WinForm中实现Adobe PDF Reader实现旋转PDF功能

news 来源：原创 2025/6/13 8:22:57

实现效果：

PDF旋转功能

回到顶部

问题点：Adobe PDF Reader中并没有可以直接旋转的方法

LoadFile	加载文件,文件URL地址
GotoFirstPage	到第一页
GotoLastPage	到最后一页
GotoPreviousPage	上一页
GotoNextPape	下一页
SetCurrentpage	到指定页
Setshowscrollbars	设置是否显示 Acrobat Reader的滚动条。带一个参数,该参数设为0时不显示滚动条,设为1时显示滚动条
SetshowToolbar	设置是否显示 Acrobat Reader的工具栏。带一个参数,该参数设为时不显示,设为1时显示。
Setview	设置显示效果。Fit：适应窗口大小； FitH：适合宽度
setZoom	设置文件的显示比例；默认是100

回到顶部

解决办法：引入PdfiumViewer旋转PDF并保存替换当前的文件。

<span style="color:#333333"><span style="background-color:#ffffff"><code class="language-c language-c#">		 <span style="color:#008000">/// <summary></span><span style="color:#008000">/// 旋转保存PDF文件并释放文件锁定</span><span style="color:#008000">/// </summary></span><span style="color:#008000">/// <param name="axControl"></param></span><span style="color:#008000">/// <param name="filePath"></param></span><span style="color:#008000">/// <param name="pdfRotation"></param></span><span style="color:#008000">/// <returns></returns>    </span>
public <span style="color:#a31515">bool</span> <span style="color:#a31515">SafeSavePdfWithRelease</span>(AxAcroPDFLib.AxAcroPDF axControl, <span style="color:#0000ff">string</span> filePath, PdfRotation pdfRotation){<span style="color:#a31515">const</span> <span style="color:#a31515">int</span> MAX_RETRY = <span style="color:#880000">3</span>;<span style="color:#a31515">const</span> <span style="color:#a31515">int</span> RETRY_DELAY = <span style="color:#880000">500</span>;<span style="color:#0000ff">for</span> (<span style="color:#a31515">int</span> attempt = <span style="color:#880000">0</span>; attempt < MAX_RETRY; attempt++){try{<span style="color:#008000">// 步骤1：创建临时副本</span><span style="color:#0000ff">string</span> tempPath = Path.GetTempFileName().Replace(<span style="color:#a31515">".tmp"</span>, <span style="color:#a31515">".pdf"</span>);File.Copy(filePath, tempPath, <span style="color:#a31515">true</span>);<span style="color:#008000">// 步骤2：使用内存流操作</span>using (var ms = new MemoryStream(File.ReadAllBytes(tempPath)))using (var document = PdfiumViewer.PdfDocument.Load(ms)){<span style="color:#0000ff">for</span> (<span style="color:#a31515">int</span> pageIndex = <span style="color:#880000">0</span>; pageIndex < document.PageCount; pageIndex++){document.RotatePage(pageIndex, pdfRotation);<span style="color:#008000">// 可选：验证旋转结果</span><span style="color:#008000">// var currentRotation = document.Pages[pageIndex].Rotation;</span><span style="color:#008000">// Debug.Assert(currentRotation == (int)rotation);</span>}<span style="color:#008000">// 执行修改操作（示例：旋转第一页）</span><span style="color:#008000">//document.RotatePage(1, PdfRotation.Rotate90);</span><span style="color:#008000">// 步骤3：保存到临时文件</span>byte[] pdfBytes;using (var outputStream = new MemoryStream()){document.Save(outputStream);pdfBytes = outputStream.ToArray();}<span style="color:#008000">// 步骤4：强制释放文件锁定</span>ForceReleasePdfFile(axControl, filePath);<span style="color:#008000">// 步骤5：原子替换文件</span>File.WriteAllBytes(tempPath, pdfBytes);<span style="color:#008000">// File.Replace(tempPath, filePath, null, true);</span><span style="color:#008000">// 1. 复制替换文件到目标路径</span>File.Copy(tempPath, filePath, overwrite: <span style="color:#a31515">true</span>);<span style="color:#008000">// 2. 