UniApp 实现自定义的侧边栏菜单组件

前言

在移动应用开发中，侧边栏（Drawer）菜单是提升导航效率和用户体验的重要组件。它不仅能容纳更多功能入口，还能让界面更简洁有序。随着鸿蒙（HarmonyOS）生态的壮大，开发者对多端适配和高性能交互提出了更高要求。本文将以 UniApp 为例，详细讲解如何开发一个美观、实用、适配鸿蒙的自定义侧边栏菜单组件。

一、需求与设计思路

1. 需求分析

支持左侧/右侧弹出
支持自定义菜单项、图标、跳转
支持遮罩点击关闭、滑动关闭
兼容鸿蒙平台，适配不同分辨率
组件化设计，便于复用和扩展

2. 设计思路

使用绝对定位和过渡动画实现侧边栏弹出/收起
菜单项通过 v-for 渲染，支持动态扩展
遮罩层点击或滑动手势关闭菜单
结合 CSS3 动画提升交互体验
适配鸿蒙平台的手势和安全区域

二、核心代码实现

1. 组件结构

<template><view><view class="drawer-mask" v-if="show" @click="close"></view><viewclass="drawer":class="[side, { show }]":style="drawerStyle"@touchstart="onTouchStart"@touchmove="onTouchMove"@touchend="onTouchEnd"><view class="drawer-header"><slot name="header">菜单</slot></view><view class="drawer-menu"><viewv-for="item in menu":key="item.key"class="drawer-item"@click="onSelect(item)"><image v-if="item.icon" :src="item.icon" class="icon" /><text>{{ item.label }}</text></view></view><view class="drawer-footer"><slot name="footer"></slot></view></view></view>
</template>

2. 脚本逻辑

<script>
export default {name: 'SidebarDrawer',props: {show: { type: Boolean, default: false },menu: { type: Array, default: () => [] },side: { type: String, default: 'left' }, // left/rightwidth: { type: String, default: '70vw' },},data() {return {startX: 0,deltaX: 0,};},computed: {drawerStyle() {return `width: ${this.width};`;},},methods: {close() {this.$emit('update:show', false);},onSelect(item) {this.$emit('select', item);this.close();},onTouchStart(e) {this.startX = e.touches[0].clientX;this.deltaX = 0;},onTouchMove(e) {this.deltaX = e.touches[0].clientX - this.startX;},onTouchEnd() {// 左侧菜单向左滑，右侧菜单向右滑关闭if ((this.side === 'left' && this.deltaX < -60) ||(this.side === 'right' && this.deltaX > 60)) {this.close();}},},
};
</script>

3. 样式设计

<style scoped>
.drawer-mask {position: fixed;left: 0; top: 0; right: 0; bottom: 0;background: rgba(0,0,0,0.3);z-index: 99;animation: fadeIn 0.2s;
}
.drawer {position: fixed;top: 0; bottom: 0;width: 70vw;background: #fff;z-index: 100;box-shadow: 4rpx 0 32rpx rgba(0,0,0,0.08);transition: transform 0.25s cubic-bezier(.4,0,.2,1);will-change: transform;padding-bottom: env(safe-area-inset-bottom);display: flex;flex-direction: column;
}
.drawer.left {left: 0;transform: translateX(-100%);
}
.drawer.right {right: 0;transform: translateX(100%);
}
.drawer.show.left {transform: translateX(0);
}
.drawer.show.right {transform: translateX(0);
}
.drawer-header {padding: 48rpx 32rpx 24rpx 32rpx;font-size: 32rpx;font-weight: bold;color: #222;border-bottom: 1rpx solid #f0f0f0;
}
.drawer-menu {flex: 1;padding: 24rpx 0;overflow-y: auto;
}
.drawer-item {display: flex;align-items: center;padding: 0 32rpx;height: 88rpx;font-size: 28rpx;color: #333;cursor: pointer;transition: background 0.2s;
}
.drawer-item:active {background: #f0faff;color: #007aff;
}
.icon {width: 40rpx;height: 40rpx;margin-right: 18rpx;
}
.drawer-footer {padding: 24rpx 32rpx 32rpx 32rpx;border-top: 1rpx solid #f0f0f0;font-size: 24rpx;color: #aaa;
}
@keyframes fadeIn {from { opacity: 0; }to { opacity: 1; }
}
</style>

三、父页面集成与使用示例

<template><button @click="showDrawer = true">打开菜单</button><sidebar-drawer:show.sync="showDrawer":menu="menuList"side="left"width="70vw"@select="onMenuSelect"><template #header>个人中心</template><template #footer>版本号 1.0.0</template></sidebar-drawer>
</template><script>
import SidebarDrawer from '@/components/SidebarDrawer.vue';
export default {components: { SidebarDrawer },data() {return {showDrawer: false,menuList: [{ key: 'home', label: '首页', icon: '/static/home.png' },{ key: 'profile', label: '个人资料', icon: '/static/user.png' },{ key: 'settings', label: '设置', icon: '/static/settings.png' },],};},methods: {onMenuSelect(item) {uni.showToast({ title: `点击了${item.label}`, icon: 'none' });// 可根据 item.key 跳转页面},},
};
</script>
