404-Spring AI Alibaba Graph 可观测性 Langfuse 功能完整案例

news 2025/11/1 11:50:27

本案例将引导您一步步构建一个 Spring Boot 应用，演示如何利用 Spring AI Alibaba Graph 与 Langfuse 集成，实现 AI 图应用的全面可观测性和监控。

1. 案例目标

我们将创建一个包含复杂图结构的 Web 应用，展示以下核心功能：

  1. 复杂图结构处理：包含并行边、串行边、子图等多种节点类型和边类型。
  2. 实时流式 AI 响应：通过 StreamingChatNode 实现实时流式 AI 响应。
  3. Langfuse 可观测性集成：完整集成 Langfuse，实现 AI 应用的全面可观测性。
  4. OpenTelemetry 追踪和指标收集：通过 OpenTelemetry 收集追踪和指标数据。
  5. SSE 实时更新支持：支持 Server-Sent Events (SSE) 实时更新。

2. 技术栈与核心依赖

  • Spring Boot 3.x
  • Spring AI Alibaba (用于对接阿里云 DashScope 通义大模型)
  • Spring AI Alibaba Graph (用于复杂图结构的 AI 处理流程)
  • Langfuse (用于 AI 可观测性、追踪和分析)
  • OpenTelemetry (用于追踪和指标收集)
  • Maven (项目构建工具)

在 pom.xml 中，你需要引入以下核心依赖：

<dependencies><!-- Spring AI Alibaba 核心启动器，集成 DashScope --><dependency><groupId>com.alibaba.cloud.ai</groupId><artifactId>spring-ai-alibaba-starter-dashscope</artifactId><version>1.0.0.3</version></dependency><!-- Spring AI Alibaba Graph 可观测性启动器 --><dependency><groupId>com.alibaba.cloud.ai</groupId><artifactId>spring-ai-alibaba-starter-graph-observation</artifactId><version>1.0.0.3</version></dependency><!-- Spring WebFlux 用于响应式编程和 SSE 支持 --><dependency><groupId>org.springframework.boot</groupId><artifactId>spring-boot-starter-webflux</artifactId></dependency><!-- HTTP 客户端 --><dependency><groupId>org.apache.httpcomponents.client5</groupId><artifactId>httpclient5</artifactId><version>5.4.1</version></dependency><!-- OpenTelemetry Spring Boot 启动器 --><dependency><groupId>io.opentelemetry.instrumentation</groupId><artifactId>opentelemetry-spring-boot-starter</artifactId><version>2.9.0</version></dependency><!-- Micrometer Tracing Bridge OpenTelemetry --><dependency><groupId>io.micrometer</groupId><artifactId>micrometer-tracing-bridge-otel</artifactId><exclusions><exclusion><artifactId>slf4j-api</artifactId><groupId>org.slf4j</groupId></exclusion></exclusions></dependency><!-- OpenTelemetry OTLP 导出器 --><dependency><groupId>io.opentelemetry</groupId><artifactId>opentelemetry-exporter-otlp</artifactId></dependency><!-- Spring Boot Actuator 用于健康检查和监控 --><dependency><groupId>org.springframework.boot</groupId><artifactId>spring-boot-starter-actuator</artifactId></dependency>
</dependencies>

3. 项目配置

在 src/main/resources/application.yml 文件中，配置你的 DashScope API Key 和 Langfuse 连接信息。

server:port: 8080
spring:application:name: graph-observation-langfuseai:dashscope:api-key: ${AI_DASHSCOPE_API_KEY}chat:options:model: qwen-maxalibaba:graph:observation:enabled: truemanagement:endpoints:web:exposure:include: "*"endpoint:health:# health status check with detailed messagesshow-details: alwaystracing:sampling:# trace information with every requestprobability: 1.0observations:annotations:enabled: trueotel:service:name: spring-ai-alibaba-graph-langfuseresource:attributes:deployment.environment: development# configure exportertraces:exporter: otlpsampler: always_onmetrics:exporter: otlp# logs exportation inhibited for langfuse currently cannot supportlogs:exporter: noneexporter:otlp:endpoint: "https://cloud.langfuse.com/api/public/otel"headers:Authorization: "Basic ${YOUR_BASE64_ENCODED_CREDENTIALS}"protocol: http/protobuf