删除临时文件（可选）</span>File.Delete(tempPath);<span style="color:#008000">// 步骤6：验证加载</span>axControl.LoadFile(filePath);<span style="color:#0000ff">return</span> <span style="color:#a31515">true</span>;}}catch (IOException ex) when (ex.HResult == <span style="color:#880000">-2147024864</span>){<span style="color:#0000ff">if</span> (attempt == MAX_RETRY - <span style="color:#880000">1</span>) throw;Thread.Sleep(RETRY_DELAY);}}<span style="color:#0000ff">return</span> <span style="color:#a31515">false</span>;}public <span style="color:#a31515">void</span> <span style="color:#a31515">ForceReleasePdfFile</span>(AxAcroPDFLib.AxAcroPDF axControl, <span style="color:#0000ff">string</span> filePath){<span style="color:#008000">// 步骤1：深度释放COM对象</span>ReleaseComObject(axControl);<span style="color:#008000">// 步骤2：内核级文件解锁</span>UnlockFileHandle(filePath);<span style="color:#008000">// 步骤3：延迟重载验证</span>Thread.Sleep(<span style="color:#880000">200</span>);axControl.LoadFile(filePath);}private <span style="color:#a31515">void</span> <span style="color:#a31515">ReleaseComObject</span>(AxAcroPDFLib.AxAcroPDF axControl){try{<span style="color:#008000">// 显式释放ActiveX资源</span><span style="color:#0000ff">if</span> (axControl.IsDisposed) <span style="color:#0000ff">return</span>;<span style="color:#008000">// 反射调用内部释放方法</span>var type = axControl.GetType();var method = type.GetMethod(<span style="color:#a31515">"ReleaseOCX"</span>, BindingFlags.Instance | BindingFlags.NonPublic);method?.Invoke(axControl, null);<span style="color:#008000">// 强制垃圾回收</span>GC.Collect();GC.WaitForPendingFinalizers();}catch (Exception ex){}}<span style="color:#008000">// 修改后的P/Invoke声明</span>[DllImport(<span style="color:#a31515">"kernel32.dll"</span>, SetLastError = <span style="color:#a31515">true</span>, CharSet = CharSet.Auto)]private <span style="color:#a31515">static</span> <span style="color:#0000ff">extern</span> IntPtr <span style="color:#a31515">CreateFile</span>(<span style="color:#0000ff">string</span> lpFileName,uint dwDesiredAccess,uint dwShareMode,IntPtr lpSecurityAttributes,FileMode dwCreationDisposition,  <span style="color:#008000">// 改用.NET枚举</span>FileAttributes dwFlagsAndAttributes,  <span style="color:#008000">// 改用.NET枚举</span>IntPtr hTemplateFile);<span style="color:#008000">// 修改后的UnlockFileHandle方法</span>private <span style="color:#a31515">void</span> <span style="color:#a31515">UnlockFileHandle</span>(<span style="color:#0000ff">string</span> filePath){<span style="color:#a31515">const</span> uint FILE_SHARE_READ = <span style="color:#880000">0x00000001</span>;<span style="color:#a31515">const</span> uint FILE_SHARE_WRITE = <span style="color:#880000">0x00000002</span>;<span style="color:#a31515">const</span> uint GENERIC_READ = <span style="color:#880000">0x80000000</span>;IntPtr hFile = CreateFile(filePath,GENERIC_READ,FILE_SHARE_READ | FILE_SHARE_WRITE,IntPtr.Zero,FileMode.Open,  <span style="color:#008000">// 对应原生OPEN_EXISTING</span>FileAttributes.Normal,  <span style="color:#008000">// 对应原生FILE_ATTRIBUTE_NORMAL</span>IntPtr.Zero);<span style="color:#0000ff">if</span> (hFile != IntPtr.Zero && hFile != new IntPtr(<span style="color:#880000">-1</span>)){CloseHandle(hFile);}}[DllImport(<span style="color:#a31515">"kernel32.dll"</span>, SetLastError = <span style="color:#a31515">true</span>)][<span style="color:#0000ff">return</span>: MarshalAs(UnmanagedType.Bool)]private <span style="color:#a31515">static</span> <span style="color:#0000ff">extern</span> <span style="color:#a31515">bool</span> CloseHandle(IntPtr hObject);`
</code></span></span>

