><uses-permission android:name="android.permission.READ_CONTACTS" /><!--接/挂电话--><uses-permission android:name="android.permission.ANSWER_PHONE_CALLS" /><!--Phone Call End-->2）检查权限
如果权限缺失会发起请求，并在 Activity 的 onRequestPermissionsResult 中调用权限授予结果；否则，直接启动手机来电状态监听。
private const val PERMISSIONS_REQUEST_CODE = 1000private val permissions = arrayOf(Manifest.permission.READ_PHONE_STATE,Manifest.permission.READ_CALL_LOG,Manifest.permission.READ_CONTACTS,Manifest.permission.ANSWER_PHONE_CALLS)private var applicationContext: Context? = null/** 检查权限，如果缺失会发起请求，否则直接启动监听 */fun checkPermissionsAndStart(context: Activity) {applicationContext = context.applicationContextval missingPermissions = permissions.filter {ContextCompat.checkSelfPermission(context, it) != PackageManager.PERMISSION_GRANTED}if (missingPermissions.isNotEmpty()) {ActivityCompat.requestPermissions(context, missingPermissions.toTypedArray(), PERMISSIONS_REQUEST_CODE)} else {startListener(context)}}/** 在 Activity 的 onRequestPermissionsResult 中调用 */fun onRequestPermissionsResult(requestCode: Int, grantResults: IntArray, context: Activity) {if (requestCode == PERMISSIONS_REQUEST_CODE) {if (grantResults.all { it == PackageManager.PERMISSION_GRANTED }) {startListener(context)} else {Toast.makeText(context,"Phone, call log, and call answer permissions are needed.",Toast.LENGTH_LONG).show()}}}2、手机来电状态监听并推送给 AR 眼镜
-
手机 App 监听到来电后，查询来电信息，包括：来电的电话号码以及联系人名字；
-
通过 BLE 定义的私有协议，将来电的电话号码以及联系人名字，推送给 AR 眼镜。
private var telephonyManager: TelephonyManager? = nullprivate val mPhoneListener = object : PhoneStateListener() {override fun onCallStateChanged(state: Int, phoneNumber: String?) {super.onCallStateChanged(state, phoneNumber)when (state) {TelephonyManager.CALL_STATE_IDLE -> {// 在注册监听的时候就会走一次回调，后面通话状态改变时也会走，如：在启动服务时如果手机没有通话相关动作，就会直接走一次TelephonyManager.CALL_STATE_IDLE。Log.i(TAG, "onCallStateChanged: 挂断 $phoneNumber")}TelephonyManager.CALL_STATE_OFFHOOK -> {Log.i(TAG, "onCallStateChanged: 接听 $phoneNumber")}TelephonyManager.CALL_STATE_RINGING -> {Log.i(TAG, "onCallStateChanged: 响铃 $phoneNumber")Log.e(TAG, "${getIncomingCallInfo(applicationContext?.contentResolver)}")}}}}/** 启动电话状态监听 */private fun startListener(context: Context) {Log.i(TAG, "startListener: ")telephonyManager =context.applicationContext.getSystemService(Context.TELEPHONY_SERVICE) as TelephonyManagertelephonyManager?.listen(mPhoneListener, PhoneStateListener.LISTEN_CALL_STATE)}/** 停止监听 */fun stopListener() {Log.i(TAG, "stopListener: ")telephonyManager?.listen(mPhoneListener, PhoneStateListener.LISTEN_NONE)}3、查询最近来电信息
data class CallInfo(val number: String, val name: String = "")private fun getIncomingCallInfo(contentResolver: ContentResolver?): CallInfo? {var phoneNumber: String? = nullvar contactName = ""var cursor: Cursor? = nullvar nameCursor: Cursor? = nulltry {if (contentResolver != null) {// 查询最近一次来电号码cursor = contentResolver.query(CallLog.Calls.CONTENT_URI,arrayOf(CallLog.Calls.NUMBER),"${CallLog.Calls.TYPE} = ${CallLog.Calls.INCOMING_TYPE}",null,"${CallLog.Calls.DATE} DESC")cursor?.use {if (it.moveToFirst()) {phoneNumber = it.getString(it.getColumnIndexOrThrow(CallLog.Calls.NUMBER))}}// 查询联系人名字if (!phoneNumber.isNullOrEmpty()) {val uri: Uri = Uri.withAppendedPath(ContactsContract.PhoneLookup.CONTENT_FILTER_URI, Uri.encode(phoneNumber))nameCursor = contentResolver.query(uri, arrayOf(ContactsContract.PhoneLookup.DISPLAY_NAME), null, null, null)nameCursor?.use {if (it.moveToFirst()) {contactName =it.getString(it.getColumnIndexOrThrow(ContactsContract.PhoneLookup.DISPLAY_NAME))}}}}} catch (e: Exception) {e.printStackTrace()} finally {cursor?.close()nameCursor?.close()}return phoneNumber?.let { CallInfo(it, contactName) }}4、手机 App 执行挂断/接听操作