重要提示：

  • 请将 AI_DASHSCOPE_API_KEY 环境变量设置为你从阿里云获取的有效 API Key。
  • 请将 YOUR_BASE64_ENCODED_CREDENTIALS 替换为你的 Base64 编码的 Langfuse 凭据（格式：public_key:secret_key）。

4. Langfuse 配置

4.1 使用 Langfuse 云端服务

  1. 在 https://cloud.langfuse.com 注册账户
  2. 创建新项目
  3. 导航到 Settings → API Keys
  4. 生成新的 API 密钥对（公钥和私钥）
  5. 将凭据编码为 Base64：
# Linux/Mac
echo -n "public_key:secret_key" | base64# Windows PowerShell
[System.Convert]::ToBase64String([System.Text.Encoding]::UTF8.GetBytes("public_key:secret_key"))

4.2 使用自托管 Langfuse

  1. 使用 Docker 部署 Langfuse：
docker compose up -d
  1. 访问 http://localhost:3000
  2. 创建项目并生成 API 密钥
  3. 更新 application.yml 中的端点

5. 图结构设计

本示例实现了一个复杂的图结构，包含多种节点类型和边类型：

开始节点 → 并行处理 → 子图处理 → 流式节点 → 汇总节点 → 结束节点

5.1 节点类型

  • StartNode：初始处理节点
  • ParallelNode1/ParallelNode2：并行处理节点（情感分析和主题分析）
  • MergeNode：合并节点，将并行输出合并为子图输入
  • SimpleSubGraph：子图节点，包含内部串行处理流程
  • StreamingNode：流式节点，实时流式 AI 响应
  • SummaryNode：汇总节点，聚合流式输出
  • EndNode：结束节点，最终输出格式化

5.2 边类型

  • 串行边：严格按顺序执行（如 START → start）
  • 并行边：同时执行多个节点（如 start → parallel1 和 start → parallel2）
  • 聚合边：等待多个节点完成后再执行下一个节点（如 parallel1/parallel2 → merge）

6. 编写 Java 代码

6.1 GraphConfiguration.java

图配置类，定义图结构和节点关系。

@Configuration
public class GraphConfiguration {@Beanpublic StateGraph observabilityGraph(ChatClient chatClient) throws GraphStateException {// Start node - initial processingChatNode startNode = ChatNode.create("StartNode", "input", "start_output", chatClient,"Please perform initial processing on the input content:");// Parallel nodes - concurrent processingChatNode parallelNode1 = ChatNode.create("ParallelNode1", "start_output", "parallel_output1", chatClient,"Please perform sentiment analysis on the content:");ChatNode parallelNode2 = ChatNode.create("ParallelNode2", "start_output", "parallel_output2", chatClient,"Please perform topic analysis on the content:");// Summary node - aggregates streaming outputChatNode summaryNode = ChatNode.create("SummaryNode", "streaming_output", "summary_output", chatClient,"Please summarize the streaming analysis results:");// Merge node - combine parallel outputs for subgraph inputMergeNode mergeNode = new MergeNode(Lists.newArrayList("parallel_output1", "parallel_output2"), "sub_input");// Streaming node - real-time AI responseStreamingChatNode streamingNode = StreamingChatNode.create("StreamingNode", "final_output", "streaming_output",chatClient, "Please perform detailed analysis on the subgraph results:");// End node - final output formattingChatNode endNode = ChatNode.create("EndNode", "summary_output", "end_output", chatClient,"Please format the final results for output:");// Create subgraphSimpleSubGraph subGraph = new SimpleSubGraph(chatClient);// Build the main graphStateGraph graph = new StateGraph(keyStrategyFactory).addNode("start", node_async(startNode)).addNode("parallel1", node_async(parallelNode1)).addNode("parallel2", node_async(parallelNode2)).addNode("merge", node_async(mergeNode)).addNode("subgraph", subGraph.subGraph()).addNode("streaming", node_async(streamingNode)).addNode("summary", node_async(summaryNode)).addNode("end", node_async(endNode)).addEdge(START, "start").addEdge("start", "parallel1").addEdge("start", "parallel2").addEdge("parallel1", "merge").addEdge("parallel2", "merge").addEdge("merge", "subgraph").addEdge("subgraph", "streaming").addEdge("streaming", "summary").addEdge("summary", "end").addEdge("end", END);return graph;}@Beanpublic CompiledGraph compiledGraph(StateGraph observabilityGraph, CompileConfig observationCompileConfig)throws GraphStateException {return observabilityGraph.compile(observationCompileConfig);}
}

