MCP模型上下文协议实战：使用TKinter构建桌面AI助手

news 2025/10/4 9:09:49

MCP模型上下文协议实战：使用TKinter构建桌面AI助手

在这里插入图片描述

一、项目概述

在本文中，我们将使用Python的TKinter框架构建一个桌面AI助手应用，并集成MCP（Model Context Protocol）模型上下文协议。这个应用将具备以下功能：

图形化用户界面进行人机对话
智能上下文管理，支持多轮对话
工具调用功能（如计算器、天气查询等）
对话历史保存和会话管理
实时响应显示

二、MCP协议在桌面应用中的价值

对于TKinter桌面应用，MCP协议提供了以下优势：

状态管理：桌面应用需要维护复杂的用户交互状态
离线能力：可以在本地缓存上下文，支持断网续聊
资源优化：减少不必要的API调用，节省token成本
用户体验：提供流畅的多轮对话体验

三、项目结构设计

mcp_tkinter_assistant/
├── main.py                 # 主程序入口
├── mcp_protocol.py         # MCP协议核心实现
├── ai_service.py           # AI服务集成
├── tools.py                # 工具函数集合
├── config.py               # 配置文件
└── assets/                 # 资源文件（图标、样式等）

四、MCP协议核心实现

4.1 MCP上下文数据结构

# mcp_protocol.py
from dataclasses import dataclass, field
from typing import List, Dict, Optional, Any
from enum import Enum
import json
import uuid
from datetime import datetimeclass ContextType(Enum):CHAT = "chat"TASK = "task"SEARCH = "search"@dataclass
class MCPMessage:"""MCP消息结构"""role: str  # "user", "assistant", "system", "tool"content: strtimestamp: datetime = field(default_factory=datetime.now)message_id: str = field(default_factory=lambda: str(uuid.uuid4()))def to_dict(self) -> Dict[str, Any]:return {"role": self.role,"content": self.content,"timestamp": self.timestamp.isoformat(),"message_id": self.message_id}@dataclass
class MCPTool:"""MCP工具定义"""name: strdescription: strparameters: Dict[str, Any]enabled: bool = True@dataclass
class MCPContext:"""MCP上下文协议主结构"""session_id: str = field(default_factory=lambda: str(uuid.uuid4()))user_id: str = "desktop_user"context_type: ContextType = ContextType.CHATmessages: List[MCPMessage] = field(default_factory=list)tools: List[MCPTool] = field(default_factory=list)metadata: Dict[str, Any] = field(default_factory=dict)state: Dict[str, Any] = field(default_factory=dict)created_at: datetime = field(default_factory=datetime.now)updated_at: datetime = field(default_factory=datetime.now)def add_message(self, role: str, content: str):"""添加消息到上下文"""message = MCPMessage(role=role, content=content)self.messages.append(message)self.updated_at = datetime.now()def get_messages_for_llm(self) -> List[Dict[str, str]]:"""获取适合LLM的格式化消息列表"""return [msg.to_dict() for msg in self.messages]def to_dict(self) -> Dict[str, Any]:"""序列化为字典"""return {"session_id": self.session_id,"user_id": self.user_id,"context_type": self.context_type.value,"messages": [msg.to_dict() for msg in self.messages],"tools": [tool.__dict__ for tool in self.tools],"metadata": self.metadata,"state": self.state,"created_at": self.created_at.isoformat(),"updated_at": self.updated_at.isoformat()}