手机 App 收到挂断/接听命令后，调用系统电话的挂断/接听接口。
1）接听电话
/** 接听电话，内部自动检查权限 */fun answerCall(context: Context) {Log.i(TAG, "answerCall: ")if (ContextCompat.checkSelfPermission(context, Manifest.permission.ANSWER_PHONE_CALLS) == PackageManager.PERMISSION_GRANTED) {try {(context.getSystemService(Context.TELECOM_SERVICE) as TelecomManager).acceptRingingCall()} catch (e: Exception) {Log.e(TAG, "answerCall: 接听电话失败: ${e.message}")}} else {Log.e(TAG, "answerCall: 缺少 ANSWER_PHONE_CALLS 权限，无法接听!")}}2）挂断电话
/** 挂断电话，内部自动检查权限 */fun endCall(context: Context): Boolean {Log.i(TAG, "endCall: ")var callSuccess = falsetry {if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.P) {if (ActivityCompat.checkSelfPermission(context, Manifest.permission.ANSWER_PHONE_CALLS) == PackageManager.PERMISSION_GRANTED) {(context.getSystemService(Context.TELECOM_SERVICE) as TelecomManager).endCall()callSuccess = true} else {Log.e(TAG, "endCall: 缺少 ANSWER_PHONE_CALLS 权限，无法挂断!")}} else {val tm = context.getSystemService(Context.TELEPHONY_SERVICE) as TelephonyManagerval m: Method = Class.forName(tm.javaClass.name).getDeclaredMethod("getITelephony")m.isAccessible = trueval telephonyService: ITelephony = m.invoke(tm) as ITelephonycallSuccess = telephonyService.endCall()Log.i(TAG, "endCall: 挂断电话成功 (低版本)!")}} catch (e: Exception) {Log.e(TAG, "endCall: ${e.printStackTrace()}")callSuccess = disconnectCall()e.printStackTrace()}return callSuccess}/** 挂断兜底方法，通过输入 keyevent */private fun disconnectCall(): Boolean {return try {Log.i(TAG, "disconnectCall: input keyevent " + KeyEvent.KEYCODE_ENDCALL)Runtime.getRuntime().exec("input keyevent " + KeyEvent.KEYCODE_ENDCALL.toString())true} catch (e: Exception) {Log.e(TAG, "disconnectCall: ${e.printStackTrace()}")false}}5、API 监听电话状态调用
override fun onCreate(savedInstanceState: Bundle?) {super.onCreate(savedInstanceState)// 启动电话监听（会自动检查权限）TelephonyManagerHelper.checkPermissionsAndStart(this)
}override fun onDestroy() {super.onDestroy()// 停止电话监听，释放资源TelephonyManagerHelper.stopListener()
}// 示例：来电时接听
fun answerIncomingCall() {TelephonyManagerHelper.answerCall(this)
}// 示例：挂断电话
fun hangupCall() {TelephonyManagerHelper.endCall(this)
}3. 💠 来电实现帮助类 TelephonyManagerHelper
object TelephonyManagerHelper {data class CallInfo(val number: String, val name: String = "")private val TAG = TelephonyManagerHelper::class.java.simpleNameprivate const val PERMISSIONS_REQUEST_CODE = 1000private val permissions = arrayOf(Manifest.permission.READ_PHONE_STATE,Manifest.permission.READ_CALL_LOG,Manifest.permission.READ_CONTACTS,Manifest.permission.ANSWER_PHONE_CALLS)private var applicationContext: Context? = nullprivate var telephonyManager: TelephonyManager? = nullprivate val mPhoneListener = object : PhoneStateListener() {override fun onCallStateChanged(state: Int, phoneNumber: String?) {super.onCallStateChanged(state, phoneNumber)when (state) {TelephonyManager.CALL_STATE_IDLE -> {// 在注册监听的时候就会走一次回调，后面通话状态改变时也会走，如：在启动服务时如果手机没有通话相关动作，就会直接走一次TelephonyManager.CALL_STATE_IDLE。Log.i(TAG, "onCallStateChanged: 挂断 $phoneNumber")}TelephonyManager.CALL_STATE_OFFHOOK -> {Log.i(TAG, "onCallStateChanged: 接听 $phoneNumber")}TelephonyManager.CALL_STATE_RINGING -> {Log.i(TAG, "onCallStateChanged: 响铃 $phoneNumber")Log.e(TAG, "${getIncomingCallInfo(applicationContext?.contentResolver)}")}}}}/** 检查权限，如果缺失会发起请求，否则直接启动监听 */fun checkPermissionsAndStart(context: Activity) {applicationContext = context.applicationContextval missingPermissions = permissions.filter {ContextCompat.checkSelfPermission(context, it) != PackageManager.PERMISSION_GRANTED}if (missingPermissions.isNotEmpty()) {ActivityCompat.requestPermissions(context, missingPermissions.toTypedArray(), PERMISSIONS_REQUEST_CODE)} else {startListener(context)}}/** 在 Activity 的 onRequestPermissionsResult 中调用 */fun onRequestPermissionsResult(requestCode: Int, grantResults: IntArray, context: Activity) {if (requestCode == PERMISSIONS_REQUEST_CODE) {if (grantResults.all { it == PackageManager.PERMISSION_GRANTED }) {startListener(context)} else {Toast.makeText(context,"Phone, call log, and call answer permissions are needed.",Toast.LENGTH_LONG).show()}}}/** 启动电话状态监听 */private fun startListener(context: Context) {Log.i(TAG, "startListener: ")telephonyManager =context.applicationContext.getSystemService(Context.TELEPHONY_SERVICE) as TelephonyManagertelephonyManager?.listen(mPhoneListener, PhoneStateListener.LISTEN_CALL_STATE)}/** 停止监听 */fun stopListener() {Log.i(TAG, "stopListener: ")telephonyManager?.listen(mPhoneListener, PhoneStateListener.LISTEN_NONE)}/** 接听电话，内部自动检查权限 */fun answerCall(context: Context) {Log.i(TAG, "answerCall: ")if (ContextCompat.checkSelfPermission(context, Manifest.permission.ANSWER_PHONE_CALLS) == PackageManager.PERMISSION_GRANTED) {try {(context.getSystemService(Context.TELECOM_SERVICE) as TelecomManager).acceptRingingCall()} catch (e: Exception) {Log.e(TAG, "answerCall: 接听电话失败: ${e.message}")}} else {Log.e(TAG, "answerCall: 缺少 ANSWER_PHONE_CALLS 权限，无法接听!")}}/** 挂断电话，内部自动检查权限 */fun endCall(context: Context): Boolean {Log.i(TAG, "endCall: ")var callSuccess = falsetry {if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.P) {if (ActivityCompat.checkSelfPermission(context, Manifest.permission.ANSWER_PHONE_CALLS) == PackageManager.PERMISSION_GRANTED) {(context.getSystemService(Context.TELECOM_SERVICE) as TelecomManager).endCall()callSuccess = true} else {Log.e(TAG, "endCall: 缺少 ANSWER_PHONE_CALLS 权限，无法挂断!")}} else {val tm = context.getSystemService(Context.TELEPHONY_SERVICE) as TelephonyManagerval m: Method = Class.forName(tm.javaClass.name).getDeclaredMethod("getITelephony")m.isAccessible = trueval telephonyService: ITelephony = m.invoke(tm) as ITelephonycallSuccess = telephonyService.endCall()Log.i(TAG, "endCall: 挂断电话成功 (低版本)!")}} catch (e: Exception) {Log.e(TAG, "endCall: ${e.printStackTrace()}")callSuccess = disconnectCall()e.printStackTrace()}return callSuccess}/** 挂断兜底方法，通过输入 keyevent */private fun disconnectCall(): Boolean {return try {Log.i(TAG, "disconnectCall: input keyevent " + KeyEvent.KEYCODE_ENDCALL)Runtime.getRuntime().exec("input keyevent " + KeyEvent.KEYCODE_ENDCALL.toString())true} catch (e: Exception) {Log.e(TAG, "disconnectCall: ${e.printStackTrace()}")false}}/** 查询最近来电信息 */private fun getIncomingCallInfo(contentResolver: ContentResolver?): CallInfo? {var phoneNumber: String? = nullvar contactName = ""var cursor: Cursor? = nullvar nameCursor: Cursor? = nulltry {if (contentResolver != null) {// 查询最近一次来电号码cursor = contentResolver.query(CallLog.Calls.CONTENT_URI,arrayOf(CallLog.Calls.NUMBER),"${CallLog.Calls.TYPE} = ${CallLog.Calls.INCOMING_TYPE}",null,"${CallLog.Calls.DATE} DESC")cursor?.use {if (it.moveToFirst()) {phoneNumber = it.getString(it.getColumnIndexOrThrow(CallLog.Calls.NUMBER))}}// 查询联系人名字if (!phoneNumber.isNullOrEmpty()) {val uri: Uri = Uri.withAppendedPath(ContactsContract.PhoneLookup.CONTENT_FILTER_URI, Uri.encode(phoneNumber))nameCursor = contentResolver.query(uri, arrayOf(ContactsContract.PhoneLookup.DISPLAY_NAME), null, null, null)nameCursor?.use {if (it.moveToFirst()) {contactName =it.getString(it.getColumnIndexOrThrow(ContactsContract.PhoneLookup.DISPLAY_NAME))}}}}} catch (e: Exception) {e.printStackTrace()} finally {cursor?.close()nameCursor?.close()}return phoneNumber?.let { CallInfo(it, contactName) }}}4. ✅ 小结
对于手机来电显示以及接听/挂断这块，本文只是一个基础实现方案，更多业务细节请参考产品逻辑去实现。
另外，由于本人能力有限，如有错误，敬请批评指正，谢谢。
