MongoDB使用x.509证书认证

8.0版本的mongodb开启复制集，配置证书认证

自定义证书

生成CA证书

生成ca私钥： openssl genrsa -out ca.key 4096 # 生成RSA 4096位私钥
生成ca证书： openssl req -x509 -new -nodes -key ca.key -sha256 -days 3650 -out ca.crt -subj "/CN=MongoDB Root CA/O=MyOrg/OU=Security"
验证ca证书： openssl x509 -in ca.crt -text -noout
生成pkcs12格式的p12文件：后续用于java代码认证
cat ca.crt ca.key > ca.pem
openssl pkcs12 -export -in ca.pem -out ca.p12 -password pass:123456

生成服务器之间的证书

生成服务器私钥： openssl genrsa -out server.key 2048
生成证书签名请求： openssl req -new -key server.key -out server.csr -subj "/CN=1.1.1.1/O=MyOrg/OU=Servers"
生成扩展配置文件（server.ext）：

authorityKeyIdentifier=keyid,issuer
basicConstraints=CA:FALSE
keyUsage=digitalSignature, keyEncipherment
extendedKeyUsage=serverAuth
subjectAltName=DNS:mongodb-server.example.com,DNS:localhost,IP:192.168.1.100

用ca签发证书： openssl x509 -req -in server.csr -CA ca.crt -CAkey ca.key -CAcreateserial -out server.crt -days 365 -sha256 -extfile server.ext
合并证书与私钥： cat server.crt server.key > server.pem
验证服务器证书： openssl verify -CAfile ca.crt server.crt # 应显示 “OK”

生成集群证书

生成集群私钥： openssl genrsa -out cluster.key 2048
生成CSR ： openssl req -new -key cluster.key -out cluster.csr -subj "/CN=node1/O=MyOrg/OU=MongoDB-Cluster" 必须包含一致的 O（组织）或 OU（部门），否则集群节点无法相互认证。
生成扩展配置文件（cluster.ext）：

authorityKeyIdentifier=keyid,issuer
basicConstraints=CA:FALSE
keyUsage=digitalSignature, keyEncipherment
extendedKeyUsage=clientAuth

ca签发集群证书： openssl x509 -req -in cluster.csr -CA ca.crt -CAkey ca.key -CAcreateserial -out cluster.crt -days 365 -sha256 -extfile cluster.ext
合并证书与私钥： cat cluster.crt cluster.key > cluster.pem
验证集群证书：
openssl x509 -in cluster.crt -text | grep "Subject:" # 确认O/OU一致性
openssl verify -CAfile ca.crt cluster.crt # 应显示 “OK”

生成用户证书

生成用户私钥： openssl genrsa -out zy1.key 2048
生成CSR ： openssl req -new -key zy1.key -out zy1.csr -subj "/O=MyOrg/CN=zy1" 必须包含一致的 O（组织）或 OU（部门），否则集群节点无法相互认证。
生成扩展配置文件（ zy1.ext）：

authorityKeyIdentifier=keyid,issuer
basicConstraints=CA:FALSE
keyUsage=digitalSignature, keyEncipherment
extendedKeyUsage=clientAuth

ca签发集群证书： openssl x509 -req -in zy1.csr -CA ca.crt -CAkey ca.key -CAcreateserial -out zy1.crt -days 365 -sha256 -extfile zy1.ext
合并证书与私钥： cat zy1.crt zy1.key > zy1.pem
获取subject ： openssl x509 -in /usr/local/database/mongodb8.0.5/crt/zy1.pem -inform PEM -subject -nameopt RFC2253

生成pkcs12 格式的信任库文件：
openssl pkcs12 -export -inkey zy1.pem -in zy1.pem -out zy1_pem.p12 -password pass:123456
测试PKCS12密码正确性
keytool -list -v -keystore C:\Users\Administrator\Desktop\crt\zy1_pem.p12 -storetype pkcs12

MongoDB配置

mongodb配置：

     # mongod.confnet:tls:mode: requireTLSCAFile: /path/to/ca.crtcertificateKeyFile: /path/to/server.pemclusterFile: /path/to/cluster.pemsecurity:clusterAuthMode: x509authorization: enabled

所有pem文件的权限都设为600 ： chmod 600 ca.crt server.pem cluster.pem
客户端的证书由同一CA签发，并且在Mongodb中创建对应用户，如下：用户名为O=MyOrg,CN=zy，需要与证书中的Subject保持一致。可以通过名命令获取：
openssl x509 -in /usr/local/database/mongodb8.0.5/crt/zy1.pem -inform PEM -subject -nameopt RFC2253

db.getSiblingDB("$external").runCommand({createUser: "O=MyOrg,CN=zy",roles: [{ role: "readWrite", db: "test" },{ role: "userAdminAnyDatabase", db: "admin" }],writeConcern: { w: "majority" , wtimeout: 5000 }}
)

