EXCEL(带图)转html【uni版】

一、前言

之前写过一个 bootstrap 版本的，但这次实现在APP上，就只有重写前端，后端也得变一变。
思路 用tab-bar 实现sheet的切换，兼容图片显示。
难点是 uni-table的后置渲染在v-html里并不上很顺利。

二、后端(.net8)


三、前端(uniapp)

<template><view class="tabs"><scroll-view id="tab-bar" class="scroll-h" :scroll-x="true" :show-scrollbar="false":scroll-into-view="scrollInto"><view v-for="(tab,index) in tabBars" :key="index" class="uni-tab-item" :id="index-1" :data-current="index"@click="ontabtap"><text class="uni-tab-item-title":class="tabIndex==index ? 'uni-tab-item-title-active' : ''">{{tab}}</text></view></scroll-view><view class="line-h"></view><view  class="swiper-box" ><view class="swiper-item " v-for="(tab,index1) in contents" :key="index1"><scroll-view  class="uni-container" :scroll-x="true"  :scroll-Y="true" v-show="index1==tabIndex" ><view v-html="tab"  class="uni-table" ></view> <!-- 动态渲染内容 --> </scroll-view></view></view></view>
</template>
</script><style lang="scss" scoped>/* #ifndef APP-PLUS */page {width: 100%;min-height: 100%;display: flex;}/* #endif */.tabs {flex: 1;flex-direction: column;overflow: hidden;background-color: #ffffff;/* #ifndef APP-PLUS */height: 100vh;/* #endif */}.scroll-h {// width: 750rpx;width: 100%;height: 80rpx;flex-direction: row;white-space: nowrap;/* flex-wrap: nowrap; *//* border-color: #cccccc;border-bottom-style: solid;border-bottom-width: 1px; */}.line-h {height: 1rpx;background-color: #cccccc;}.uni-tab-item {display: inline-block;flex-wrap: nowrap;padding-left: 34rpx;padding-right: 34rpx;}.uni-tab-item-title {color: #555;font-size: 30rpx;height: 80rpx;line-height: 80rpx;flex-wrap: nowrap;/* #ifndef APP-PLUS */white-space: nowrap;/* #endif */}.uni-tab-item-title-active {color: #007AFF;}.swiper-box {flex: 1;}uni-swiper{height: 550px !important;}.uni-container{height: 550px !important;}/* .swiper-item {flex: 1;flex-direction: row;} */.scroll-v {flex: 1;/* #ifndef MP-ALIPAY */flex-direction: column;/* #endif */width: 750rpx;width: 100%;}/* 手动添加 uni-table 样式 */
::v-deep  .uni-table table {width: 200%;border: 1px solid #d7d9df ;border-collapse: collapse;
}
.uni-table th,
::v-deep  .uni-table td {border: 0px ;border-left: 1px solid #d7d9df ;border-bottom: 1px solid #d7d9df ;padding: 8px;
}</style>
