cesium中，获取光标处颜色

news 2025/10/13 12:35:24

替换官方的helloworld.html即可

<!doctype html>
<html lang="en">
  <head>
    <!-- Use correct character set. -->
    <meta charset="utf-8" />
    <!-- Tell IE to use the latest, best version. -->
    <meta http-equiv="X-UA-Compatible" content="IE=edge" />
    <!-- Make the application on mobile take up the full browser screen and disable user scaling. -->
    <meta
      name="viewport"
      content="width=device-width, initial-scale=1, maximum-scale=1, minimum-scale=1, user-scalable=no"
    />
    <title>Hello World!</title>
    <script src="../Build/CesiumUnminified/Cesium.js"></script>
    <style>
      @import url(../Build/CesiumUnminified/Widgets/widgets.css);
      html,
      body,
      #cesiumContainer {
        width: 100%;
        height: 100%;
        margin: 0;
        padding: 0;
        overflow: hidden;
      }
    </style>
  </head>
  <body>
    <div id="cesiumContainer"></div>
    <script>
      const viewer = new Cesium.Viewer("cesiumContainer", {
        contextOptions: { webgl: { preserveDrawingBuffer: true } }, // 关键配置
      });
      const scene = viewer.scene;

      let mousePosition = null;
      const handler = new Cesium.ScreenSpaceEventHandler(scene.canvas);
      handler.setInputAction((movement) => {
        mousePosition = movement.endPosition;
        test();
      }, Cesium.ScreenSpaceEventType.MOUSE_MOVE);

      function test() {
        // 精确坐标系转换
        const x = Math.floor(mousePosition.x);
        const y = Math.floor(scene.canvas.height - mousePosition.y);

        if (
          x < 0 ||
          x >= scene.canvas.width ||
          y < 0 ||
          y >= scene.canvas.height
        )
          return;

        // 新版核心修正：直接使用WebGL常量
        const gl = scene.context._gl;
        const pixel = new Uint8Array(4);
        gl.readPixels(
          x,
          y,
          1,
          1,
          gl.RGBA, // 对应格式常量
          gl.UNSIGNED_BYTE, // 对应类型常量
          pixel,
        );

        // 空值保护
        if (!pixel || pixel.length < 4) return;

        const color = Cesium.Color.fromBytes(
          pixel[0],
          pixel[1],
          pixel[2],
          pixel[3],
        );
        console.log(
          "%c" + `RGBA: [${pixel.join(", ")}]`,
          `background-color: ${color.toCssHexString()}`,
        );
      }
    </script>
  </body>
</html>