6.2 GraphController.java

图控制器，提供同步图执行接口。

@RestController
@RequestMapping("/graph/observation")
public class GraphController {@Autowiredprivate CompiledGraph compiledGraph;@GetMapping("/execute")public Map<String, Object> execute(@RequestParam(value = "prompt", defaultValue = "Hello World") String input) {try {// Create initial stateMap<String, Object> initialState = new HashMap<>();initialState.put("input", input);// Execute graphOverAllState result = compiledGraph.invoke(initialState).get();// Return resultMap<String, Object> response = new HashMap<>();response.put("success", true);response.put("input", input);response.put("output", result.value("end_output").orElse("No output"));response.put("logs", result.value("logs").orElse("No logs"));return response;}catch (Exception e) {Map<String, Object> errorResponse = new HashMap<>();errorResponse.put("success", false);errorResponse.put("error", e.getMessage());return errorResponse;}}
}

6.3 GraphStreamController.java

图流控制器，提供流式图执行接口。

@RestController
@RequestMapping("/graph/observation")
public class GraphStreamController {@Autowiredprivate CompiledGraph compiledGraph;@GetMapping(value = "/stream", produces = MediaType.TEXT_EVENT_STREAM_VALUE)public Flux<ServerSentEvent<String>> stream(@RequestParam(value = "prompt", defaultValue = "Hello World") String input,@RequestParam(value = "thread_id", defaultValue = "observability", required = false) String threadId)throws GraphRunnerException {// Create runnable configurationRunnableConfig runnableConfig = RunnableConfig.builder().threadId(threadId).build();// Create initial stateMap<String, Object> initialState = new HashMap<>();initialState.put("input", input);// Create graph processorGraphProcess graphProcess = new GraphProcess();// Get streaming outputAsyncGenerator<NodeOutput> resultStream = compiledGraph.stream(initialState, runnableConfig);// Process and return streaming outputreturn graphProcess.processStream(resultStream).doOnCancel(() -> logger.info("Client disconnected from streaming")).doOnError(e -> logger.error("Error occurred during streaming output", e)).doOnComplete(() -> logger.info("Streaming output completed"));}
}

6.4 SimpleSubGraph.java

子图实现，包含内部串行处理流程。

public class SimpleSubGraph implements SubGraphNode {private final ChatClient chatClient;public SimpleSubGraph(ChatClient chatClient) {this.chatClient = chatClient;this.subGraph = createSubGraph();}@Overridepublic String id() {return "simple_subgraph";}@Overridepublic StateGraph subGraph() {return this.subGraph;}private StateGraph createSubGraph() {try {// Create internal nodes for the subgraph (serial processing)ChatNode subNode1 = ChatNode.create("SubGraphNode1", "sub_input", "sub_output1", chatClient,"Please perform the first step processing on the following content:");ChatNode subNode2 = ChatNode.create("SubGraphNode2", "sub_output1", "sub_output2", chatClient,"Please perform the second step processing on the following content:");ChatNode subNode3 = ChatNode.create("SubGraphNode3", "sub_output2", "subgraph_final_output", chatClient,"Please perform the final processing on the following content:");// Build subgraph (pure serial structure)return new StateGraph("Simple SubGraph", keyStrategyFactory).addNode("sub_node1", node_async(subNode1)).addNode("sub_node2", node_async(subNode2)).addNode("sub_node3", node_async(subNode3)).addEdge(START, "sub_node1").addEdge("sub_node1", "sub_node2").addEdge("sub_node2", "sub_node3").addEdge("sub_node3", END);}catch (GraphStateException e) {throw new RuntimeException("Failed to create subgraph", e);}}
}

