WeMos D1+PIR+Android 的小场景制作

news 来源：原创 2025/5/13 13:17:24

最近在做一个有趣的小场景功能，其实已经有成熟产品，但是考虑到没法实现场景扩展，所以自己开始动手做。

场景描述：玄关人体感应，有人进门，致欢迎词，有人离开，致欢送词。

硬件设备：WeMOS D1 + PIR 【HC-SR501 】 + Android手机

数据流：

从WeMOS D1开始

关于WeMos D1的参考链接：

Arduino文档阅读笔记-WeMos D1 ESP8266 WIFI开发板入门_wemos d1手册-CSDN博客

ArduiNo(WeMos D1)基础（一）_arduino d1-CSDN博客

ESP8266之WiFiClient库学习-CSDN博客

WeMos D1主要是是作为TCPClient,将接收到的PIR信息推送给android系统，并接收反馈信息

/*
    This sketch establishes a TCP connection to a "quote of the day" service.
    It sends a "hello" message, and then prints received data.
*/

#include <ESP8266WiFi.h>

#ifndef STASSID
#define STASSID "your-ssid"
#define STAPSK "your-password"
#endif

const char* ssid = STASSID;
const char* password = STAPSK;

const char* host = "djxmmx.net";
const uint16_t port = 17;

void setup() {
  Serial.begin(115200);

  // We start by connecting to a WiFi network

  Serial.println();
  Serial.println();
  Serial.print("Connecting to ");
  Serial.println(ssid);

  /* Explicitly set the ESP8266 to be a WiFi-client, otherwise, it by default,
     would try to act as both a client and an access-point and could cause
     network-issues with your other WiFi-devices on your WiFi-network. */
  WiFi.mode(WIFI_STA);
  WiFi.begin(ssid, password);

  while (WiFi.status() != WL_CONNECTED) {
    delay(500);
    Serial.print(".");
  }

  Serial.println("");
  Serial.println("WiFi connected");
  Serial.println("IP address: ");
  Serial.println(WiFi.localIP());
}

void loop() {
  static bool wait = false;

  Serial.print("connecting to ");
  Serial.print(host);
  Serial.print(':');
  Serial.println(port);

  // Use WiFiClient class to create TCP connections
  WiFiClient client;
  if (!client.connect(host, port)) {
    Serial.println("connection failed");
    delay(5000);
    return;
  }

  // This will send a string to the server
  Serial.println("sending data to server");
  if (client.connected()) { client.println("hello from ESP8266"); }

  // wait for data to be available
  unsigned long timeout = millis();
  while (client.available() == 0) {
    if (millis() - timeout > 5000) {
      Serial.println(">>> Client Timeout !");
      client.stop();
      delay(60000);
      return;
    }
  }

  // Read all the lines of the reply from server and print them to Serial
  Serial.println("receiving from remote server");
  // not testing 'client.connected()' since we do not need to send data here
  while (client.available()) {
    char ch = static_cast<char>(client.read());
    Serial.print(ch);
  }

  // Close the connection
  Serial.println();
  Serial.println("closing connection");
  client.stop();

  if (wait) {
    delay(300000);  // execute once every 5 minutes, don't flood remote service
  }
  wait = true;
}

PIR功能的开发测试链接：

在 Arduino 上使用 HC-SR501 人体热释电（PIR）传感器 – Arduino 实验室 (nxez.com)

其中的有些代码还是要调整的：

int pirPin = D5;  // PIR传感器连接的引脚

void setup() {
  pinMode(pirPin, INPUT);  // 将PIR传感器引脚设置为输入模式
  pinMode(LED_BUILTIN, OUTPUT);
  Serial.begin(115200);      // 初始化串口通信
}

void loop() {
  int pirValue = digitalRead(pirPin); // 读取PIR传感器的值

  if (pirValue == HIGH) { // 如果检测到运动
    digitalWrite(LED_BUILTIN, HIGH);   // turn the LED on (HIGH is the voltage level)
    delay(1000);                       // wait for a second
    digitalWrite(LED_BUILTIN, LOW);    // turn the LED off by making the voltage LOW
    delay(1000);
    Serial.println("Motion detected!"); // 在串口打印消息
    delay(1000); // 延迟1秒
  } else {
    digitalWrite(LED_BUILTIN, LOW);    // turn the LED off by making the voltage LOW
    delay(1000);
  }
}

通过Android系统，搭建TCPServer接收 WeMos发送的PIR的测试信息.

Android功能待更新...
