SpringBoot实现简单图形验证码
项目场景：
为防止验证系统被暴力破解，很多系统都增加了验证码效验，业内比较安全的是短信验证码，图形验证码是最传统且应用最广泛的验证码类型，原理是在服务端生成随机字符串并渲染成图片，用户需要识别图片中的字符并输入。图形验证码实现简单，对用户体验影响较小，是中小型应用的理想选择。
实现步骤
需要集成redis，用于记录验证码的id
核心代码CodeUtil：
package com.test.utils;import com.test.constant.CommonConstant;
import com.test.form.CaptchaVo;
import lombok.Cleanup;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.data.redis.core.RedisTemplate;
import org.springframework.stereotype.Service;
import sun.misc.BASE64Encoder;import javax.imageio.ImageIO;
import javax.servlet.http.HttpServletResponse;
import java.awt.*;
import java.awt.image.BufferedImage;
import java.io.ByteArrayOutputStream;
import java.util.Random;
import java.util.UUID;
import java.util.concurrent.TimeUnit;@Service
}
Controller验证：
package com.test.controller;import com.google.code.kaptcha.Producer;
import com.test.utils.CodeUtil;
import com.test.utils.Result;
import io.swagger.annotations.Api;
import io.swagger.annotations.ApiOperation;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;
import sun.misc.BASE64Encoder;import javax.imageio.ImageIO;
import javax.servlet.ServletOutputStream;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import java.awt.image.BufferedImage;
import java.io.ByteArrayOutputStream;
import java.io.IOException;
import java.util.UUID;@RestController
@Api(tags = "验证码接口")
@RequestMapping("/captcha")
public class CaptchaController {@Autowiredprivate CodeUtil codeUtil;@ApiOperation(value = "登录")@GetMapping("/login")public Result<?> login(String captcha, String captchaKey, HttpServletRequest request) {// 验证验证码if (!codeUtil.validateCaptcha(captchaKey, captcha)) {return Result.error("验证码错误或已过期");}return Result.ok("登录成功");}@ApiOperation(value = "获取验证码")@GetMapping("/image")public Result<?> getImageCaptcha2(HttpServletResponse response, HttpServletRequest request) throws IOException {return Result.ok(codeUtil.getRandcode(response));}}
效果截图：
把base64转图片：
主要逻辑：
实际使用把获取到的base64设置到图片src属性里
<img src="base64的值" alt="验证码（点击刷新）" >登录时，把获取到的随机字符和验证码一块提交。
这里是用的原生代码写的，也可以依赖第三方库实现：
