Java条码与二维码生成技术详解

news 来源：原创 2025/5/10 8:06:36

一、技术选型分析

1.1 条码生成方案

Barbecue是最成熟的Java条码库，支持：

Code 128
EAN-13/UPC-A
USPS Inteligent Mail
等12种工业标准格式

1.2 二维码方案对比

库名称	维护状态	复杂度	功能扩展性
ZXing	★★★★☆	较高	强
QRGen	★★★☆☆	简单	一般
BoofCV	★★☆☆☆	复杂	强

二、环境准备

2.1 Maven依赖

<!-- 条码生成 -->
<dependency>
    <groupId>net.sf.barbecue</groupId>
    <artifactId>barbecue</artifactId>
    <version>1.5-beta1</version>
</dependency>

<!-- 二维码核心库 -->
<dependency>
    <groupId>com.google.zxing</groupId>
    <artifactId>core</artifactId>
    <version>3.4.1</version>
</dependency>

<!-- 二维码图形生成 -->
<dependency>
    <groupId>com.google.zxing</groupId>
    <artifactId>javase</artifactId>
    <version>3.4.1</version>
</dependency>

<!-- QRGen简化封装 -->
<dependency>
    <groupId>net.glxn</groupId>
    <artifactId>qrgen</artifactId>
    <version>2.0</version>
</dependency>

三、条码生成实战

3.1 Code 128基础生成

public static void generateCode128(String data, File outputFile)
        throws BarcodeException, IOException {

    Barcode barcode = BarcodeFactory.createCode128(data);
    barcode.setResolution(300); // 设置DPI

    // 设置尺寸策略
    barcode.setBarWidth(2);
    barcode.setBarHeight(50);

    // 添加文本标签
    barcode.setDrawingText(true);
    barcode.setFont(new Font("Arial", Font.PLAIN, 12));

    BarcodeImageHandler.savePNG(barcode, outputFile);
}

3.2 物流条码生成示例（Inteligent Mail）

public static void generateInteligentMail(String routingCode, File output)
        throws Exception {

    IntelligentMailBarcode imb = new IntelligentMailBarcode(
        routingCode,    // 路由编码
        "9405511042",  // 跟踪号
        "1234"          // 服务类型代码
    );

    imb.setHumanReadableTextPosition(Barcode.HUMAN_READABLE_BOTTOM);
    imb.setBarHeight(40);

    BufferedImage image = new BufferedImage(
        300, 60, BufferedImage.TYPE_BYTE_BINARY);
    imb.draw(image.createGraphics(), new Point(10, 10));

    ImageIO.write(image, "PNG", output);
}

四、二维码高级应用

4.1 ZXing基础生成

public static void generateQRWithZXing(String content, int width, int height, File file)
        throws WriterException, IOException {

    Map<EncodeHintType, Object> hints = new EnumMap<>(EncodeHintType.class);
    hints.put(EncodeHintType.CHARACTER_SET, "UTF-8");
    hints.put(EncodeHintType.ERROR_CORRECTION, ErrorCorrectionLevel.H); // 30%容错
    hints.put(EncodeHintType.MARGIN, 2); // 边距

    BitMatrix matrix = new MultiFormatWriter()
        .encode(content, BarcodeFormat.QR_CODE, width, height, hints);

    MatrixToImageWriter.writeToPath(
        matrix,
        "PNG",
        file.toPath(),
        new MatrixToImageConfig(0xFF000000, 0xFFFFFFFF) // 自定义颜色
    );
}

4.2 带Logo的复杂二维码

public static void generateQRWithLogo(String content, File logoFile, File output)
        throws Exception {

    // 生成基础二维码
    BufferedImage qrImage = MatrixToImageWriter.toBufferedImage(
        new QRCodeWriter().encode(
            content,
            BarcodeFormat.QR_CODE,
            400, 400,
            Collections.singletonMap(EncodeHintType.MARGIN, 1)
        )
    );

    // 添加Logo
    BufferedImage logo = ImageIO.read(logoFile);
    Graphics2D graphics = qrImage.createGraphics();
    int logoSize = qrImage.getWidth() / 5;
    int x = (qrImage.getWidth() - logoSize) / 2;
    int y = (qrImage.getHeight() - logoSize) / 2;
    graphics.drawImage(logo, x, y, logoSize, logoSize, null);

    // 添加抗锯齿效果
    graphics.setRenderingHint(
        RenderingHints.KEY_ANTIALIASING,
        RenderingHints.VALUE_ANTIALIAS_ON
    );

    graphics.dispose();
    ImageIO.write(qrImage, "PNG", output);
}

五、性能优化建议

对象复用：频繁生成时复用BarcodeFactory实例
异步生成：使用CompletableFuture实现并行生成
缓存策略：对固定内容条码进行内存缓存
分辨率控制：根据输出介质动态调整DPI
- 屏幕显示：72-96 DPI
- 打印输出：300+ DPI

六、异常处理最佳实践

public void safeGenerateQR(String content) {
    try {
        // 生成逻辑...
    } catch (WriterException e) {
        logger.error("内容编码失败: {}", e.getMessage());
        if (e.getMessage().contains("Contents length")) {
            throw new IllegalArgumentException("输入内容过长");
        }
    } catch (IOException e) {
        logger.error("IO异常: {}", e.getMessage());
        throw new RuntimeException("文件保存失败");
    } finally {
        // 清理临时资源
    }
}

七、扩展功能实现

7.1 生成彩色二维码

public static void generateColorQR() throws Exception {
    Map<EncodeHintType, Object> hints = new HashMap<>();
    hints.put(EncodeHintType.ERROR_CORRECTION, ErrorCorrectionLevel.M);

    BitMatrix matrix = new QRCodeWriter()
        .encode("https://example.com", BarcodeFormat.QR_CODE, 300, 300, hints);

    BufferedImage image = new BufferedImage(
        300, 300, BufferedImage.TYPE_INT_RGB);

    for (int x = 0; x < matrix.getWidth(); x++) {
        for (int y = 0; y < matrix.getHeight(); y++) {
            image.setRGB(x, y,
                matrix.get(x, y) ?
                0xFF0099FF : // 蓝色数据点
                0xFFFFFFFF); // 白色背景
        }
    }
}

7.2 生成动态GIF二维码

public static void generateAnimatedQR() throws Exception {
    GifSequenceWriter gifWriter = new GifSequenceWriter(
        new FileOutputStream("animated_qr.gif"),
        BufferedImage.TYPE_INT_RGB,
        500, // 帧间隔
        true
    );

    for (int i = 0; i < 10; i++) {
        BufferedImage frame = MatrixToImageWriter.toBufferedImage(
            new QRCodeWriter().encode(
                "Frame " + i,
                BarcodeFormat.QR_CODE,
                200, 200
            )
        );
        gifWriter.writeToSequence(frame);
    }
    gifWriter.close();
}
