JMETER+ANT接口自动化测试环境搭建实战讲解

news 2025/10/23 9:22:43

宝子们，时隔四年多，我再次执笔为文。

今天我们来讲解JMeter与Ant的环境搭建，重点介绍Ant的相关内容。考虑到大家应该已经熟悉JMeter的使用，这里就不再赘述，我会着重讲解Ant与JMeter的整合部分。下面正式开始今天的讲解内容：

1、下载并配置ant

下载地址：https://ant.apache.org/bindownload.cgi#Verify%20Releases

我是Windows的电脑，所以下载如下图所示zip包

2、解压下载的ant包，我放到了与jmeter同级的目录下

3、配置环境变量

①ANT_HOME（系统变量），写自己实际的路径

②CLASSPATH，添加%ANT_HOME%\lib;

③PATH，添加%ANT_HOME%\bin;

④打开CMD，输入ant -version，出现以下内容说明配置成功

4、拷贝jmeter/extras目录下的ant-jmeter-1.1.1.jar到ant安装路径lib下

5、配置ant的编译文件build.xml

我放在了jmeter下的ant_demo（自己新建的）目录下，可以根据自己的要求新建一个文件夹

build.xml内容如下所示（其中涉及到路径的地方自行修改成实际的路径，否则报错）：

<?xml version="1.0" encoding="UTF-8"?>
<project name="ant-jmeter-test" default="run" basedir="."><property environment="env"/><tstamp><format property="time" pattern="yyyy_MM_dd_hh_mm" />
</tstamp><!--需要调用的jmeter目录，根据需要进行修改，本次使用的Windows路径--><property name="jmeter.home" value="D:\Program Files\apache-jmeter-5.6.3" /><property name="report.title" value="接口性能测试"/><!-- jmeter生成jtl格式的结果报告的路径--><property name="jmeter.result.jtl.dir" value="D:\Program Files\apache-jmeter-5.6.3\ant_demo\jtl" /><!-- jmeter生成html格式的结果报告的路径--><property name="jmeter.result.html.dir" value="D:\Program Files\apache-jmeter-5.6.3\ant_demo\html" /><!-- 【详细报告】jmeter生成html格式的详细报告的路径--><property name="jmeter.result.html.dir1" value="report" /><!--生成的报告的前缀--><property name="ReportName" value="接口测试汇总报告" /><property name="ReportName1" value="接口测试详细报告" /><property name="jmeter.result.jtlName" value="${jmeter.result.jtl.dir}/${ReportName}.jtl" /><property name="jmeter.result.htmlName" value="${jmeter.result.html.dir}/${ReportName}.html" /><!-- 【详细报告】详细报告的文件名--><property name="jmeter.result.htmlName1" value="${jmeter.result.html.dir1}/${ReportName1}.html" /><target name="run" ><!--antcall target-"delete" /--><antcall target="test" /><antcall target="report" /></target><target name="test"><taskdef name="jmeter" classname="org.programmerplanet.ant.taskdefs.jmeter.JMeterTask" /><jmeter jmeterhome="${jmeter.home}" resultlog="${jmeter.result.jtlName}"><!-- 声明要运行的脚本路径"*.jmx"指包含此目录下的所有jmeter脚本--><testplans dir="D:\Program Files\apache-jmeter-5.6.3\ant_demo" includes="*.jmx" /><property name="jmeter.save.saveservice.output_format" value="xml"/></jmeter></target><path id="xslt.classpath"><fileset dir="${jmeter.home}/lib" includes="xalan*.jar"/><fileset dir="${jmeter.home}/lib" includes="serializer*.jar"/></path><!--该命令为生成汇总和详细报告--><target name="report"><tstamp><format property="report.datestamp" pattern="yyy/MM/dd HH:mm" /></tstamp><xsltclasspathref="xslt.classpath"force="true"in="${jmeter.result.jtlName}"out="${jmeter.result.htmlName}"style="${jmeter.home}/extras/jmeter-results-report_21.xsl"><param name="dateReport" expression="${report.datestamp}"/></xslt><!--【详细报告】指定详细报告模板文件--><xslt 			classpathref="xslt.classpath"force="true"in="${jmeter.result.jtlName}"out="${jmeter.result.htmlName1}"style="${jmeter.home}/extras/jmeter.results.shanhe.me.xsl"><param name="dateReport" expression="$report.datestamp"/></xslt><!--因为上面生成报告的时候，不会将相关的图片也一起拷贝至日标目录，所以，需要手动拷贝--><copy todir="${jmeter.result.html.dir}"><fileset dir="${jmeter.home}/extras"><include name="collapse.png" /><include name="expand.png" /></fileset></copy><!-- 【详细报告】拷贝图片到目标日录--><copy todir="${jmeter.result.html.dir1}"><fileset dir="${jmeter.home}/extras"><include name="collapse.png" /><include name="expand.png" /></fileset></copy></target>
</project>

6、配置jmeter的全局配置文件bin/jmeter.properties，以下三处找到放开对应修改即可：

①jmeter.save.saveservice.output_format=xml

②jmeter.save.saveservice.response_data=true

③jmeter.save.saveservice.samplerData=true

7、添加配置文件jmeter.results.shanhe.me.xsl到extras目录下，该文件为报告提供模板，如果你的jmeter跟我一样没有这个文件（jmeter/extras下检查下有没有），那么可以新建一个文件，名字就是上边的

这个xsl文件的内容如下：

<?xml version="1.0" encoding="UTF-8"?>
</xsl:stylesheet>

8、完成以上操作后，咱们打开命令行，进入到上边提到的ant_demo目录下，运行ant -f build.xml

如下图所示表示配置成功（当然你的内容可能与我截图的有所区别，原因是咱们的主角jmx文件还没登场，别急，继续往下看）：
