机器学习周报十七

摘要

本周对transformer进行训练，并将transformer用于简单的机器翻译任务。

Abstract

Train the transformer this week and use the transformer for simple machine translation tasks.

1 transformer

之前多次尝试理解注意力机制和自注意力机制，顾名思义的理解是很简单的，就是关注重要的信息，忽略不重要的信息，但是将这个简单的概念，通过Q、K、V进行理解时，对我来说就会很困难，对一个查询query看与每个词的关联性，需要把这个Q和每个词的K矩阵相乘，得到一个权重，然后得到的权重与每个词的V矩阵相乘，这个query得到的结果就会包含每个关键词的信息。

1.1 注意力机制

注意力机制，在翻译时，对于生成的每一个英文词会生成一个Q，然后根据这个Q去和原句子每个词提供的K矩阵进行计算，得到英文词与哪个原单词联系更大。注意力机制主要应用于机器翻译。比如翻译’Good Morning’，生成第一个词’好’，就会对生成一个Q，根据这个Q去查询原句子的K和V就会得到与哪个词更匹配，然后翻译这个词就是这个’好’，怎么这个’好’字呢，经过大量数据的训练，就像学英语一样，看到了I就会翻译成我，模型参数会匹配到这个’好’。

1.2 自注意力机制

自注意力机制，每个词都会生成自己的Q、K、V，然后每个词的Q会和自己以及其他的词进行相乘，然后得到一组注意力分数。自注意力机制是去理解一句话的意图，主要应用于transformer。比如，对于’苹果很甜’和’苹果手机’两句话，这两句话中的’苹果’的含义是不同的，自注意力机制会计算每一个词之间的联系，得到发现’苹果’和’甜’在一起出现，就会理解这句话的’苹果’是水果。模型怎么知道需要联系甜和苹果，模型接受了一个训练句子，‘苹果很甜’，最开始苹果的Q矩阵和甜的K矩阵是随机的，$Q\cdot K^T$是一个没什么意义的值。根据当前的参数，为每个词计算注意力分数，根据注意力分数预测’苹果很_‘的下一个词，选择分数高的词进行预测，预测到的可能是’困’，然后通过损失函数来计算’困’和’甜’的损失值。再通过反向传播调整参数。最后知道苹果和甜会联系在一起。

$output=softmax(\frac{Q{K}^T}{\sqrt{d_k}})V$

1.3 掩码自注意力机制

对于训练数据集，所有的单词是同时出现的，不能让计算注意力分数的时候，看到后面的单词，应该是只能看见当前预测词之前的单词，所以需要添加一个掩码，来盖住后面的词，通常是乘以一个很大的负权重，这样后面的词就不起作用了。

1.4 多头自注意力机制

多头自注意力机制是从多个角度或者说通道去理解一句话，一句话是有情感、逻辑和语法的，比如’小猫太累了在睡觉’，语法层面会理解到小猫是主语，逻辑层面理解到小猫睡觉是因为太累了，情感层面可以理解到小猫的疲惫。一个自注意力机制有三个Q、K、V，多头自注意力机制有多个Q、K、V，有n个头，就把原始的输入分成n份，然后用这n个Q、K、V来计算注意力分数，最后把这些结果拼接在一起，就会变成一个和原本输入维度相同的输出。

以上是transformer的核心内容。

现在再回来看transformer模型，描述上稍微有点不同，解码器的第二步有一个多头交叉注意力机制，为了明确第二步的Q矩阵和K、V矩阵不是同源的双方不是来源于同一个词。理解上按照原来的理解也可以。