7. 运行与测试

  1. 设置环境变量：
# 必需：DashScope API 密钥
export AI_DASHSCOPE_API_KEY=your_dashscope_api_key
  1. 编译和运行：
mvn clean compile
mvn spring-boot:run

应用将在 http://localhost:8080 启动

测试 1：同步图执行

访问以下 URL，执行同步图处理：

curl "http://localhost:8080/graph/observation/execute?prompt=请分析这段文本：人工智能的发展"

预期响应：

{"success": true,"input": "请分析这段文本：人工智能的发展","output": "经过完整图处理的最终结果","logs": "执行日志信息"
}

测试 2：流式图执行

访问以下 URL，执行流式图处理：

curl "http://localhost:8080/graph/observation/stream?prompt=请分析这段文本：人工智能的发展&thread_id=demo"

预期响应（流式输出）：

data: {"type":"node_output","node":"start","data":{...},"timestamp":...}
event: node_output
id: start_...data: {"type":"node_output","node":"parallel1","data":{...},"timestamp":...}
event: node_output
id: parallel1_...data: {"type":"node_output","node":"parallel2","data":{...},"timestamp":...}
event: node_output
id: parallel2_...data: {"type":"node_output","node":"merge","data":{...},"timestamp":...}
event: node_output
id: merge_...data: {"type":"node_output","node":"subgraph","data":{...},"timestamp":...}
event: node_output
id: subgraph_...data: {"type":"streaming","node":"streaming","chunk":"...","timestamp":...}
event: node_output
id: streaming_...data: {"type":"streaming","node":"streaming","chunk":"...","timestamp":...}
event: node_output
id: streaming_...data: {"type":"node_output","node":"summary","data":{...},"timestamp":...}
event: node_output
id: summary_...data: {"type":"node_output","node":"end","data":{...},"timestamp":...}
event: node_output
id: end_...data: {"type":"completed","message":"Graph processing completed"}
event: completed

8. Langfuse 可观测性集成

8.1 启用 Graph 可观测性

在 application.yml 中启用 Graph 可观测性：

spring:ai:alibaba:graph:observation:enabled: true

8.2 注入 observationCompileConfig

在图配置中注入 observationCompileConfig：

@Bean
public CompiledGraph compiledGraph(StateGraph observabilityGraph, CompileConfig observationCompileConfig)throws GraphStateException {return observabilityGraph.compile(observationCompileConfig);
}

8.3 查看 Langfuse 仪表板

  1. 登录 Langfuse 云端服务或本地部署的 Langfuse 实例
  2. 导航到 Traces 页面查看图执行追踪
  3. 导航到 Sessions 页面查看会话数据
  4. 导航到 Scores 页面查看评分数据
  5. 导航到 Analytics 页面查看分析报告

9. 实现思路与扩展建议

实现思路

本案例的核心思想是"复杂图结构与可观测性结合"。我们将：

  • 复杂图结构：通过 Spring AI Alibaba Graph 实现复杂的图结构，包含并行边、串行边、子图等多种节点类型和边类型。
  • 可观测性集成：通过 Langfuse 集成，实现 AI 应用的全面可观测性，包括追踪、指标和日志。
  • 实时流式处理：通过 StreamingChatNode 实现实时流式 AI 响应，提供更好的用户体验。
  • OpenTelemetry 集成：通过 OpenTelemetry 收集追踪和指标数据，实现与 Langfuse 的无缝集成。

扩展建议

  • 自定义节点类型：根据业务需求，实现自定义节点类型，扩展图处理能力。
  • 动态图结构：实现动态图结构，根据运行时条件动态调整图结构。
  • 多模态处理：集成多模态处理能力，支持文本、图像、音频等多种输入类型。
  • 高级可观测性：集成更多可观测性工具，如 Prometheus、Grafana 等，实现更全面的监控和分析。
  • 分布式图处理：实现分布式图处理，支持大规模图计算任务。
  • 图优化算法：集成图优化算法，提高图处理效率和性能。
