html5+css3实现傅里叶变换的动态展示效果(仅供参考)
<!DOCTYPE html>
<html lang="zh-CN">
<head><meta charset="UTF-8"><meta name="viewport" content="width=device-width, initial-scale=1.0"><title>傅里叶变换的动态展示效果</title><style>body {font-family: 'Microsoft YaHei', Arial, sans-serif;margin: 0;padding: 0;background: #f8f9fa;color: #333;}.container {max-width: 1200px;margin: 0 auto;padding: 20px;}h1 {text-align: center;color: #2c3e50;margin-bottom: 30px;}.controls {display: flex;flex-wrap: wrap;gap: 20px;justify-content: center;margin-bottom: 30px;background: #fff;padding: 20px;border-radius: 8px;box-shadow: 0 2px 10px rgba(0, 0, 0, 0.1);}.control-group {display: flex;flex-direction: column;min-width: 200px;}label {margin-bottom: 5px;font-weight: bold;}input[type="range"], select {width: 100%;padding: 8px;border: 1px solid #ddd;border-radius: 4px;}button {background: #3498db;color: white;border: none;padding: 10px 20px;border-radius: 4px;cursor: pointer;font-size: 16px;transition: background-color 0.3s;}button:hover {background: #2980b9;}.visualization {display: flex;flex-wrap: wrap;gap: 20px;justify-content: center;}.canvas-container {background: #fff;padding: 20px;border-radius: 8px;box-shadow: 0 2px 10px rgba(0, 0, 0, 0.1);flex: 1;min-width: 300px;}canvas {width: 100%;height: 300px;background: #f1f1f1;border-radius: 4px;}.explanation {margin-top: 30px;background: #fff;padding: 20px;border-radius: 8px;box-shadow: 0 2px 10px rgba(0, 0, 0, 0.1);}.formula {font-family: 'Cambria Math', serif;text-align: center;margin: 20px 0;font-size: 18px;}.loading {display: none;text-align: center;margin: 20px 0;}.loading img {width: 50px;height: 50px;}@media (max-width: 768px) {.canvas-container {min-width: 100%;}}</style>
</head>
</body>
</html>
仅供参考，我也不懂数学。
傅里叶变换是一种将时域信号转换为频域表示的数学工具。它可以将任何周期性的函数分解为简单正弦波的叠加。
离散傅里叶变换 (DFT)：
X(k) = Σ[n=0 to N-1] x(n) · e-j2πkn/N
傅里叶级数：
f(t) = a0/2 + Σ[n=1 to ∞] [ancos(nωt) + bnsin(nωt)]
在这个演示中，您可以通过控制面板选择不同的波形，并观察其傅里叶变换结果。傅里叶变换让我们能够看到波形中包含的各种频率成分及其振幅和相位。