2 代码

# model.pyimport torch
import torch.nn as nn
import math
from torch import optimclass MultiHeadAttention(nn.Module):def __init__(self, d_model, num_heads):super(MultiHeadAttention, self).__init__()assert d_model % num_heads == 0, "d_model必须能被num_heads整除"self.d_model = d_model  # 模型维度（如512）self.num_heads = num_heads  # 注意力头数（如8）self.d_k = d_model // num_heads  # 每个头的维度（如64）# 定义线性变换层（无需偏置）self.W_q = nn.Linear(d_model, d_model)  # 查询变换self.W_k = nn.Linear(d_model, d_model)  # 键变换self.W_v = nn.Linear(d_model, d_model)  # 值变换self.W_o = nn.Linear(d_model, d_model)  # 输出变换def scaled_dot_product_attention(self, Q, K, V, mask=None):"""计算缩放点积注意力输入形状：Q: (batch_size, num_heads, seq_length, d_k)K, V: 同Q输出形状： (batch_size, num_heads, seq_length, d_k)"""# 计算注意力分数（Q和K的点积）attn_scores = torch.matmul(Q, K.transpose(-2, -1)) / math.sqrt(self.d_k)# 应用掩码（如填充掩码或未来信息掩码）if mask is not None:attn_scores = attn_scores.masked_fill(mask == 0, -1e9)# 计算注意力权重（softmax归一化）attn_probs = torch.softmax(attn_scores, dim=-1)# 对值向量加权求和output = torch.matmul(attn_probs, V)return outputdef split_heads(self, x):"""将输入张量分割为多个头输入形状: (batch_size, seq_length, d_model)输出形状: (batch_size, num_heads, seq_length, d_k)"""batch_size, seq_length, d_model = x.size()return x.view(batch_size, seq_length, self.num_heads, self.d_k).transpose(1, 2)def combine_heads(self, x):"""将多个头的输出合并回原始形状输入形状: (batch_size, num_heads, seq_length, d_k)输出形状: (batch_size, seq_length, d_model)"""batch_size, _, seq_length, d_k = x.size()return x.transpose(1, 2).contiguous().view(batch_size, seq_length, self.d_model)def forward(self, Q, K, V, mask=None):"""前向传播输入形状: Q/K/V: (batch_size, seq_length, d_model)输出形状: (batch_size, seq_length, d_model)"""# 线性变换并分割多头Q = self.split_heads(self.W_q(Q))  # (batch, heads, seq_len, d_k)K = self.split_heads(self.W_k(K))V = self.split_heads(self.W_v(V))# 计算注意力attn_output = self.scaled_dot_product_attention(Q, K, V, mask)# 合并多头并输出变换output = self.W_o(self.combine_heads(attn_output))return outputclass PositionWiseFeedForward(nn.Module):def __init__(self, d_model, d_ff):super(PositionWiseFeedForward, self).__init__()self.fc1 = nn.Linear(d_model, d_ff)  # 第一层全连接self.fc2 = nn.Linear(d_ff, d_model)  # 第二层全连接self.relu = nn.ReLU()  # 激活函数def forward(self, x):# 前馈网络的计算return self.fc2(self.relu(self.fc1(x)))class PositionalEncoding(nn.Module):def __init__(self, d_model, max_seq_length):super(PositionalEncoding, self).__init__()pe = torch.zeros(max_seq_length, d_model)  # 初始化位置编码矩阵position = torch.arange(0, max_seq_length, dtype=torch.float).unsqueeze(1)div_term = torch.exp(torch.arange(0, d_model, 2).float() * -(math.log(10000.0) / d_model))pe[:, 0::2] = torch.sin(position * div_term)  # 偶数位置使用正弦函数pe[:, 1::2] = torch.cos(position * div_term)  # 奇数位置使用余弦函数self.register_buffer('pe', pe.unsqueeze(0))  # 注册为缓冲区def forward(self, x):# 将位置编码添加到输入中return x + self.pe[:, :x.size(1)]class EncoderLayer(nn.Module):def __init__(self, d_model, num_heads, d_ff, dropout):super(EncoderLayer, self).