基于计算机视觉的试卷答题区表格识别与提取技术

摘要

本文介绍了一种基于计算机视觉技术的试卷答题区表格识别与提取算法。该算法能够自动从试卷图像中定位答题区表格，执行图像方向矫正，精确识别表格网格线，并提取每个答案单元格。本技术可广泛应用于教育测评、考试管理系统等场景，极大提高答卷处理效率。

关键技术

表格区域提取与分割
图像二值化预处理
多尺度形态学操作
水平线与竖线精确检测
单元格定位与提取

1. 系统架构

我们设计的试卷答题区表格处理工具由以下主要模块组成：

答题区定位：从整张试卷图像中提取右上角的答题区表格
图像预处理：进行二值化、去噪等操作以增强表格线条
表格网格识别：精确检测水平线和竖线位置
单元格提取：根据网格线交点切割并保存各个答案单元格

处理流程：

输入图像 -> 答题区定位 -> 方向矫正 -> 图像预处理 ->
网格线检测 -> 单元格提取 -> 输出结果

2. 核心功能实现

2.1 答题区表格定位

我们假设答题区通常位于试卷右上角，首先提取该区域并应用轮廓检测算法：

# 提取右上角区域（答题区域通常在试卷右上角）
x_start = int(width * 0.6)
y_start = 0
w = width - x_start
h = int(height * 0.5)# 提取区域
region = img[y_start:y_start + h, x_start:x_start + w]

接着使用形态学操作提取线条并查找表格轮廓：

# 转为灰度图并二值化
gray = cv2.cvtColor(region, cv2.COLOR_BGR2GRAY)
binary = cv2.adaptiveThreshold(gray, 255, cv2.ADAPTIVE_THRESH_GAUSSIAN_C,cv2.THRESH_BINARY_INV, 11, 2)# 使用形态学操作检测线条
horizontal_lines = cv2.morphologyEx(binary, cv2.MORPH_OPEN, kernel_h, iterations=2)
vertical_lines = cv2.morphologyEx(binary, cv2.MORPH_OPEN, kernel_v, iterations=2)

2.2 图像预处理

为了增强表格线条特征，我们执行以下预处理步骤：

# 高斯平滑去噪
blurred = cv2.GaussianBlur(gray, (5, 5), 0)# 自适应阈值二值化
binary = cv2.adaptiveThreshold(blurred, 255, cv2.ADAPTIVE_THRESH_GAUSSIAN_C, cv2.THRESH_BINARY_INV, 21, 5)# 形态学操作填充小空隙
kernel = np.ones((3, 3), np.uint8)
binary = cv2.morphologyEx(binary, cv2.MORPH_CLOSE, kernel)

2.3 表格网格线识别

这是本算法的核心部分，我们分别检测水平线和竖线：

2.3.1 水平线检测

使用形态学开运算提取水平线，然后计算投影找到线条位置：

horizontal_kernel = cv2.getStructuringElement(cv2.MORPH_RECT, (horizontal_size, 1))
horizontal_lines = cv2.morphologyEx(binary_image, cv2.MORPH_OPEN, horizontal_kernel, iterations=2)# 提取水平线坐标 - 基于行投影
h_coords = []
h_projection = np.sum(horizontal_lines, axis=1)
for i in range(1, len(h_projection) - 1):if h_projection[i] > h_projection[i - 1] and h_projection[i] > h_projection[i + 1] and h_projection[i] > width // 5:h_coords.append(i)

2.3.2 竖线检测

竖线检测采用多尺度策略，使用不同大小的结构元素，提高检测的鲁棒性：

# 使用不同大小的结构元素进行竖线检测
vertical_kernels = [cv2.getStructuringElement(cv2.MORPH_RECT, (1, (table_bottom - table_top) // 12)),  # 细线cv2.getStructuringElement(cv2.MORPH_RECT, (1, (table_bottom - table_top) // 8)),  # 中等cv2.getStructuringElement(cv2.MORPH_RECT, (1, (table_bottom - table_top) // 4))  # 粗线
]# 合并不同尺度的检测结果
vertical_lines = np.zeros_like(binary_image)
for kernel in vertical_kernels:v_lines = cv2.morphologyEx(binary_image, cv2.MORPH_OPEN, kernel, iterations=1)vertical_lines = cv2.bitwise_or(vertical_lines, v_lines)

2.4 表格竖线位置精确校正

由于竖线检测可能存在偏左问题，我们实现了复杂的位置校正算法：

# 竖线位置修正：解决偏左问题 - 检测实际线条中心位置
v_coords_corrected = []
for idx, v_coord in enumerate(v_coords_detected):# 第2-11根竖线特殊处理if 1 <= idx <= 10:  # 第2-11根竖线search_range_left = 2  # 左侧搜索范围更小search_range_right = 12  # 右侧搜索范围大幅增大else:search_range_left = 5search_range_right = 5# 在搜索范围内找到峰值中心位置# 对于特定竖线，使用加权平均来偏向右侧if 1 <= idx <= 10:window = col_sum[left_bound:right_bound+1]weights = np.linspace(0.3, 2.0, len(window))  # 更强的右侧权重weighted_window = window * weightsmax_pos = left_bound + np.argmax(weighted_window)# 强制向右偏移max_pos += 3else:max_pos = left_bound + np.argmax(col_sum[left_bound:right_bound+1])

2.4.1 不等间距网格处理

我们根据实际表格特点，处理了第一列宽度与其他列不同的情况：

# 设置第一列的宽度为其他列的1.3倍
first_column_width_ratio = 1.3# 计算除第一列外每列的宽度
remaining_width = right_bound - left_bound
regular_column_width = remaining_width / (expected_vlines - 1 + (first_column_width_ratio - 1))

2.5 单元格提取与保存

根据检测到的网格线，我们提取出每个单元格：

# 提取单元格的过程
cell_img = image[y1_m:y2_m, x1_m:x2_m].copy()# 保存单元格图片
cell_filename = f'cell_0{q_num:02d}.png'
cell_path = os.path.join(output_dir, cell_filename)
cv2.imwrite(cell_path, cell_img)

3. 技术创新点

多尺度形态学操作：使用不同尺寸的结构元素检测竖线，提高了检测的鲁棒性
表格线位置动态校正：针对不同位置的竖线采用不同的校正策略，解决了竖线偏左问题
不等间距网格处理：通过特殊计算处理第一列宽度不同的情况，更好地适应实际试卷样式
加权峰值搜索：使用加权策略进行峰值搜索，提高了线条中心位置的准确性

4. 使用示例

4.1 基本用法

from image_processing import process_image# 处理单张图像
input_image = "./images/1.jpg"
output_dir = "./output"
image_paths = process_image(input_image, output_dir)print(f"处理成功: 共生成{len(image_paths)}个单元格图片")

4.2 批量处理

我们还提供了批量处理多张试卷图像的功能：

# 批量处理目录中的所有图像
for img_file in image_files:img_path = os.path.join(images_dir, img_file)output_dir = os.path.join(output_base_dir, f"result_{img_name}")image_paths = process_image(img_path, output_dir)

4.3 完整代码

"""
试卷答题区表格处理工具
1. 从试卷提取答题区表格
2. 对表格进行方向矫正
3. 切割表格单元格并保存所有25道题的答案单元格
"""
