内存泄漏系列专题分析之二十：camx swap内存泄漏实例分析

news 来源：原创 2025/6/15 7:58:45

【关注我，后续持续新增专题博文，谢谢！！！】

上一篇我们讲了：内存泄漏系列专题分析之十九: 开机内存占用超标分析一：cameraserver超标1.8M分析

        这一篇我们开始讲： 内存泄漏系列专题分析之二十：swap内存泄漏实例分析

目录

一、背景

二、：swap内存泄漏思路

    2.1：首先确认camx hal进程内存占用是否正常

    2.2 ：首先需确认camx hal进程内存占用是否正常？是否泄漏？

    2.3 ：基于原理来分析swap内存泄漏

    2.4 ：分析低内存下kernel dump进程内存分布

    2.5 ：导出Camx HAL进程的内存细化情况

    2.6 ：此时，12小时之前不增长，后面swap异常增长变得难以理解了

    2.7 ：继续压测monkey正式版本，无法复现

    2.8 ：基于测试情况对老化版本的猜测

    2.9 ：使用老化版本高负载下压测，果然复现

    2.10 ：基于上面swap原理分析，我们开始复现并分析内存泄漏

    2.11 ：分析Camx HAL fdnode代码

    2.12 ：加日志debug

    2.13 ：解决问题

    2.14 ：总结

一、背景

        之前一个项目出现老化过程中，出现相机等各种app ANR爆了。分析发现camx hal进程swap内存持续增长到4.5G，很明显的内存泄漏。而swap内存并没有用户态分配内存接口，它由kernel内核控制，导致内存泄漏分析思路完全颠覆了，常规直接切入swap内存分配无法进行，此时该如何分析呢？

二、：swap内存泄漏思路

    2.1：首先确认camx hal进程内存占用是否正常

1：我们在这份日志里找到 (4,544,364K in swap)，即camx hal进程swap内存已经达到4.5G，而此时相机是退出状态，也说明了这个swap内存并没有释放，即使相机关闭状态，也一直驻留在PSS里。

1739472003612@1739472703954@2025_02_14_02_52_53@SystemLog.zip    4,597,384K: vendor.qti.camera.provider@2.7-service_64 (pid 1634)        (4,544,364K in swap)

    2.2 ：首先需确认camx hal进程内存占用是否正常？是否泄漏？

        我们下载老化单台机器所有日志进一步确认是否持续增长，结果下载老化几天的日志，dump出camx hal进程内存不同时间段的情况。

        可以发现老化压测几天几夜的过程中，单台机器的Camx HAL进程swap内存一直是持续增长过程，无论相机是否打开，swap内存就一直没有降低或释放过，因此我们断定swap内存泄漏了。

单台机器的详细日志：相机camx hal进程内存增长情况：
1739266999645@1739326404235@2025_02_12_10_28_48@SystemLog.zip    198,013K: vendor.qti.camera.provider@2.7-service_64 (pid 1634)        (  145,308K in swap)
1739327328830@1739341135895@2025_02_12_14_41_18@SystemLog.zip    894,815K: vendor.qti.camera.provider@2.7-service_64 (pid 1634)        (  841,472K in swap)
1739341385357@1739357045550@2025_02_12_18_45_45@SystemLog.zip    1,501,088K: vendor.qti.camera.provider@2.7-service_64 (pid 1634)        (1,447,940K in swap)
1739368747545@1739369513656@2025_02_12_22_13_35@SystemLog.zip    2,253,697K: vendor.qti.camera.provider@2.7-service_64 (pid 1634)        (2,200,436K in swap)
1739391291701@1739392395773@2025_02_13_04_34_54@SystemLog.zip    3,112,163K: vendor.qti.camera.provider@2.7-service_64 (pid 1634)        (3,059,024K in swap)
1739472003612@1739472703954@2025_02_14_02_52_53@SystemLog.zip    4,597,384K: vendor.qti.camera.provider@2.7-service_64 (pid 1634)        (4,544,364K in swap)

    2.3 ：基于原理来分析swap内存泄漏

        这时需要理解swap内存的定义是什么？是否真的内存泄漏了？swap内存的来源是什么？
        swap主要是在内存不够用的时候，将部分内存上的数据交换到swap空间上，以便让系统不会因为内存不够用而导致oom或者更致命的情况出现。当内存使用存在压力的时候，开始触发内存回收行为，就可能会使用swap空间。Swap 把这些不常访问的内存先写到磁盘中，然后释放这些内存，给其他更需要的进程使用。再次访问这些内存时，重新从磁盘读入内存就可以了

        swap内存主要是压缩不活跃的内存，如果内存泄漏了，swap的来源肯定也是持续增长趋势。通常情况下，swap不会去压缩ION内存，更多是压缩malloc分配的ANON等匿名页，也就是进程通过malloc/mmap使用的内存部分。于是我们需要细化观察进程各个内存变化过程。