4.2 MCP上下文管理器

# mcp_protocol.py (续)
import os
import pickle
from pathlib import Pathclass MCPContextManager:"""MCP上下文管理器 - 专为桌面应用优化"""def __init__(self, storage_path: str = "contexts"):self.storage_path = Path(storage_path)self.storage_path.mkdir(exist_ok=True)self.current_context: Optional[MCPContext] = Noneself.contexts: Dict[str, MCPContext] = {}self.load_all_contexts()def create_context(self, context_type: ContextType = ContextType.CHAT) -> MCPContext:"""创建新上下文"""context = MCPContext(context_type=context_type)# 添加系统消息context.add_message("system", "你是一个桌面AI助手，帮助用户完成各种任务。你可以使用工具来执行具体操作。")self.contexts[context.session_id] = contextself.current_context = contextself.save_context(context)return contextdef switch_context(self, session_id: str) -> bool:"""切换到指定上下文"""if session_id in self.contexts:self.current_context = self.contexts[session_id]return Truereturn Falsedef get_current_context(self) -> Optional[MCPContext]:"""获取当前上下文"""return self.current_contextdef add_user_message(self, content: str):"""添加用户消息"""if self.current_context:self.current_context.add_message("user", content)self.save_context(self.current_context)def add_assistant_message(self, content: str):"""添加助手消息"""if self.current_context:self.current_context.add_message("assistant", content)self.save_context(self.current_context)def save_context(self, context: MCPContext):"""保存上下文到文件"""filepath = self.storage_path / f"{context.session_id}.pkl"with open(filepath, 'wb') as f:pickle.dump(context, f)def load_context(self, session_id: str) -> Optional[MCPContext]:"""从文件加载上下文"""filepath = self.storage_path / f"{session_id}.pkl"if filepath.exists():with open(filepath, 'rb') as f:context = pickle.load(f)self.contexts[session_id] = contextreturn contextreturn Nonedef load_all_contexts(self):"""加载所有上下文"""for filepath in self.storage_path.glob("*.pkl"):session_id = filepath.stemcontext = self.load_context(session_id)if context:self.contexts[session_id] = contextdef get_context_list(self) -> List[Dict[str, Any]]:"""获取上下文列表用于UI显示"""context_list = []for session_id, context in self.contexts.items():last_message = context.messages[-1].content if context.messages else "新会话"context_list.append({"session_id": session_id,"created_at": context.created_at.strftime("%Y-%m-%d %H:%M"),"last_message": last_message[:50] + "..." if len(last_message) > 50 else last_message,"message_count": len(context.messages)})# 按创建时间倒序排列context_list.sort(key=lambda x: x["created_at"], reverse=True)return context_list

五、AI服务集成

# ai_service.py  国内GLM模型
from zhipuai import ZhipuAI
import json
from typing import List, Dict, Any, Optional
from mcp_protocol import MCPContext, MCPToolclass AIService:"""AI服务封装类 - 使用 GLM-4"""def __init__(self, api_key: str):self.client = ZhipuAI(api_key=api_key)# 定义可用工具（GLM-4 使用与 OpenAI 类似的工具格式）self.available_tools = [MCPTool(name="calculate",description="执行数学计算",parameters={"type": "object","properties": {"expression": {"type": "string", "description": "数学表达式"}},"required": ["expression"]}),MCPTool(name="get_current_time",description="获取当前时间",parameters={"type": "object","properties": {},"required": []})]def process_with_context(self, context: MCPContext) -> Dict[str, Any]:"""使用MCP上下文调用 GLM-4"""try:# 准备消息messages = self._prepare_messages(context)# 准备工具（转换为 GLM-4 支持的格式）tools = self._convert_tools_for_glm()# 调用 GLM-4response = self.client.chat.completions.create(model="glm-4",  # 或 "glm-4-plus"、"glm-4-flash" 等messages=messages,tools=tools if tools else None,tool_choice="auto")# GLM-4 的响应结构与 OpenAI 高度兼容message = response.choices[0].messagereturn {"success": True,"response": {"role": message.role,"content": message.content,"tool_calls": [{"id": tool_call.index,  # GLM 使用 index 作为 ID"function": {"name": tool_call.function.name,"arguments": tool_call.function.arguments}}for tool_call in (message.tool_calls or [])] if message.tool_calls else None},"usage": response.usage}except Exception as e:return {"success": False,"error": str(e)}def _prepare_messages(self, context: MCPContext) -> List[Dict[str, Any]]:"""准备发送给 GLM-4 的消息"""messages = []for msg in context.messages:if msg.role == "tool":# GLM-4 要求工具消息格式为特定结构try:tool_result = json.loads(msg.content)messages.append({"role": "tool","content": json.dumps(tool_result, ensure_ascii=False),"tool_call_id": getattr(msg, 'tool_call_id', 'default_id')})except:# 兜底处理messages.append({"role": "user","content": f"[工具结果] {msg.content}"})else:messages.append({"role": msg.role,"content": msg.content})return messagesdef _convert_tools_for_glm(self) -> List[Dict[str, Any]]:"""将MCP工具转换为 GLM-4 工具格式"""glm_tools = []for tool in self.available_tools:if tool.enabled:glm_tools.append({"type": "function","function": {"name": tool.name,"description": tool.description,"parameters": tool.parameters}})return glm_tools