调用代码：

<span style="color:#333333"><span style="background-color:#ffffff"><code class="language-C language-C#">		  <span style="color:#008000">/// <summary></span><span style="color:#008000">/// 当前旋转角度</span><span style="color:#008000">/// </summary></span>public <span style="color:#a31515">static</span> <span style="color:#a31515">int</span> currentRotation = <span style="color:#880000">0</span>;<span style="color:#008000">/// <summary></span><span style="color:#008000">/// 逆时针旋转</span><span style="color:#008000">/// </summary></span><span style="color:#008000">/// <param name="sender"></param></span><span style="color:#008000">/// <param name="e"></param></span>private <span style="color:#a31515">void</span> <span style="color:#a31515">pictureEdit3_Click</span>(object sender, EventArgs e){<span style="color:#0000ff">if</span> (axAcroPDF1.Visible){currentRotation -= <span style="color:#880000">90</span>; PdfRotation pdfRotation = GetCounterClockwiseRotation(currentRotation);var path = axAcroPDF1.src;<span style="color:#008000">//调用旋转PDF保存方法</span>SafeSavePdfWithRelease(axAcroPDF1, path,pdfRotation); axAcroPDF1.LoadFile(path);axAcroPDF1.setView(<span style="color:#a31515">"Fit"</span>); <span style="color:#008000">//适应窗口大小</span>}}<span style="color:#008000">/// <summary></span><span style="color:#008000">/// 顺时针旋转</span><span style="color:#008000">/// </summary></span><span style="color:#008000">/// <param name="sender"></param></span><span style="color:#008000">/// <param name="e"></param></span>private <span style="color:#a31515">void</span> <span style="color:#a31515">pictureEdit2_Click</span>(object sender, EventArgs e){<span style="color:#0000ff">if</span> (axAcroPDF1.Visible){currentRotation += <span style="color:#880000">90</span>; PdfRotation pdfRotation = GetCounterClockwiseRotation(currentRotation);var path = axAcroPDF1.src;<span style="color:#008000">//调用旋转PDF保存方法</span>SafeSavePdfWithRelease(axAcroPDF1, path, pdfRotation);axAcroPDF1.LoadFile(path);axAcroPDF1.setView(<span style="color:#a31515">"Fit"</span>); <span style="color:#008000">//适应窗口大小 </span>}}<span style="color:#008000">/// <summary></span><span style="color:#008000">/// 通过旋转度数计算旋转的角度</span><span style="color:#008000">/// </summary></span><span style="color:#008000">/// <param name="counterClockwiseDegrees">当前旋转角度</param></span>public <span style="color:#a31515">static</span> PdfRotation <span style="color:#a31515">GetCounterClockwiseRotation</span>(<span style="color:#a31515">int</span> counterClockwiseDegrees){<span style="color:#a31515">const</span> <span style="color:#a31515">int</span> fullCircle = <span style="color:#880000">360</span>;<span style="color:#a31515">int</span> effectiveDegrees = counterClockwiseDegrees % fullCircle;<span style="color:#0000ff">if</span> (effectiveDegrees < <span style="color:#880000">0</span>) effectiveDegrees += fullCircle; <span style="color:#008000">// 处理负角度</span><span style="color:#0000ff">if</span> (currentRotation >= <span style="color:#880000">360</span>) {currentRotation = <span style="color:#880000">0</span>;}<span style="color:#0000ff">if</span> (currentRotation <= <span style="color:#880000">-360</span>) {currentRotation = <span style="color:#880000">0</span>;}<span style="color:#0000ff">switch</span> (effectiveDegrees){<span style="color:#0000ff">case</span> <span style="color:#880000">90</span>:<span style="color:#0000ff">return</span> PdfRotation.Rotate90; <span style="color:#0000ff">case</span> <span style="color:#880000">180</span>:<span style="color:#0000ff">return</span> PdfRotation.Rotate180;<span style="color:#0000ff">case</span> <span style="color:#880000">270</span>:<span style="color:#0000ff">return</span> PdfRotation.Rotate270;<span style="color:#0000ff">case</span> <span style="color:#880000">0</span>:<span style="color:#0000ff">default</span>:<span style="color:#0000ff">return</span> PdfRotation.Rotate0;}}<span style="color:#008000">/// <summary></span>
</code></span></span>