    2.4 ：分析低内存下kernel dump进程内存分布

通常如下：（内存理论知识，后续补充发布）
======= dump_procs
comm             32   uid s f   pid  ppid   oom       vss    anon    file   shmem    swap
vendor.qti.came   0  1047 S    1634     1 -1000   2276752   56001   27834     181  463869
======= dump_procs_dmabuf_info
comm             pid   size
vendor.qti.came   1634 249424

    2.5 ：导出Camx HAL进程的内存细化情况

        我们写个脚本导出所有老化过程中这个进程的内存细化情况，如下：
        梳理swap的过程数据，发现swap后期恶化了，过程数据可以说明和相机无关。压测14小时相机swap稳定在150~200M左右，没有增长。大概02-12 08点之后长时间（几个小时）低内存状态，但这个低内存不是相机导致的。swap恶化时间段，相机是没运行的，很可能是长时间低内存导致不断恶化。

        日志详解：

{"HAL_Memory":{"pid":"1634","pss":"106200","swapPss":"272728","total":"378928"}}

表示Camx HAL进程的pid是1634，pss是106M，swap内存272M，合计378M。

kernel_log_20250212_074848.txt:02-12 09:15:23.704673    vendor.qti.came   0  1047 S    1634     1 -1000   1771517   89069   30060     510   79668   //356M 318M

表示AON内存是89069，size是89069 * 4 = 356M，swap内存是79668，size是79668 * 4 = 318M（这里的单位是page，即4K，所以要乘以4）

