防火墙虚拟系统实验
拓扑图
需求一
安全策略要求：
1、只存在一个公网IP地址，公司内网所有部门都需要借用同一个接口访问外网
2、财务部禁止访问Internet，研发部门只有部分员工可以访问Internet，行政部门全部可以访问互联网
3、为三个部门的虚拟系统分配相同的资源类
基础配置
启用虚拟系统
[FW]vsys enable
配置资源类
[FW]resource-class r1---创建资源类r1
[FW-resource-class-r1]resource-item-limit bandwidth 2 outbound
[FW-resource-class-r1]resource-item-limit session reserved-number 500 maximum 1000
[FW-resource-class-r1]resource-item-limit user reserved-number 100
[FW]display resource global-resource------查看剩余公共资源
创建虚拟系统
[FW]vsys name vsysa ---创建虚拟系统，名称为vsysa
[FW-vsys-vsysa]assign resource-class r1 ---设定使用的资源类
[FW-vsys-vsysa]assign interface GigabitEthernet 1/0/1 ---将接口划入虚拟系统
管理员配置
[FW]switch vsys vsysa ---切换到vsysa系统中
[FW-vsysa]aaa
[FW-vsysa-aaa]manager-user admin@@vsysa ---创建vsysa虚拟系统管理员，@@为固定，前为用户名，后为虚拟系统名称
[FW-vsysa-aaa-manager-user-admin@@vsysa]password --配置密码，需要输入两遍，密码没有回显
Enter Password:admin@123
Confirm Password:admin@123
[FW-vsysa-aaa-manager-user-admin@@vsysa]level 15 --设定权限
[FW-vsysa-aaa-manager-user-admin@@vsysa]service-type web telnet ssh ---设定登录服务，一般选择ssh和web即可
[FW-vsysa-aaa-manager-user-admin@@vsysa]quit
[FW-vsysa-aaa]bind manager-user admin@@vsysa role system-admin ---定义admin@@vsysa用户为系统管理员
nat策略配置
[FW]security-policy
[FW-policy-security]rule name to_internet
[FW-policy-security-rule-to_internet]source-zone trust
[FW-policy-security-rule-to_internet]destination-zone untrust
[FW-policy-security-rule-to_internet]action permit
[FW-policy-security]q
[FW]nat-policy
[FW-policy-nat]rule name nat1
[FW-policy-nat-rule-nat1]source-zone trust
[FW-policy-nat-rule-nat1]destination-zone
[FW-policy-nat-rule-nat1]egress-interface GigabitEthernet 1/0/0
[FW-policy-nat-rule-nat1]source-address 10.3.0.0 16
[FW-policy-nat-rule-nat1]action source-nat easy-ip
虚拟系统配置
[FW]switch vsys vsysa
[FW-vsysa]int g1/0/1
[FW-vsysa-GigabitEthernet1/0/1]ip add 10.3.0.254 24
Error: The address already exists.
[FW-vsysa-GigabitEthernet1/0/1]q
[FW-vsysa]interface Virtual-if 1
[FW-vsysa-Virtual-if1]ip add 172.16.1.1 24
[FW-vsysa-Virtual-if1]q
[FW-vsysa]firewall zone trust
[FW-vsysa-zone-trust]add int g 1/0/1
[FW-vsysa]firewall zone untrust
[FW-vsysa-zone-untrust]add int Virtual-if 1
[FW-vsysa-zone-untrust]q
[FW-vsysa]ip route-static 0.0.0.0 0 public
[FW-vsysa]ip address-set ip_add01 type object
[FW-vsysa-object-address-set-ip_add01]add range 10.3.0.1 10.3.0.10
[FW-vsysa-object-address-set-ip_add01]q
[FW-vsysa]security-policy
[FW-vsysa-policy-security]rule name to_internet
[FW-vsysa-policy-security-rule-to_internet]source-zone trust
[FW-vsysa-policy-security-rule-to_internet]destination-zone untrust
[FW-vsysa-policy-security-rule-to_internet]source-address address-set ip_add01
[FW-vsysa-policy-security-rule-to_internet]action permit
虚拟系统配置
[FW]switch vsys vsysb
[FW-vsysb]int g1/0/2
[FW-vsysb-GigabitEthernet1/0/2]ip add 10.3.1.254 24
[FW-vsysb-GigabitEthernet1/0/2]q
[FW-vsysb]int Virtual-if 2
[FW-vsysb-Virtual-if2]ip add 172.16.2.1 24
[FW-vsysb-Virtual-if2]q
[FW-vsysb]firewall zone trust
[FW-vsysb-zone-trust]add int g 1/0/2
[FW-vsysb-zone-trust]q
[FW-vsysb]firewall zone untrust
[FW-vsysb-zone-untrust]add int Virtual-if 2
[FW-vsysb-zone-untrust]q
[FW-vsysb]ip route-static 0.0.0.0 0 public
[FW]switch vsys vsysc
[FW-vsysc]int g1/0/3
[FW-vsysc-GigabitEthernet1/0/3]ip add 10.3.2.254 24
[FW-vsysc]int Virtual-if 3
[FW-vsysc-Virtual-if3]ip add 172.16.3.1 24
[FW-vsysc-Virtual-if3]q
[FW-vsysc]firewall zone trust
[FW-vsysc-zone-trust]add int g1/0/3
[FW-vsysc-zone-trust]q
[FW-vsysc]firewall zone untrust
[FW-vsysc-zone-untrust]add int Virtual-if 3
[FW-vsysc-zone-untrust]q
[FW-vsysc]ip route-static 0.0.0.0 0 public
[FW-vsysc]security-policy
[FW-vsysc-policy-security]rule name to_internet
[FW-vsysc-policy-security-rule-to_internet]source-zone trust
[FW-vsysc-policy-security-rule-to_internet]destination-zone untrust
[FW-vsysc-policy-security-rule-to_internet]source-address 10.3.2.0 24
[FW-vsysc-policy-security-rule-to_internet]action permit
测试