# ai_service.py  使用openAI大模型
import openai
import json
from typing import List, Dict, Any, Optional
from mcp_protocol import MCPContext, MCPToolclass AIService:"""AI服务封装类"""def __init__(self, api_key: str):self.api_key = api_keyopenai.api_key = api_key# 定义可用工具self.available_tools = [MCPTool(name="calculate",description="执行数学计算",parameters={"type": "object","properties": {"expression": {"type": "string", "description": "数学表达式"}},"required": ["expression"]}),MCPTool(name="get_current_time",description="获取当前时间",parameters={"type": "object","properties": {},"required": []})]def process_with_context(self, context: MCPContext) -> Dict[str, Any]:"""使用MCP上下文处理请求"""try:# 准备消息messages = self._prepare_messages(context)# 准备工具定义（转换为OpenAI格式）tools = self._convert_tools_for_openai()# 调用OpenAI APIresponse = openai.ChatCompletion.create(model="gpt-3.5-turbo",messages=messages,tools=tools if tools else None,tool_choice="auto")return {"success": True,"response": response.choices[0].message,"usage": response.usage}except Exception as e:return {"success": False,"error": str(e)}def _prepare_messages(self, context: MCPContext) -> List[Dict[str, str]]:"""准备发送给LLM的消息"""messages = []for msg in context.messages:messages.append({"role": msg.role,"content": msg.content})return messagesdef _convert_tools_for_openai(self) -> List[Dict[str, Any]]:"""将MCP工具转换为OpenAI工具格式"""openai_tools = []for tool in self.available_tools:if tool.enabled:openai_tools.append({"type": "function","function": {"name": tool.name,"description": tool.description,"parameters": tool.parameters}})return openai_tools

六、工具函数实现

# tools.py
import datetime
import re
from typing import Dict, Anyclass ToolExecutor:"""工具执行器"""@staticmethoddef calculate(expression: str) -> Dict[str, Any]:"""安全的数学计算"""try:# 清理表达式，只允许数字、运算符和括号cleaned_expr = re.sub(r'[^0-9+\-*/().\s]', '', expression)result = eval(cleaned_expr, {"__builtins__": {}}, {})return {"success": True, "result": str(result)}except Exception as e:return {"success": False, "error": f"计算错误: {str(e)}"}@staticmethoddef get_current_time() -> Dict[str, Any]:"""获取当前时间"""now = datetime.datetime.now()return {"success": True,"result": now.strftime("%Y年%m月%d日 %H:%M:%S")}@staticmethoddef execute_tool(tool_name: str, arguments: Dict[str, Any]) -> Dict[str, Any]:"""执行指定工具"""if tool_name == "calculate":return ToolExecutor.calculate(arguments.get("expression", ""))elif tool_name == "get_current_time":return ToolExecutor.get_current_time()else:return {"success": False, "error": f"未知工具: {tool_name}"}