android_log_20250211_181654.txt:02-11 18:17:58.134540  2419  2704 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"107716","swapPss":"140076","total":"247792"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:13.836740  2419  2419 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"452426","swapPss":"271648","total":"724074"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:15.554367  2419 14677 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"111951","swapPss":"271468","total":"383419"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:18.157295  2419 14677 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"106260","swapPss":"274080","total":"380340"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:19.174628  2419 16408 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"433823","swapPss":"273476","total":"707299"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:19.519812  2419 16408 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"476763","swapPss":"273424","total":"750187"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:20.854754  2419 14677 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"105258","swapPss":"273416","total":"378674"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:25.353172  2419 16408 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"106388","swapPss":"273416","total":"379804"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:26.068137  2419 14677 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"459636","swapPss":"272712","total":"732348"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:26.154126  2419 14677 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"486884","swapPss":"272712","total":"759596"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:27.256947  2419 14677 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"493341","swapPss":"273156","total":"766497"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:28.080545  2419 14677 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"530484","swapPss":"272756","total":"803240"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:28.599953  2419 16408 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"225294","swapPss":"272752","total":"498046"}}, len: 80
android_log_20250212_090446.txt:02-12 09:05:29.195314  2419  2419 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"106200","swapPss":"272728","total":"378928"}}, len: 80kernel_log_20250212_074848.txt:02-12 09:15:23.704673    vendor.qti.came   0  1047 S    1634     1 -1000   1771517   89069   30060     510   79668   //356M 318M
kernel_log_20250212_074848.txt:02-12 09:15:23.719473    vendor.qti.came   1634 534520
kernel_log_20250212_074848.txt:02-12 09:15:23.732906    vendor.qti.came   1634 2056
kernel_log_20250212_074848.txt:02-12 09:15:23.779898    vendor.qti.came  1634  57436
kernel_log_20250212_074848.txt:02-12 09:22:26.605359    vendor.qti.came   0  1047 S    1634     1 -1000   1787105   89807   32791     486   90479	//350M 361M
kernel_log_20250212_074848.txt:02-12 09:22:26.641372    vendor.qti.came   1634 543048
kernel_log_20250212_074848.txt:02-12 09:22:26.676573    vendor.qti.came   1634 2056
kernel_log_20250212_074848.txt:02-12 09:22:26.713047    vendor.qti.came  1634  37016
kernel_log_20250212_074848.txt:02-12 09:23:22.603924    vendor.qti.came   0  1047 S    1634     1 -1000   1696732   87060   26704     460   90752
kernel_log_20250212_074848.txt:02-12 09:23:22.607066    vendor.qti.came   1634 374220
kernel_log_20250212_074848.txt:02-12 09:23:22.613789    vendor.qti.came   1634 2056
kernel_log_20250212_074848.txt:02-12 09:23:22.625893    vendor.qti.came  1634  21600
kernel_log_20250212_074848.txt:02-12 09:27:39.210729    vendor.qti.came   0  1047 S    1634     1 -1000   1785854   88981   31053     486   90044
kernel_log_20250212_074848.txt:02-12 09:27:39.221070    vendor.qti.came   1634 545020
kernel_log_20250212_074848.txt:02-12 09:27:39.238331    vendor.qti.came   1634 2056
kernel_log_20250212_074848.txt:02-12 09:27:39.251598    vendor.qti.came  1634  57436
kernel_log_20250212_074848.txt:02-12 09:27:49.209565    vendor.qti.came   0  1047 R    1634     1 -1000   1970717   58090   28009     695  135891   //232M 543M
kernel_log_20250212_074848.txt:02-12 09:27:49.219898    vendor.qti.came   1634 1209240
kernel_log_20250212_074848.txt:02-12 09:27:49.231472    vendor.qti.came   1634 2056
kernel_log_20250212_074848.txt:02-12 09:27:49.235120    vendor.qti.came  1634  57436
kernel_log_20250212_074848.txt:02-12 09:28:46.534259    vendor.qti.came   0  1047 S    1634     1 -1000   1799432   89018   34058     466   90156
kernel_log_20250212_074848.txt:02-12 09:28:46.550716    vendor.qti.came   1634 477708
kernel_log_20250212_074848.txt:02-12 09:28:46.604629    vendor.qti.came   1634 2056
kernel_log_20250212_074848.txt:02-12 09:28:46.613610    vendor.qti.came  1634  57436
kernel_log_20250212_074848.txt:02-12 09:30:23.664100    vendor.qti.came   0  1047 S    1634     1 -1000   1740557   87743   30190     464   90309
kernel_log_20250212_074848.txt:02-12 09:30:23.668068    vendor.qti.came   1634 463936
kernel_log_20250212_074848.txt:02-12 09:30:23.671577    vendor.qti.came   1634 2056
kernel_log_20250212_074848.txt:02-12 09:30:23.687504    vendor.qti.came  1634  33752
kernel_log_20250212_074848.txt:02-12 09:30:38.004229    vendor.qti.came   0  1047 S    1634     1 -1000   1776584   88696   30085     469   90435
kernel_log_20250212_074848.txt:02-12 09:30:38.008920    vendor.qti.came   1634 488416
kernel_log_20250212_074848.txt:02-12 09:30:38.012524    vendor.qti.came   1634 2056
kernel_log_20250212_074848.txt:02-12 09:30:38.014416    vendor.qti.came  1634  10756
kernel_log_20250212_074848.txt:02-12 09:31:30.068130    vendor.qti.came   0  1047 S    1634     1 -1000   1799189   88731   32692     469   90584
kernel_log_20250212_074848.txt:02-12 09:31:30.073191    vendor.qti.came   1634 528200
kernel_log_20250212_074848.txt:02-12 09:31:30.078858    vendor.qti.came   1634 2056
kernel_log_20250212_074848.txt:02-12 09:31:30.081252    vendor.qti.came  1634  47524
kernel_log_20250212_093326.txt:02-12 09:34:15.483537    vendor.qti.came   0  1047 R    1634     1 -1000   1696184   61990   29558     443   90922  //247m, 363M
kernel_log_20250212_093326.txt:02-12 09:34:15.518644    vendor.qti.came   1634 259644
kernel_log_20250212_093326.txt:02-12 09:34:15.569083    vendor.qti.came   1634 2056
kernel_log_20250212_093326.txt:02-12 09:34:15.576392    vendor.qti.came  1634  50804android_log_20250212_093815.txt:02-12 09:38:20.401365  2419 16428 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"53561","swapPss":"441428","total":"494989"}}, len: 79
android_log_20250212_093815.txt:02-12 09:38:21.495971  2419 16428 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"419354","swapPss":"404776","total":"824130"}}, len: 80
android_log_20250212_093815.txt:02-12 09:38:22.117979  2419 16428 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"446997","swapPss":"402052","total":"849049"}}, len: 80
kernel_log_20250212_093326.txt:02-12 09:38:22.903274  5174  5174 I [57697.813535]osvelte: vendor.qti.came   0  1047 S    1634     1 -1000   1795295   89358   29790     526  100309
kernel_log_20250212_093326.txt:02-12 09:38:22.924792  5174  5174 I [57697.835053]osvelte: vendor.qti.came   1634 558480
kernel_log_20250212_093326.txt:02-12 09:38:22.989238  5174  5174 I [57697.899499]osvelte: vendor.qti.came   1634 2056
kernel_log_20250212_093326.txt:02-12 09:38:23.024083  5174  5174 I [57697.934344]osvelte: vendor.qti.came  1634  57436
android_log_20250212_093815.txt:02-12 09:38:23.974748  2419 16428 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"436127","swapPss":"400380","total":"836507"}}, len: 80
android_log_20250212_093815.txt:02-12 09:38:25.048338  2419  2419 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"131587","swapPss":"399708","total":"531295"}}, len: 80
android_log_20250212_105715.txt:02-12 10:57:45.990464  2419 16408 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"108438","swapPss":"524372","total":"632810"}}, len: 80
android_log_20250212_105715.txt:02-12 10:57:46.877925  2419 28204 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"413473","swapPss":"522412","total":"935885"}}, len: 80
android_log_20250212_105715.txt:02-12 10:57:47.067209  2419 28204 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"423721","swapPss":"522400","total":"946121"}}, len: 80
android_log_20250212_105715.txt:02-12 10:57:48.851122  2419 28204 I CameraServiceExtImpl.cpp: 969 onTransact() onTransact, str: {"HAL_Memory":{"pid":"1634","pss":"453347","swapPss":"522660","total":"976007"}}, len: 80

