Android framework 问题记录

news 来源：原创 2025/5/20 6:18:04

一、休眠唤醒，很快熄屏

1.1 问题描述

机器休眠唤醒后，没有按照约定的熄屏timeout 进行熄屏，很快就熄屏（约2s~3s左右）

1.2 原因分析：

抓取相关log，打印休眠背光相关调用栈

//具体打印调用栈直接从网上找即可，这里checkout了，就随便贴一个
//在frameworks/base/services/core/java/com/android/server/power/PowerManagerService.java的isBeingKeptAwakeLocked 函数里 加入如下
Log.e("TAG", Log.getStackTraceString(new Exception("Stack trace")));

根据打印调用栈对比正常情况，可以得知多出如下打印

java.lang.Throwableat com.android.server.power.PowerManagerService.isBeingKeptAwakeLocked(PowerManagerService.java:2909)at com.android.server.power.PowerManagerService.isItBedTimeYetLocked(PowerManagerService.java:2887)at com.android.server.power.PowerManagerService.updateWakefulnessLocked(PowerManagerService.java:2843)at com.android.server.power.PowerManagerService.updatePowerStateLocked(PowerManagerService.java:2152)at com.android.server.power.PowerManagerService.userActivityInternal(PowerManagerService.java:1698)at com.android.server.power.PowerManagerService.onFlip(PowerManagerService.java:1086)at com.android.server.power.PowerManagerService.$r8$lambda$q7dp6tNnllSjuO6t2c5KypV49H8(Unknown Source:0)at com.android.server.power.PowerManagerService$$ExternalSyntheticLambda1.accept(Unknown Source:8)at com.android.server.power.FaceDownDetector.faceDownDetected(FaceDownDetector.java:297)at com.android.server.power.FaceDownDetector.onSensorChanged(FaceDownDetector.java:284)at android.hardware.SystemSensorManager$SensorEventQueue.dispatchSensorEvent(SystemSensorManager.java:886)at android.os.MessageQueue.nativePollOnce(Native Method)at android.os.MessageQueue.next(MessageQueue.java:335)at android.os.Looper.loopOnce(Looper.java:161)at android.os.Looper.loop(Looper.java:288)at com.android.server.SystemServer.run(SystemServer.java:922)at com.android.server.SystemServer.main(SystemServer.java:618)at java.lang.reflect.Method.invoke(Native Method)at com.android.internal.os.RuntimeInit$MethodAndArgsCaller.run(RuntimeInit.java:568)at com.android.internal.os.ZygoteInit.main(ZygoteInit.java:1023)

排查onSensorChanged中的faceDownDetected

    @Overridepublic void onSensorChanged(SensorEvent event) {if (event.sensor.getType() != Sensor.TYPE_ACCELEROMETER) return;if (!mActive || !mIsEnabled) return;final float x = event.values[0];final float y = event.values[1];mCurrentXYAcceleration.updateMovingAverage(x * x + y * y);mCurrentZAcceleration.updateMovingAverage(event.values[2]);// Detect movement// If the x, y acceleration is within the acc threshold for at least a length of time longer// than the time threshold, we set moving to true.final long curTime = event.timestamp;if (Math.abs(mCurrentXYAcceleration.mMovingAverage - mPrevAcceleration)> mAccelerationThreshold) {mPrevAcceleration = mCurrentXYAcceleration.mMovingAverage;mPrevAccelerationTime = curTime;}final boolean moving = curTime - mPrevAccelerationTime <= mTimeThreshold.toNanos();// If the z acceleration is beyond the gravity/z-acceleration threshold for at least a// length of time longer than the time threshold, we set isFaceDownForPeriod to true.final float zAccelerationThreshold =mFaceDown ? mZAccelerationThresholdLenient : mZAccelerationThreshold;final boolean isCurrentlyFaceDown =mCurrentZAcceleration.mMovingAverage < zAccelerationThreshold;final boolean isFaceDownForPeriod = isCurrentlyFaceDown&& mZAccelerationIsFaceDown&& curTime - mZAccelerationFaceDownTime > mTimeThreshold.toNanos();if (isCurrentlyFaceDown && !mZAccelerationIsFaceDown) {mZAccelerationFaceDownTime = curTime;mZAccelerationIsFaceDown = true;} else if (!isCurrentlyFaceDown) {mZAccelerationIsFaceDown = false;}if (!moving && isFaceDownForPeriod && !mFaceDown) {//已知是这个导致的，把这个func注释后，现象就消失了.//关注原因，是因为G-sensor导致的，关注到调试时，板子并非按整机方式进行放置，x、y会出现问题，//最终导致执行了faceDownDetected，因而导致了亮屏后快速熄屏。faceDownDetected();} else if (!isFaceDownForPeriod && mFaceDown) {unFlipDetected();}}