七、TKinter界面实现

7.1 主窗口类

# main.py
import tkinter as tk
from tkinter import ttk, scrolledtext, messagebox
import threading
import json
from mcp_protocol import MCPContextManager, ContextType
from ai_service import AIService
from tools import ToolExecutor
import osclass MCPDesktopAssistant:"""MCP桌面AI助手主窗口"""def __init__(self, root):self.root = rootself.root.title("MCP桌面AI助手")self.root.geometry("800x600")self.root.minsize(600, 400)# 初始化服务api_key = os.getenv("OPENAI_API_KEY")if not api_key:api_key = self._get_api_key_from_user()if not api_key:messagebox.showerror("错误", "需要OpenAI API密钥才能使用")root.quit()returnself.context_manager = MCPContextManager()self.ai_service = AIService(api_key)self.tool_executor = ToolExecutor()# 创建当前上下文self.context_manager.create_context(ContextType.CHAT)# 创建UIself._create_ui()# 绑定事件self.root.protocol("WM_DELETE_WINDOW", self._on_closing)def _get_api_key_from_user(self) -> str:"""从用户获取API密钥"""dialog = tk.Toplevel(self.root)dialog.title("输入API密钥")dialog.geometry("400x150")dialog.transient(self.root)dialog.grab_set()tk.Label(dialog, text="请输入OpenAI API密钥:").pack(pady=10)api_key_var = tk.StringVar()entry = tk.Entry(dialog, textvariable=api_key_var, width=50, show="*")entry.pack(pady=5)def on_ok():dialog.result = api_key_var.get()dialog.destroy()def on_cancel():dialog.result = ""dialog.destroy()button_frame = tk.Frame(dialog)button_frame.pack(pady=10)tk.Button(button_frame, text="确定", command=on_ok).pack(side=tk.LEFT, padx=5)tk.Button(button_frame, text="取消", command=on_cancel).pack(side=tk.LEFT, padx=5)self.root.wait_window(dialog)return getattr(dialog, 'result', "")def _create_ui(self):"""创建用户界面"""# 创建主框架main_frame = ttk.Frame(self.root)main_frame.pack(fill=tk.BOTH, expand=True, padx=10, pady=10)# 创建左侧会话列表left_frame = ttk.Frame(main_frame, width=200)left_frame.pack(side=tk.LEFT, fill=tk.Y, padx=(0, 10))left_frame.pack_propagate(False)# 会话列表标题ttk.Label(left_frame, text="会话历史", font=("Arial", 12, "bold")).pack(pady=(0, 10))# 会话列表self.session_listbox = tk.Listbox(left_frame, height=15)self.session_listbox.pack(fill=tk.BOTH, expand=True)self.session_listbox.bind('<<ListboxSelect>>', self._on_session_select)# 新会话按钮ttk.Button(left_frame, text="新会话", command=self._new_session).pack(pady=10)# 创建右侧聊天区域right_frame = ttk.Frame(main_frame)right_frame.pack(side=tk.RIGHT, fill=tk.BOTH, expand=True)# 聊天显示区域self.chat_display = scrolledtext.ScrolledText(right_frame, wrap=tk.WORD, state=tk.DISABLED,font=("Arial", 10))self.chat_display.pack(fill=tk.BOTH, expand=True, pady=(0, 10))# 输入区域input_frame = ttk.Frame(right_frame)input_frame.pack(fill=tk.X)self.user_input = tk.Text(input_frame, height=3, font=("Arial", 10))self.user_input.pack(side=tk.LEFT, fill=tk.X, expand=True, padx=(0, 10))self.user_input.bind("<Return>", self._on_enter_pressed)self.user_input.bind("<Shift-Return>", lambda e: self.user_input.insert(tk.INSERT, "\n"))send_button = ttk.Button(input_frame, text="发送", command=self._send_message)send_button.pack(side=tk.RIGHT)# 加载会话列表self._load_session_list()self._display_current_chat()def _load_session_list(self):"""加载会话列表"""self.session_listbox.delete(0, tk.END)contexts = self.context_manager.get_context_list()for i, ctx in enumerate(contexts):display_text = f"{ctx['created_at']} - {ctx['last_message']}"self.session_listbox.insert(tk.END, display_text)# 选中当前会话if self.context_manager.current_context and ctx['session_id'] == self.context_manager.current_context.session_id:self.session_listbox.selection_set(i)def _new_session(self):"""创建新会话"""self.context_manager.create_context(ContextType.CHAT)self._load_session_list()self._display_current_chat()def _on_session_select(self, event):"""会话选择事件"""selection = self.session_listbox.curselection()if selection:index = selection[0]contexts = self.context_manager.get_context_list()if index < len(contexts):session_id = contexts[index]['session_id']self.context_manager.switch_context(session_id)self._display_current_chat()def _display_current_chat(self):"""显示当前聊天内容"""self.chat_display.config(state=tk.NORMAL)self.chat_display.delete(1.0, tk.END)context = self.context_manager.get_current_context()if context:for message in context.messages:if message.role == "user":self._add_message_to_display("👤 用户", message.content, "blue")elif message.role == "assistant":self._add_message_to_display("🤖 助手", message.content, "green")elif message.role == "tool":self._add_message_to_display("🔧 工具", message.content, "purple")self.chat_display.config(state=tk.DISABLED)self.chat_display.see(tk.END)def _add_message_to_display(self, sender: str, content: str, color: str):"""添加消息到显示区域"""self.chat_display.insert(tk.END, f"{sender}: {content}\n\n")# 这里可以添加颜色标签，简化起见使用默认颜色def _on_enter_pressed(self, event):"""回车键发送消息"""if not event.state & 0x1:  # 没有Shift键self._send_message()return "break"  # 阻止默认换行def _send_message(self):"""发送消息"""user_message = self.user_input.get(1.0, tk.END).strip()if not user_message:return# 清空输入框self.user_input.delete(1.0, tk.END)# 添加用户消息到上下文self.context_manager.add_user_message(user_message)self._display_current_chat()# 在新线程中处理AI响应（避免UI阻塞）threading.Thread(target=self._process_ai_response, args=(user_message,), daemon=True).start()def _process_ai_response(self, user_message: str):"""处理AI响应（在后台线程中执行）"""try:# 获取当前上下文context = self.context_manager.get_current_context()if not context:return# 调用AI服务result = self.ai_service.process_with_context(context)if result["success"]:response_message = result["response"]# 检查是否有工具调用if response_message.get("tool_calls"):# 执行工具调用tool_results = []for tool_call in response_message["tool_calls"]:tool_name = tool_call["function"]["name"]arguments = json.loads(tool_call["function"]["arguments"])tool_result = self.tool_executor.execute_tool(tool_name, arguments)tool_results.append({"tool_call_id": tool_call["id"],"role": "tool","name": tool_name,"content": json.dumps(tool_result)})# 将工具结果添加到上下文for tool_result in tool_results:self.context_manager.current_context.messages.append(type('obj', (object,), {'role': tool_result['role'],'content': tool_result['content'],'timestamp': datetime.datetime.now(),'message_id': str(uuid.uuid4())})())# 再次调用AI获取最终响应final_result = self.ai_service.process_with_context(context)if final_result["success"]:final_response = final_result["response"]assistant_content = final_response.get("content", "")else:assistant_content = "处理工具调用时发生错误。"else:assistant_content = response_message.get("content", "")# 更新UIself.root.after(0, self._update_ui_with_response, assistant_content)else:error_msg = f"AI服务错误: {result['error']}"self.root.after(0, self._update_ui_with_response, error_msg)except Exception as e:error_msg = f"处理消息时发生错误: {str(e)}"self.root.after(0, self._update_ui_with_response, error_msg)def _update_ui_with_response(self, response: str):"""在主线程中更新UI"""self.context_manager.add_assistant_message(response)self._display_current_chat()self._load_session_list()  # 更新会话列表def _on_closing(self):"""窗口关闭事件"""if messagebox.askokcancel("退出", "确定要退出MCP桌面AI助手吗？"):self.root.destroy()def main():root = tk.Tk()app = MCPDesktopAssistant(root)root.mainloop()if __name__ == "__main__":main()

7.2 配置文件

# config.py
import os
from pathlib import Pathclass Config:"""配置类"""# API配置OPENAI_API_KEY = os.getenv("OPENAI_API_KEY", "")# 路径配置CONTEXT_STORAGE_PATH = "mcp_contexts"LOG_PATH = "logs"# 应用配置WINDOW_WIDTH = 800WINDOW_HEIGHT = 600MAX_CONTEXT_MESSAGES = 20  # 最大上下文消息数@classmethoddef ensure_directories(cls):"""确保必要目录存在"""Path(cls.CONTEXT_STORAGE_PATH).mkdir(exist_ok=True)Path(cls.LOG_PATH).mkdir(exist_ok=True)

八、使用说明

8.1 环境准备

# 安装依赖
pip install openai #选用国外模型
pip install zhipuai #选用国内模型# 设置环境变量（可选）
export OPENAI_API_KEY="your-api-key-here"
export ZHIPU_API_KEY="your-api-key-here"