java使用x.509证书连接MongoDB

package com.zy.sslcontext;import com.mongodb.ConnectionString;
import com.mongodb.MongoClientSettings;
import com.mongodb.MongoCredential;
import com.mongodb.ServerAddress;
import com.mongodb.client.MongoClient;
import com.mongodb.client.MongoClients;
import com.mongodb.client.MongoCollection;
import com.mongodb.client.MongoDatabase;
import org.bson.Document;import javax.net.ssl.KeyManager;
import javax.net.ssl.KeyManagerFactory;
import javax.net.ssl.SSLContext;
import javax.net.ssl.TrustManagerFactory;
import java.io.FileInputStream;
import java.io.IOException;
import java.io.InputStream;
import java.security.*;
import java.security.cert.CertificateException;
import java.security.cert.CertificateFactory;
import java.security.cert.X509Certificate;
import java.util.Arrays;
import java.util.concurrent.TimeUnit;/*** Connect to a MongoDB cluster with TLS connection.* Validate MongoDB server's certificate with the CA certificate. Present a Client certificate to be validated by* the MongoDB server.** Use X509 certificate to authenticate with the MongoDB server** Create a custom {@link javax.net.ssl.SSLContext} with the TrustStore holding the CA certificate and* the KeyStore holding the Client certificate and provide it to the MongoDB Driver.*/
public class ValidateServerPresentClientCertificateX509Auth {public static void main(String[] args) {//     System.setProperty("javax.net.debug", "ssl:handshake:verbose");// Configure MongoDB Driver to use MONGODB-X509 as authentication mechanism// 此处url可以不用填写用户名密码，则后续配置时采用credential(MongoCredential.createMongoX509Credential())使用证书在的用户信息进行数据操作String connectionString = "mongodb://zy:123456@1.1.1.1:27017/?&ssl=true"; SSLContext sslContext;try {sslContext = getSSLContext();} catch (Exception e) {System.out.println("Failed to generate SSLContext. Error: " + e.getMessage());return;}MongoClientSettings settings = MongoClientSettings.builder().applyConnectionString(new ConnectionString(connectionString)) .applyToSslSettings(builder -> {builder.enabled(true); // 开启sslbuilder.context(sslContext);})
//                .credential(MongoCredential.createCredential("zy","admin","123456".toCharArray()))
//                .credential(MongoCredential.createMongoX509Credential("O=MyOrg,CN=zy"))
//                .credential(MongoCredential.createMongoX509Credential()).applyToConnectionPoolSettings(builder -> builder.maxSize(1)          // 总最大连接数（所有实例总和）.minSize(1)           // 总最小空闲连接数.maxWaitTime(1500, TimeUnit.MILLISECONDS).maxConnectionIdleTime(10, TimeUnit.MINUTES)).applyToSocketSettings(b -> b.connectTimeout(3000, TimeUnit.MILLISECONDS).readTimeout(5000, TimeUnit.MILLISECONDS)).build();MongoClient client = MongoClients.create(settings);MongoDatabase test = client.getDatabase("test");MongoCollection<Document> coll  = test.getCollection("collection1");// Retrieve the first document and print itSystem.out.println(coll.getNamespace());System.out.println(coll.find().first());MongoCollection<Document> collection = client.getDatabase("zy").getCollection("test1");collection.find().forEach(System.out::println);}/*** Load CA certificate from the file into the Trust Store.* Use PKCS12 keystore storing the Client certificate and read it into the {@link KeyStore}* Generate {@link SSLContext} from the Trust Store and {@link KeyStore}** @return SSLContext** @throws IOException* @throws CertificateException* @throws NoSuchAlgorithmException* @throws KeyStoreException* @throws KeyManagementException*/private static SSLContext getSSLContext() throws IOException, CertificateException,NoSuchAlgorithmException, KeyStoreException, KeyManagementException, UnrecoverableKeyException {//        String certsPath = System.getProperty("cert_path");String certsPath = "C:\\Users\\Administrator\\Desktop\\crt\\";// Path to the CA certificate on diskString caCertPath = certsPath + "ca.crt";// 避坑：使用JKS认证失败// openssl pkcs12 -export -inkey zy.key -in zy.pem -out zy.p12// Path to the PKCS12 Key Store holding the Client certificateString clientCertPath = certsPath + "zy1_pem.p12";String clientCertPwd  = "123456";SSLContext sslContext;try (InputStream caInputStream = new FileInputStream(caCertPath);InputStream clientInputStream = new FileInputStream(clientCertPath)) {// Read Client certificate from PKCS12 Key StoreKeyStore clientKS = KeyStore.getInstance("PKCS12");clientKS.load(clientInputStream, clientCertPwd.toCharArray());// Retrieve Key Managers from the Client certificate Key StoreKeyManagerFactory kmf = KeyManagerFactory.getInstance(KeyManagerFactory.getDefaultAlgorithm());kmf.init(clientKS, clientCertPwd.toCharArray());KeyManager[] keyManagers = kmf.getKeyManagers();// Read CA certificate from file and convert it into X509CertificateCertificateFactory certFactory = CertificateFactory.getInstance("X509");X509Certificate caCert = (X509Certificate)certFactory.generateCertificate(caInputStream);KeyStore caKS = KeyStore.getInstance(KeyStore.getDefaultType());caKS.load(null);caKS.setCertificateEntry("caCert", caCert);// Initialize Trust ManagerTrustManagerFactory tmf = TrustManagerFactory.getInstance(TrustManagerFactory.getDefaultAlgorithm());tmf.init(caKS);// Create SSLContext. We need Trust Manager only in this use casesslContext = SSLContext.getInstance("TLS");sslContext.init(keyManagers, tmf.getTrustManagers(), null);}return sslContext;}
}

MongoShell使用证书连接

./mongosh --host 1.1.1.1 --tls --tlsCAFile /usr/local/database/mongodb8.0.5/crt/ca.crt --tlsCertificateKeyFile /usr/local/database/mongodb8.0.5/crt/zy.pem --authenticationDatabase '$external' --authenticationMechanism MONGODB-X509
