Learning vtkjs之ImplicitBoolean

隐式函数布尔操作

介绍

vtkImplicitBoolean 允许对隐式函数(如平面、球体、圆柱体和盒子)进行布尔组合。操作包括并集、交集和差集。可以指定多个隐式函数(所有函数都使用相同的操作进行组合)。

支持的操作:‘UNION’(<=0),‘INTERSECTION’(=1),‘DIFFERENCE’(>=2)

效果

在这里插入图片描述

核心代码

主要是隐式函数添加,然后执行操作,可视化是需要借助vtkSampleFunction来采样的

	const lCylCut = vtkImplicitBoolean.newInstance({operation: Operation.UNION,functions: [cyl, pLeft],});const rCylCut = vtkImplicitBoolean.newInstance({operation: Operation.INTERSECTION,});rCylCut.addFunction(lCylCut);rCylCut.addFunction(pRight);

完整逻辑

 	const fullScreenRenderer = vtkFullScreenRenderWindow.newInstance({background: [0, 0, 0],rootContainer: vtkContainerRef.current,});const renderer = fullScreenRenderer.getRenderer();const renderWindow = fullScreenRenderer.getRenderWindow();const actor = vtkActor.newInstance();renderer.addActor(actor);const mapper = vtkMapper.newInstance();actor.setMapper(mapper);// Build pipeline. Boolean together some implicit functions and then sample, isosurface themconst pLeft = vtkSphere.newInstance({center: [-6.0, 0, 0],radius: 0.8,});const pRight = vtkPlane.newInstance({normal: [1, 0, 0],origin: [5, 0, 0],});const cyl = vtkCylinder.newInstance({radius: 0.5,center: [0, 0, 0],axis: [1, 0, 0],});const lCylCut = vtkImplicitBoolean.newInstance({operation: Operation.UNION,functions: [cyl, pLeft],});const rCylCut = vtkImplicitBoolean.newInstance({operation: Operation.INTERSECTION,});rCylCut.addFunction(lCylCut);rCylCut.addFunction(pRight);const sample = vtkSampleFunction.newInstance({implicitFunction: rCylCut,sampleDimensions: [100, 100, 100],modelBounds: [-7.5, 7.5, -1, 1, -1, 1],});const mCubes = vtkImageMarchingCubes.newInstance({ contourValue: 0.0 });// Connect the pipeline propermCubes.setInputConnection(sample.getOutputPort());mapper.setInputConnection(mCubes.getOutputPort());renderer.resetCamera();renderWindow.render();

全部代码都放到github上了
新坑_Learning vtkjs_git地址
关注我,我持续更新vtkjs的example学习案例

也欢迎各位给我提意见,技术交流~

大鸿

WeChat : HugeYen
WeChat Public Account : BIM树洞

做一个静谧的树洞君

用建筑的语言描述IT事物;

用IT的思维解决建筑问题;

共建BIM桥梁,聚合团队。

本学习分享资料不得用于商业用途,仅做学习交流!!如有侵权立即删除!!
