k8s--Discuz论坛lnmp平台部署

news 2025/8/21 8:00:45

Deployment和Service删除

🗑️ 完整删除步骤

1. 删除 Deployment（会同时删除 Pod）

kubectl delete deployment nginx -n default

这会删除名为 nginx 的 Deployment
Deployment 管理的所有 Pod 也会被自动删除

2. 删除 Service

kubectl delete service nginx-svc-nodeport -n default

这会删除 NodePort 类型的 Service

3. 验证删除结果

# 检查 Deployment
kubectl get deployments -n default

# 检查 Pod
kubectl get pods -n default

# 检查 Service
kubectl get services -n default

所有相关资源应显示 "No resources found"

#默认命名空间是 default
#查看deployment
[root@k8s-master ~]# kubectl get deployments.apps
NAME    READY   UP-TO-DATE   AVAILABLE   AGE
nginx   2/2     2            2           116s
#删除名为nginx的deployment（会同时删除 Pod）（因为是在default空间里，所以-n指向default命名空间删除名为nginx的deployment）
[root@k8s-master ~]# kubectl delete deployment nginx -n default
deployment.apps "nginx" deleted
#删除 Service
#这会删除 NodePort 类型的 Service
[root@k8s-master ~]# kubectl delete service nginx-svc-nodeport -n default

部署Discuz

#部署Discuz
[root@k8s-master ~]# ls
anaconda-ks.cfg                     lnmp.tar
#复制一份给从节点34
[root@k8s-master ~]# scp /root/lnmp.tar root@192.168.158.34:/root/Authorized users only. All activities may be monitored and reported.
lnmp.tar                                                               100%  624MB 226.6MB/s   00:02
#复制一份给从节点35
[root@k8s-master ~]# scp /root/lnmp.tar root@192.168.158.35:/root/Authorized users only. All activities may be monitored and reported.
lnmp.tar                                                                 0%    0     0.0KB/s   --:-- ETA^lnmp.tar                                                               100%  624MB 243.9MB/s   00:02
#从tar文档中加载镜像
[root@k8s-master ~]# docker load -i lnmp.tar
418dccb7d85a: Loading layer  8.596MB/8.596MB
4c1eede456c7: Loading layer    269MB/269MB
96d171dad28b: Loading layer  8.192kB/8.192kB
85db2e8d5fe7: Loading layer  3.584kB/3.584kB
3faa67a4599d: Loading layer  4.096kB/4.096kB
af6a339017a4: Loading layer  3.072kB/3.072kB
57bd1c48fa9b: Loading layer  3.584kB/3.584kB
8ff6aada8914: Loading layer  3.072kB/3.072kB
2320e8c251b4: Loading layer  149.5MB/149.5MB
e035f427eac8: Loading layer  2.048kB/2.048kB
e6b477eb3187: Loading layer  3.072kB/3.072kB
ebc3cf110417: Loading layer  4.608kB/4.608kB
43746c7407c2: Loading layer  227.4MB/227.4MB
Loaded image: lnmp:1
[root@k8s-master ~]# docker images
REPOSITORY                                                        TAG        IMAGE ID       CREATED                  SIZE
lnmp                                                              1          c80af76648ee   Less than a second ago   649MB

编辑deployment文件

#编辑deployment文件
[root@k8s-master ~]# vim nginx-pod-liveness-http.yaml
apiVersion: apps/v1
kind: Deployment
metadata:labels:app: nginxname: nginxnamespace: default
spec:replicas: 1selector:matchLabels:app: nginxtemplate:metadata:labels:app: nginxspec:containers:- name: nginximage: lnmp:1imagePullPolicy: IfNotPresentports:- containerPort: 80livenessProbe:             #指定探针httpGet:                  #指定探针方式path: /info.php       port: 80                initialDelaySeconds: 5periodSeconds: 5initialDelaySeconds: 15
---
apiVersion: v1
kind: Service
metadata:labels:svc: nginx-svc-nodeportname: nginx-svc-nodeport
spec:type: NodePortports:- port: 80targetPort: 80nodePort: 30080selector:app: nginx

提交pod文件

#提交pod文件
[root@k8s-master ~]# kubectl apply -f nginx-pod-liveness-http.yaml
deployment.apps/nginx created
service/nginx-svc-nodeport created
#查看pod资源
[root@k8s-master ~]# kubectl get pod
NAME                    READY   STATUS    RESTARTS   AGE
nginx-89f8c6894-jdx6b   1/1     Running   0          90m
#查看deployment
[root@k8s-master ~]# kubectl get deployments.apps
NAME    READY   UP-TO-DATE   AVAILABLE   AGE
nginx   1/1     1            1           91m
#查看service
[root@k8s-master ~]# kubectl get service
NAME                 TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)        AGE
kubernetes           ClusterIP   10.96.0.1        <none>        443/TCP        45h
nginx-svc-nodeport   NodePort    10.105.189.102   <none>        80:30080/TCP   92m
#就可以了

查看pod详细信息

#查看pod详细信息
#查看 default 命名空间中名为 m 的Pod的详细信息
[root@k8s-master ~]# kubectl describe pod nginx-89f8c6894-jdx6b -n default

查看验证

#查看
[root@k8s-master ~]# kubectl exec -it nginx-89f8c6894-jdx6b -- ls /var/www/html
discuz      index.html  info.php    mysql.php
[root@k8s-master ~]# curl 192.168.158.33:30080/index.html
nginx
[root@k8s-master ~]# curl 192.168.158.33:30080/info.php
<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "DTD/xhtml1-transitional.dtd">
<html xmlns="http://www.w3.org/1999/xhtml"><head>
<style type="text/css">
[root@k8s-master ~]# curl 192.168.158.33:30080/mysql.php
MySQL 连接成功！[root@k8s-master ~]#
