c++ 表格控件 UltimateGrid 控件实例

news 2025/9/6 16:34:50

控件区域：

使用效果：

代码如下：
void MyUGCtrl::OnSetup()
{
m_nButtonIndex = AddCellType(&m_button);

SetNumberCols(6);
AppendRow();

   CUGCell cell;
   int rows, cols;
   int row = 0;

   // 头部
   int nHeaderRow = -1;
   {
       QuickSetText(0, nHeaderRow, L"Button");
       QuickSetAlignment(0, nHeaderRow, UG_ALIGNCENTER | UG_ALIGNVCENTER);

QuickSetText(1, nHeaderRow, L"Text");
QuickSetAlignment(1, nHeaderRow, UG_ALIGNCENTER | UG_ALIGNVCENTER);

QuickSetText(2, nHeaderRow, L"CheckBox");
QuickSetAlignment(2, nHeaderRow, UG_ALIGNCENTER | UG_ALIGNVCENTER);

       QuickSetText(3, nHeaderRow, L"RadioButton");
       QuickSetAlignment(3, nHeaderRow, UG_ALIGNCENTER | UG_ALIGNVCENTER);
       SetRowHeight(nHeaderRow, 80);

QuickSetText(4, nHeaderRow, L"SpinButton");
QuickSetAlignment(4, nHeaderRow, UG_ALIGNCENTER | UG_ALIGNVCENTER);

       QuickSetText(5, nHeaderRow, L"DateTime");
       QuickSetAlignment(5, nHeaderRow, UG_ALIGNCENTER | UG_ALIGNVCENTER);
   }

   //button
   {
       GetCell(0, 0, &cell);
       cell.SetText(L"Button");
       cell.SetCellType(m_nButtonIndex);
       cell.SetCellTypeEx(UGCT_BUTTONNOFOCUS);
       cell.SetAlignment(UG_ALIGNCENTER | UG_ALIGNVCENTER);
       cell.SetTextColor(RGB(0, 0, 128));
       cell.SetBackColor(GetSysColor(COLOR_BTNFACE));
       SetCell(0, 0, &cell);
       SetRowHeight(0, 60);
   }

   //文本
   {
       QuickSetText(1, 0, L"Text");
       QuickSetAlignment(1, 0, UG_ALIGNCENTER | UG_ALIGNVCENTER);
   }

   // checkbox
   {
       QuickSetCellType(2, 0, UGCT_CHECKBOX);
       QuickSetCellTypeEx(2, 0, UGCT_CHECKBOXCHECKMARK /*| UGCT_CHECKBOX3DRAISED | UGCT_CHECKBOX3STATE*/);
       QuickSetBackColor(2, 0, GetSysColor(COLOR_BTNFACE));
       QuickSetLabelText(2, 0, L"Checkbox");
       QuickSetAlignment(2, 0, UG_ALIGNCENTER | UG_ALIGNVCENTER);
   }

   // radiobutton
   m_nRadioIndex = AddCellType(&m_radio);
   {
       cell.ClearAll();
       GetCell(3, 0, &cell);
       cell.SetLabelText(L"One\nTwo\n");
       cell.SetCellType(m_nRadioIndex);
       SetCell(3, 0, &cell);
       QuickSetAlignment(3, 0, UG_ALIGNCENTER | UG_ALIGNVCENTER);
   }

   // SpinButton
   m_nSpinIndex = AddCellType(&m_spin);
   {
       cell.ClearAll();
       GetCell(4, 0, &cell);
       cell.SetText(L"1");
       cell.SetCellType(m_nSpinIndex);
       cell.SetParam(SPIN_TYPE1);
       SetCell(4, 0, &cell);
       QuickSetAlignment(4, 0, UG_ALIGNCENTER | UG_ALIGNVCENTER);
   }

   //DateTime
   m_nDateTimeIndex = AddCellType(&m_dateTime);
   {
       cell.ClearAll();
       GetCell(5, 0, &cell);
       cell.SetText(COleDateTime::GetCurrentTime().Format(VAR_DATEVALUEONLY));
       cell.SetCellType(m_nDateTimeIndex);
       SetCell(5, 0, &cell);
       QuickSetAlignment(5, 0, UG_ALIGNCENTER | UG_ALIGNVCENTER);
   }
}