__init__()self.self_attn = MultiHeadAttention(d_model, num_heads)  # 自注意力机制self.feed_forward = PositionWiseFeedForward(d_model, d_ff)  # 前馈网络self.norm1 = nn.LayerNorm(d_model)  # 层归一化self.norm2 = nn.LayerNorm(d_model)self.dropout = nn.Dropout(dropout)  # Dropoutdef forward(self, x, mask):# 自注意力机制attn_output = self.self_attn(x, x, x, mask)x = self.norm1(x + self.dropout(attn_output))  # 残差连接和层归一化# 前馈网络ff_output = self.feed_forward(x)x = self.norm2(x + self.dropout(ff_output))  # 残差连接和层归一化return xclass DecoderLayer(nn.Module):def __init__(self, d_model, num_heads, d_ff, dropout):super(DecoderLayer, self).__init__()self.self_attn = MultiHeadAttention(d_model, num_heads)  # 自注意力机制self.cross_attn = MultiHeadAttention(d_model, num_heads)  # 交叉注意力机制self.feed_forward = PositionWiseFeedForward(d_model, d_ff)  # 前馈网络self.norm1 = nn.LayerNorm(d_model)  # 层归一化self.norm2 = nn.LayerNorm(d_model)self.norm3 = nn.LayerNorm(d_model)self.dropout = nn.Dropout(dropout)  # Dropoutdef forward(self, x, enc_output, src_mask, tgt_mask):# 自注意力机制attn_output = self.self_attn(x, x, x, tgt_mask)x = self.norm1(x + self.dropout(attn_output))  # 残差连接和层归一化# 交叉注意力机制attn_output = self.cross_attn(x, enc_output, enc_output, src_mask)x = self.norm2(x + self.dropout(attn_output))  # 残差连接和层归一化# 前馈网络ff_output = self.feed_forward(x)x = self.norm3(x + self.dropout(ff_output))  # 残差连接和层归一化return xclass Transformer(nn.Module):def __init__(self, src_vocab_size, tgt_vocab_size, d_model, num_heads, num_layers, d_ff, max_seq_length, dropout):super(Transformer, self).__init__()self.encoder_embedding = nn.Embedding(src_vocab_size, d_model)  # 编码器词嵌入self.decoder_embedding = nn.Embedding(tgt_vocab_size, d_model)  # 解码器词嵌入self.positional_encoding = PositionalEncoding(d_model, max_seq_length)  # 位置编码# 编码器和解码器层self.encoder_layers = nn.ModuleList([EncoderLayer(d_model, num_heads, d_ff, dropout) for _ in range(num_layers)])self.decoder_layers = nn.ModuleList([DecoderLayer(d_model, num_heads, d_ff, dropout) for _ in range(num_layers)])self.fc = nn.Linear(d_model, tgt_vocab_size)  # 最终的全连接层self.dropout = nn.Dropout(dropout)  # Dropoutdef generate_mask(self, src, tgt):# 源掩码：屏蔽填充符（假设填充符索引为0）# 形状：(batch_size, 1, 1, seq_length)src_mask = (src != 0).unsqueeze(1).unsqueeze(2)# 目标掩码：屏蔽填充符和未来信息# 形状：(batch_size, 1, seq_length, 1)tgt_mask = (tgt != 0).unsqueeze(1).unsqueeze(3)seq_length = tgt.size(1)# 生成上三角矩阵掩码，防止解码时看到未来信息nopeak_mask = (1 - torch.triu(torch.ones(1, seq_length, seq_length), diagonal=1)).bool()tgt_mask = tgt_mask & nopeak_mask  # 合并填充掩码和未来信息掩码return src_mask, tgt_maskdef forward(self, src, tgt):# 生成掩码src_mask, tgt_mask = self.generate_mask(src, tgt)# 编码器部分src_embedded = self.dropout(self.positional_encoding(self.encoder_embedding(src)))enc_output = src_embeddedfor enc_layer in self.encoder_layers:enc_output = enc_layer(enc_output, src_mask)# 解码器部分tgt_embedded = self.dropout(self.positional_encoding(self.decoder_embedding(tgt)))dec_output = tgt_embeddedfor dec_layer in self.decoder_layers:dec_output = dec_layer(dec_output, enc_output, src_mask, tgt_mask)# 最终输出output = self.fc(dec_output)return output