    2.6 ：此时，12小时之前不增长，后面swap异常增长变得难以理解了

        于是测试和正面分析同步进行。经过压测大量测试场景，均未发现相机进程内存泄漏。一定程度排除内存泄漏的可能，而swap的写入写出不是用户态控制，由kernel内核态控制。分析内核日志后也无特别异常。

    2.7 ：继续压测monkey正式版本，无法复现

压测monkey正式版本发现hal进程crash，测试完，相机退出，hal进程内存也非常正常，swap内存也只有几百M。

    2.8 ：基于测试情况对老化版本的猜测

开始怀疑老化版本在高负载情况下才出现，正式版本一般情况下不会出现。

    2.9 ：使用老化版本高负载下压测，果然复现

于是使用老化版本高负载下压测并dump内存果然出现heap增长，但不是每次都增长，而是概率性增长，而PSS增长到2G左右，swap内存开始增长。正式版本却很难复现。

    2.10 ：基于上面swap原理分析，我们开始复现并分析内存泄漏

开启malloc debug进行复测，发现FDnode代码中VendorFDDeinit没有执行cv_face_destroy_tracker导致出现泄漏。其中malloc debug分析方式参考：内存泄漏系列专题分析之五：使用malloc_debug定位C/C++ native heap内存泄露

VOID FDManagerNode::VendorFDLoad(senseTime_lib_struct *p_lib)
{int rc = 0;struct timeval mStartTime, mEndTime;gettimeofday(&mStartTime, NULL);……………………………………ret = g_senseTime_lib.cv_face_create_tracker(&m_SenseTimeEngine.cv_tracker_handle, NULL, flag);if ((ret != CV_OK) || (m_SenseTimeEngine.cv_tracker_handle == NULL)){CAMX_LOG_ERROR(CamxLogGroupFD, "WIDE: cv_face_create_tracker error: %d", ret);return ret;}
}
VOID FDManagerNode::VendorFDDeinit()
{struct timeval mStartTime, mEndTime;gettimeofday(&mStartTime, NULL);if (m_SenseTimeEngine.cv_tracker_handle){g_senseTime_lib.cv_face_destroy_tracker(m_SenseTimeEngine.cv_tracker_handle);m_SenseTimeEngine.cv_tracker_handle = NULL;}CamxAtomicDecU(&m_engineCounter);VendorFDModelDeinit();if (m_attrFeature != NULL){free(m_attrFeature);m_attrFeature = NULL;}if (m_attrEmotion != NULL){free(m_attrEmotion);m_attrEmotion = NULL;}gettimeofday(&mEndTime, NULL);CAMX_LOG_INFO(CamxLogGroupFD, "FD deinit spends %lld ms (pending engine: %d)",((mEndTime.tv_sec - mStartTime.tv_sec) * 1000 + (mEndTime.tv_usec - mStartTime.tv_usec)/1000), m_engineCounter);
}

  .

    2.11 ：分析Camx HAL fdnode代码

经过代码分析，FDnode申请和释放是对应关系，并没有特别异常。

申请内存：在VendorFDLoad里调用cv_face_create_tracker

释放内存：在VendorFDDeinit里调用cv_face_destroy_tracker

从代码上看，并没有内存泄漏。

  .

    2.12 ：加日志debug

        于是加日志debug，发现FDnode是创建多线程运行，且多个锁操作和原子操作。而在性能极差的情况下，线程同步会出现问题，导致内存handler在构造函数创建线程时已经置空，导致另外一个线程在析构函数未释放。代码如下：

void FDManagerNode::OPLUSFDManagerNode()
{……//多线程这里全局变量置NULL了m_SenseTimeEngine.cv_tracker_handle = NULL;……
}VOID FDManagerNode::VendorFDDeinit()
{//导致这里无法进入是否内存if (m_SenseTimeEngine.cv_tracker_handle){g_senseTime_lib.cv_face_destroy_tracker(m_SenseTimeEngine.cv_tracker_handle);m_SenseTimeEngine.cv_tracker_handle = NULL;}
}

    2.13 ：解决问题

解决线程同步异常问题就解决该问题。

    2.14 ：总结

终于有了最终结论，性能极差下，非常低概率下，线程同步异常导致内存泄漏。