# train.py
import re
from model import *
from collections import Counterclass TranslationDataset:def __init__(self, src_file, tgt_file, src_vocab_size=5000, tgt_vocab_size=5000, max_length=100):self.src_file = src_fileself.tgt_file = tgt_fileself.src_vocab_size = src_vocab_sizeself.tgt_vocab_size = tgt_vocab_sizeself.max_length = max_length# 构建词汇表self.src_vocab, self.tgt_vocab = self.build_vocabularies()self.src_data, self.tgt_data = self.load_data()def preprocess_text(self, text):"""预处理文本"""text = text.lower()text = re.sub(r'\s+', ' ', text)text = re.sub(r'([.,!?;:])', r' \1 ', text)text = re.sub(r'\s+', ' ', text)return text.strip()def build_vocabularies(self):"""构建源语言和目标语言的词汇表"""src_sentences = []tgt_sentences = []with open(self.src_file, 'r', encoding='utf-8') as f_src, \open(self.tgt_file, 'r', encoding='utf-8') as f_tgt:src_lines = f_src.readlines()tgt_lines = f_tgt.readlines()for src_line, tgt_line in zip(src_lines, tgt_lines):src_sentences.append(self.preprocess_text(src_line))tgt_sentences.append(self.preprocess_text(tgt_line))# 基于所有句子的词汇src_all_words = []tgt_all_words = []for sentence in src_sentences:src_all_words.extend(sentence.split())for sentence in tgt_sentences:tgt_all_words.extend(sentence.split())# 构建词汇表src_word_counts = Counter(src_all_words)tgt_word_counts = Counter(tgt_all_words)src_vocab = ['<pad>', '<unk>', '<sos>', '<eos>'] + \[word for word, count in src_word_counts.most_common(self.src_vocab_size - 4)]tgt_vocab = ['<pad>', '<unk>', '<sos>', '<eos>'] + \[word for word, count in tgt_word_counts.most_common(self.tgt_vocab_size - 4)]src_word2idx = {word: idx for idx, word in enumerate(src_vocab)}tgt_word2idx = {word: idx for idx, word in enumerate(tgt_vocab)}return src_word2idx, tgt_word2idxdef load_data(self):"""加载并编码数据"""src_sequences = []tgt_sequences = []with open(self.src_file, 'r', encoding='utf-8') as f_src, \open(self.tgt_file, 'r', encoding='utf-8') as f_tgt:src_lines = f_src.readlines()tgt_lines = f_tgt.readlines()for src_line, tgt_line in zip(src_lines, tgt_lines):# 预处理src_line = self.preprocess_text(src_line)tgt_line = self.preprocess_text(tgt_line)# 分词src_words = src_line.split()[:self.max_length - 2]  # 保留位置给<sos>和<eos>tgt_words = tgt_line.split()[:self.max_length - 2]# 编码src_encoded = [self.src_vocab.get('<sos>', 2)] + \[self.src_vocab.get(word, self.src_vocab.get('<unk>', 1)) for word in src_words] + \[self.src_vocab.get('<eos>', 3)]tgt_encoded = [self.tgt_vocab.get('<sos>', 2)] + \[self.tgt_vocab.get(word, self.tgt_vocab.get('<unk>', 1)) for word in tgt_words] + \[self.tgt_vocab.get('<eos>', 3)]# 填充到最大长度src_encoded = self.pad_sequence(src_encoded, self.max_length)tgt_encoded = self.pad_sequence(tgt_encoded, self.max_length)src_sequences.append(src_encoded)tgt_sequences.append(tgt_encoded)return torch.tensor(src_sequences), torch.tensor(tgt_sequences)def pad_sequence(self, sequence, max_length):"""填充序列到指定长度"""if len(sequence) < max_length:sequence = sequence + [0] * (max_length - len(sequence))  # 0是<pad>的索引else:sequence = sequence[:max_length]return sequencedef __len__(self):return len(self.src_data)def __getitem__(self, idx):return self.src_data[idx], self.tgt_data[idx]class TranslationTrainer:def __init__(self, model, dataset, batch_size=32):self.model = modelself.dataset = datasetself.batch_size = batch_sizeself.criterion = nn.CrossEntropyLoss(ignore_index=0)  # 忽略<pad>self.optimizer = optim.Adam(model.parameters(), lr=0.0001, betas=(0.9, 0.98), eps=1e-9)def train(self, epochs):self.model.train()for epoch in range(epochs):total_loss = 0num_batches = 0# 简单的批次处理for i in range(0, len(self.dataset), self.batch_size):batch_src = self.dataset.src_data[i:i + self.batch_size]batch_tgt = self.dataset.tgt_data[i:i + self.batch_size]self.optimizer.zero_grad()# 输入目标序列去掉最后一个词，用于预测下一个词output = self.model(batch_src, batch_tgt[:, :-1])# 计算损失时，目标序列从第二个词开始（即预测下一个词）loss = self.criterion(output.contiguous().view(-1, self.model.fc.out_features),batch_tgt[:, 1:].contiguous().view(-1))loss.backward()self.optimizer.step()total_loss += loss.item()num_batches += 1avg_loss = total_loss / num_batchesprint(f"Epoch {epoch + 1}/{epochs}, Loss: {avg_loss:.6f}")class Translator:def __init__(self, model, src_vocab, tgt_vocab, max_length=100):self.model = modelself.src_vocab = src_vocabself.tgt_vocab = tgt_vocabself.idx2word = {idx: word for word, idx in tgt_vocab.items()}self.max_length = max_lengthself.model.eval()def translate(self, src_sentence):"""翻译单个句子"""# 预处理和编码源句子src_sentence = self.preprocess_text(src_sentence)src_words = src_sentence.split()src_encoded = [self.src_vocab.get('<sos>', 2)] + \[self.src_vocab.get(word, self.src_vocab.get('<unk>', 1)) for word in src_words] + \[self.src_vocab.get('<eos>', 3)]# 填充src_encoded = self.pad_sequence(src_encoded, self.max_length)src_tensor = torch.tensor(src_encoded).unsqueeze(0)  # 添加batch维度# 开始翻译with torch.no_grad():# 初始化目标序列（只有<sos>）tgt_sequence = torch.tensor([[self.tgt_vocab.get('<sos>', 2)]])for i in range(self.max_length - 1):output = self.model(src_tensor, tgt_sequence)# 获取最后一个词的预测next_word_logits = output[0, -1, :]next_word_idx = torch.argmax(next_word_logits).item()# 如果遇到<eos>则停止if next_word_idx == self.tgt_vocab.get('<eos>', 3):break# 将预测的词添加到序列中next_word_tensor = torch.tensor([[next_word_idx]])tgt_sequence = torch.cat([tgt_sequence, next_word_tensor], dim=1)# 解码目标序列translated_words = []for idx in tgt_sequence[0][1:].tolist():  # 跳过<sos>if idx == self.tgt_vocab.get('<eos>', 3):breakword = self.idx2word.get(idx, '<unk>')if word not in ['<sos>', '<eos>', '<pad>']:translated_words.append(word)return ' '.join(translated_words)def preprocess_text(self, text):text = text.lower()text = re.sub(r'\s+', ' ', text)text = re.sub(r'([.,!?;:])', r' \1 ', text)text = re.sub(r'\s+', ' ', text)return text.strip()def pad_sequence(self, sequence, max_length):if len(sequence) < max_length:sequence = sequence + [0] * (max_length - len(sequence))else:sequence = sequence[:max_length]return sequence# 使用示例
def main():# 创建数据集dataset = TranslationDataset(src_file='source.txt',  # 源语言文件tgt_file='target.txt',  # 目标语言文件src_vocab_size=2000,tgt_vocab_size=2000,max_length=50)# 创建模型transformer = Transformer(src_vocab_size=len(dataset.src_vocab),tgt_vocab_size=len(dataset.tgt_vocab),d_model=256,num_heads=4,num_layers=4,d_ff=512,max_seq_length=50,dropout=0.1)# 训练trainer = TranslationTrainer(transformer, dataset, batch_size=32)trainer.train(epochs=25)# 创建翻译器translator = Translator(transformer, dataset.src_vocab, dataset.tgt_vocab,50)# 测试翻译test_sentence1 = "chinese boy"translation1 = translator.translate(test_sentence1)print(f"原文: {test_sentence1}")print(f"翻译: {translation1}")test_sentence2 = "i am chinese"translation2 = translator.translate(test_sentence2)print(f"原文: {test_sentence2}")print(f"翻译: {translation2}")if __name__ == "__main__":main()

以上代码是transformer的代码，通过训练用于翻译任务。

原文: chinese boy
翻译: 是 一个 男孩
原文: i am chinese
翻译: 我 是 中国人

翻译的结果并不好，训练的epoch太小，文本数据量太少，超参数没有进行调整。但是至少代码跑起来了。

source.txt和target.txt放在了gitee

https://gitee.com/diskcache/transformer.git

总结

transformer是一个新的架构，和之前的神经网络都有很大不同，但是效果却是很好，而且可以用于图像处理中，下周将学习transformer用于图像处理。
